Alpine MRV-F340 Owner's Manual

5/4/3 channel power amplifier 4/3/2 channel power amplifier

Hide thumbs

Table Of Contents

Table of Contents

Quick Links

CONTENTS

WARNING ............................................................... 2

CAUTION ................................................................ 3

INSTALLATION ....................................................... 4

CONNECTIONS ....................................................... 6

CONNECTIONS CHECK LIST ................................. 10

SWITCH SETTINGS .............................................. 12

SYSTEM DIAGRAMS ............................................ 15

SPECIFICATIONS .................................................. 19

ACCESSORIES

• End Cover ........................................................... 1

• Terminal Cover ................................................... 1

• Bracket ............................................................... 2

• Hexagon Wrench (M3) ....................................... 1

• Hexagon Wrench (M4) ....................................... 1

• Self-Tapping Screw ............................................ 4

• Machine Screw ................................................... 4

• Hexagon Screw (M3) ......................................... 2

• Hexagon Screw (M4) ......................................... 3

• Double Face Tape ........................................ 1 SET

• Cushion ....................................................... 1 SET

• Insulation Tube (for Power Supply/

for Speaker Output) .................................... 1 SET

• Rubber pipe ........................................................ 1

• Speaker Input Connector (MRV-F340 only) ........ 1

English

MRV-F450

5/4/3 CHANNEL POWER AMPLIFIER

MRV-F540/MRV-F340

4/3/2 CHANNEL POWER AMPLIFIER

• OWNER'S MANUAL

Please read this manual to maximize your enjoyment of the outstanding

performance and feature capabilities of the equipment, then retain the

manual for future reference.

• MODE D'EMPLOI

Veuillez lire ce mode d'emploi pour tirer pleinement profit des

excellentes performances et fonctions de cet appareil, et conservez-le

pour toute référence future.

• MANUAL DE OPERACION

Lea este manual, por favor, para disfrutar al máximo de las

excepcionales prestaciones y posibilidades funcionales que ofrece el

equipo, luego guarde el manual para usarlo como referencia en el futuro.

English

TABLE DES MATIERES

AVERTISSEMENT ...................................................... 2

ATTENTION ................................................................ 3

INSTALLATION .......................................................... 4

CONNEXIONS ............................................................ 6

LISTE DE VERIFICATION DES CONNEXIONS ........... 10

REGLAGES DE COMMUTATEUR .............................. 12

DIAGRAMMES DU SYSTEME .................................. 15

SPECIFICATIONS ..................................................... 19

ACCESSOIRES

• Couvercle d'achèvement ........................................ 1

• Couvercle cache-bornes ........................................ 1

• Support ................................................................. 2

• Clé hexagonale (M3) ............................................. 1

• Clé hexagonale (M4) ............................................. 1

• Vis autotaraudeuse ................................................ 4

• Vis à métaux .......................................................... 4

• Vis à six pans (M3) ............................................... 2

• Vis à six pans (M4) ............................................... 3

• Ruban adhésif double face ............................. 1 JEU

• Coussin .......................................................... 1 JEU

• Tube d'isolation (pour alimentation/

pour la sortie de haut-parleur) ......................... 1 JEU

• Tube en caoutchouc .............................................. 1

• Connecteur d'entrée de haut-parleur

(uniquement MRV-F340) ....................................... 1

Français

ADVERTENCIA ........................................................ 2

PRUDENCIA ........................................................... 3

INSTALACION ......................................................... 4

CONEXIONES ......................................................... 6

LISTA DE VERIFICACION DE CONEXIONES .......... 10

AJUSTES DEL INTERRUPTOR .............................. 12

DIAGRAMAS DEL SISTEMA ................................. 15

ESPECIFICACIONES ............................................. 19

ACCESORIOS

• Cubierta de acabado ........................................... 1

• Cubierta de terminales ....................................... 1

• Soporte .............................................................. 2

• Llave hexagonal (M3) ......................................... 1

• Llave hexagonal (M4) ......................................... 1

• Tornillo autorroscante ........................................ 4

• Tornillo para metales .......................................... 4

• Tornillo hexagonal (M3) ..................................... 2

• Tornillo hexagonal (M4) ..................................... 3

• Cinta de doble cara ................................. 1 JUEGO

• Almohadilla ............................................ 1 JUEGO

• Tubo de aislamiento (para la alimentación/

para la salida de altavoz) ........................ 1 JUEGO

• Tubo de caucho .................................................. 1

• Conector de entrada del altavoz

(MRV-F340 solamente) ...................................... 1

Español

INDICE

Table of Contents

Need help?

Do you have a question about the MRV-F340 and is the answer not in the manual?

Questions and answers

Summary of Contents for Alpine MRV-F340

Page 1 • Cushion ... 1 SET • Insulation Tube (for Power Supply/ for Speaker Output) ... 1 SET • Rubber pipe ... 1 • Speaker Input Connector (MRV-F340 only) ... 1 MRV-F450 5/4/3 CHANNEL POWER AMPLIFIER MRV-F540/MRV-F340 4/3/2 CHANNEL POWER AMPLIFIER •...
Page 2 Prière de lire attentivement ce MODE D'EMPLOI pour se familiariser avec chaque commande et fonction. Chez Alpine, nous espérons que le nouveau MRV-F450/MRV- F540/MRV-F340 donnera de nombreuses années de plai- sir d'écoute. En cas de problèmes lors de l'installation du MRV-F450/ MRV-F540/MRV-F340, prière de contacter le revendeur...
Page 3: Prudencia
PROBLEME. Le non-respect de cette précaution peut entraîner des blessures ou endommager l’appareil. Retourner l’appareil auprès du distributeur Alpine agréé ou un centre de service après-vente Alpine en vue de la réparation. FAIRE INSTALLER LE CABLAGE ET L’APPAREIL PAR DES EXPERTS. Le câblage et l’installation de cet appa- reil requiert des compétences techniques et de l’expé-...
Page 4: Installation
Español INSTALACION Debido a la salida de alta potencia del MRV-F450/MRV-F540/ MRV-F340, se produce un calor considerable cuando el am- plificador está en funcionamiento. Por esta razón, el amplifi- cador deberá montarse en una ubicación que permita la libre circulación de aire, como por ejemplo dentro del maletero.
Page 5: Bracket
English MOUNTING THE END COVERS • The product’s appearance can be improved by mount- ing the end covers on the main unit after installation. • Mount the end covers after installing the main unit. 1. Mounting the brackets 1) Use the included machine screws 6 to mount the two included brackets 5 onto the side opposite the terminal surface.
Page 6: Connections
(remove any paint or grease if necessary) of the car chassis. • If you add an optional noise suppressor, connect it as far away from the unit as possible. Your Alpine dealer carries various noise suppressors, contact them for further information.
Page 7 Subwoofer Output Terminals (CH-5) (MRV-F450 only) Speaker Output Terminals The MRV-F450/MRV-F540/MRV-F340 has two sets of speaker outputs. Be sure to observe correct speaker output connections and phasing. In the ste- reo mode, connect the right speaker outputs to the right speaker and the left to left.
Page 8 When not using the RCA Line Input connectors, you should connect these wires to the speaker output leads of your head unit. The MRV-F340 accepts input from high power or standard power head units. Å...
Page 9: Vis À Six Pans (M4)
English Hexagon screw (M4)/Vis à six pans (M4)/ Tornillo hexagonal (M4) Cautions on wire lead connections When using third-party wire cables (power supply cord), use the supplied hex screws (M4) and the hex wrench (M4) to simplify the connection. Refer to the description below for the proper procedure. If you are in doubt about how to make this connection, consult your dealer.
Page 10: Liste De Verification Des Connexions
Throw) switch, in addition to the 3A fuse mentioned above, may be installed in-line on the MRV-F450/MRV- F540/MRV-F340 turn-on lead. This switch will then be used to turn on (and off) the MRV-F450/MRV-F540/ MRV-F340. Therefore, the switch should be mounted so it is accessible to the driver.
Page 11: Hexagon Screw (M3)
English MOUNTING THE TERMINAL COVER • The product’s appearance can be improved by mounting the terminal cover on the main unit after installation. • Mount the terminal cover after the connections have been made and you have checked that operation is normal. 1.
Page 12: Switch Settings
Ajuste la de ganancia de entrada del MRV-F450/MRV-F540/ MRV-F340 a su posición mínima (4V). Utilizando un CD di- námico como fuente, aumente el volumen de la unidad prin- cipal hasta que haya distorsión. Después, reduzca de un paso el volumen (o hasta que la salida no salga distorsionada).
Page 13 English è Input Channel Selector Switch a) Setting this switch to "3+4" will send the signal at the inputs of CH-3/4 to CH-5 of the MRV-F450. This eliminates the need for "Y"-adaptors when using a head unit with front and rear pre-amp out- puts.
Page 14 Setting this switch to "1/2" will send the signal at the inputs of CH-1/2 to CH-3/ 4 of the MRV-F540/MRV-F340. This eliminates the need for "Y"-adaptors when using a head unit with a single pair of pre-amp output.
Page 15: System Diagrams
SYSTEM DIAGRAMS/DIAGRAMMES DU SYSTEME/DIAGRAMAS DEL SISTEMA English MRV-F450 5-Channel System/Système à 5 canaux/Sistema de 5 canales Subwoofer – – – BRIDGED CH-2 CH-1 CH-3 CH-1 CH-5 CH-5 CH-4 CH-3 CH-4 CH-2 BRIDGED – Subwoofer – – – BRIDGED CH-1 CH-3 CH-1 CH-2 CH-5...
Page 16 MRV-F450 English 4-Channel System/Système à 4 canaux/Sistema de 4 canales Subwoofer – – – BRIDGED CH-2 CH-1 CH-3 CH-1 CH-5 CH-5 CH-3 CH-4 CH-4 CH-2 BRIDGED – Subwoofer 3-Channel System/Système à 3 canaux/Sistema de 3 canales Subwoofer – – BRIDGED CH-3 CH-1 CH-2...
Page 17 MRV-F540 English 4-Channel System/Système à 4 canaux/Sistema de 4 canales – – BRIDGED BRIDGED CH-3 CH-1 CH-4 CH-2 CH-3 CH-1 CH-1+3 INPUT SPEAKER OUTPUT CH-4 CH-2 CH-2+4 – – 3-Channel System/Système à 3 canaux/Sistema de 3 canales – – BRIDGED BRIDGED CH-4 CH-3...
Page 18 MRV-F340 English 2-Channel System/Système à 2 canaux/Sistema de 2 canales – BRIDGED CH-4 CH-2 CH-1 CH-3 CH-1 CH-1+3 INPUT SPEAKER LEVEL INPUT CH-4 CH-3 CH-4 CH-2 CH-2+4 BRIDGED – Speaker Input Leads System (4-Channel System)/Système des conducteurs d’entrée de haut-parleur (Système à 4 canaux)/Sistema...
Page 19: Specifications
(12-3/8" x 2-11/16" x 9-11/16") Weight MRV-F450 ... 5.5 kg (12 lbs. 2 oz) MRV-F540 ... 5.5 kg (12 lbs. 2 oz) MRV-F340 ... 4.0 kg (8 lbs. 13 oz) NOTE: For product improvement, specifications and design are sub- ject to change without notice.
Page 20: Soins Pratiques
Enregistrer le numéro de série de l'appareil dans l'espace prévu ici et le conserver en permanence. La plaque de numéro de série est située à l'arrière de l'appareil. ALPINE ELECTRONICS OF AUSTRALIA PTY. LTD. 6-8 Fiveways Boulevarde Keysborough, Victoria 3173, Australia Tel.: (03) 9769-0000...

This manual is also suitable for:

Mrv-f450 Mrv-f540 Icf-cd831 Icf-cd831l
