SERVICE MANUAL 4 CHANNEL POWER AMPLIFIER TO ALPINE Home Page 5 / 03-A 68E35552S01 MRV-F900...
Page 2
Contents Packing Assembly Parts List Packing Method View Specifications Adjustment Procedures Block Diagram Parts Layout on P.W.Boards and Wiring Schematic Diagram Terminal Voltage of IC/ TR Description of IC Terminal Exploded View (Cabinet) Cabinet Assembly Parts List Electrical Parts List NOTE : Due to continuing product improvement, specifications and designs are subject to change without notice.
Adjustment Procedures 1. Idling Adjustment (1) Connection (3) Control Settings GAIN Control ..........MIN (2) Adjustment Procedures Test Point/ P.W.Board Step Connection Adjustment Coordinates (1) BATT : OFF , REMOTE : OFF (2) VR100,VR200,VR300,andVR400are turnedclockwise. (3) BATT : ON , REMOTE : ON TP8018- TP8019 The pointwith which a value serves as the maximum in a test pointis investigated.
Page 5
Test Point/ P.W.Board Step Connection Adjustment Coordinates The pointwith which a value serves as the maximum in a test pointis investigated. (TEST POINT 1 : TP8018- TP8019, TEST POINT 2 : TP8020- TP8021, TEST POINT 3 : TP8022- TP8023) TP8018- TP8019 (4-A) (4-A) The value of the pointwith which a value serves as the maximum in a test point...
