Hanna Instruments HI 99181 Instruction Manual

Instruction Manual
HI 99181
Portable Waterproof
Skin pH Meter
w w w . h a n n a i n s t . c o m
WARRANTY
All Hanna Instruments meters are warranted
for two years against defects in workmanship
and materials when used for their intended pur-
pose and maintained according to instructions.
The probes are warranted for a period of
six months.
This warranty is limited to repair or replacement
free of charge. Damage due to accidents, misuse,
tampering or lack of prescribed maintenance are
not covered.
If service is required, contact the dealer from
whom you purchased the instrument. If under
warranty, report the model number, date of pur-
chase, serial number and the nature of the prob-
lem. If the repair is not covered by the warranty,
you will be notified of the charges incurred. If the
instrument is to be returned to Hanna Instruments,
first obtain a Returned Goods Authorization Num-
ber from the Customer Service department and
then send it with shipment costs prepaid. When
shipping any instrument, make sure it is properly
packaged for complete protection.
All rights are reserved. Reproduction in whole or in
part is prohibited without the written consent of the
copyright owner.
Dear Customer,
Thank you for choosing a Hanna Instruments
Product.
Please read this instruction manual carefully
before using the instrument.
If you need additional technical information,
do not hesitate to e-mail us
tech@hannainst.com
This instrument is in compliance with the
directives.
PRELIMINARY EXAMINATION
Remove the instrument from the packing ma-
terial and examine it carefully to make sure
that no damage has occurred during ship-
ment. If noticeable damage is evident, notify
your dealer.
Note: Save all packing material until you
are sure that the instrument func-
tions correctly. All defective items
must be returned in the original pack-
ing together with the supplied ac-
cessories.
GENERAL DESCRIPTION
HI 99181 is a portable, microprocessor-
based pH and temperature meter with a spe-
cial probe. The HI 1414D/50 probe has been
specially designed with flat tip for skin pH
measurement.
Moreover, a built-in temperature sensor al-
lows simultaneous pH and temperature
readings and a mini amplifier renders mea-
surements impervious to noise and electri-
cal interferences.
The meter is supplied in a rugged carrying
case, complete with:
•
HI 1414D/50 pH/temperature probe with
flat tip, 50 mm-long body, DIN connector
and 1 m (3.3') cable
• HI 70004 pH 4.01 buffer, 20 mL sachet
•
HI 70007 pH 7.01 buffer, 20 mL sachet
•
HI 700620 cleaning & disinfection solution
for skin residuals, 20 mL sachet (2 pcs.)
• HI 700621 cleaning solution for skin grease
and sebum, 20 mL sachet (2 pcs.)
• batteries and instructions
LCD DESCRIPTION
at
1. Automatic Temperature Compensation
indicator
2. Stability indicator
3. Battery percentage
4. pH calibration indicator
5. Low battery indicator
6. Selectable temperature unit
7. Secondary display
8. Primary display
9. Measuring unit for primary display
SPECIFICATIONS
Range -2.00 to 16.00 pH
-5.0 to 105.0°C / 23.0 to 221.0°F
Resolution 0.01 pH / 0.1°C / 0.1°F
Accuracy ±0.02 pH
±0.5°C up to 60°C; ±1°C outside
(@20°C/68°F)
±1°F up to 140°F; ±2°F outside
Typical EMC
Deviation ±0.2°C / ±0.4°F
Temp. Compensation
pH Calibration Automatic, 1 or 2 point
with 2 sets of standardized buffers
(4.01/7.01/10.01 or 4.01/6.86/9.18)
Probe (included)
amplified pH/temperature probe
Battery Type 3 x 1.5V AA / IEC LR6
Battery Life Approx. 1500 hours
Auto-off After 8 minutes of non-use
Environment 0 to 50°C; RH 100%
Dimensions150 x 80 x 36 mm (5.9 x 3.2 x 1.4")
Weight
ACCESSORIES
HI 1414D/50 Amplified pH probe with flat tip,
50 mm-long body, built-in tem-
perature sensor, DIN connec-
tor and 1 m (3.3') cable.
HI 70004P pH 4.01 buffer solution, 20 mL
sachet (25 pcs.)
HI 7004L pH 4.01 buffer solution, 500 mL
bottle
HI 70006P pH 6.86 buffer solution, 20 mL
sachet (25 pcs.)
HI 7006L pH 6.86 buffer solution, 500 mL
bottle
HI 70007P pH 7.01 buffer solution, 20 mL
sachet (25 pcs.)
HI 7007L pH 7.01 buffer solution, 500 mL
bottle
HI 70300M Storage solution, 230 mL bottle
HI 70300L Storage solution, 500 mL bottle
HI 7061M General purpose cleaning so-
lution, 230 mL bottle
HI 7061L General purpose cleaning so-
lution, 500 mL bottle
HI 700620P Cleaning & disinfection solu-
tion for skin residuals, 20 mL
sachet (25 pcs.)
HI 70620M Cleaning & disinfection solu-
tion for skin residuals, 230 mL
HI 70620L Cleaning & disinfection solu-
tion for skin residuals, 500 mL
HI 700621P Cleaning solution for skin
grease and sebum, 20 mL sa-
chet (25 pcs.)
±0.02 pH
HI 70621M Cleaning solution for skin
grease and sebum, 230 mL
Automatic
HI 70621L Cleaning solution for skin
grease and sebum, 500 mL
HI 70960 Electrolyte solution for sample
preparation, 30 mL bottle
HI 1414D/50
HI 710007 Blue shockproof rubber boot
HI 710008 Orange shockproof rubber boot
HI 721312 Hard carrying case
Hanna Instruments reserves the right to
modify the design, construction and appear-
ance of its products without advance notice.
210 g (7.4 oz.)
IST99181R1 05/05
