- Page 1 Elo Entuitive Touchmonitor User Guide For 12.1" LCD Kiosk Touchmonitors 1247L Series Revision A...
-
Page 2: User Guide
Elo Entuitive Touchmonitor User Guide 12.1" LCD Kiosk Touchmonitor 1247L Series Revision A P/N 008570 Elo TouchSystems, Inc. 1-800-ELOTOUCH www.elotouch.com... - Page 3 Elo TouchSystems. Disclaimer The information in this document is subject to change without notice. Elo TouchSystems makes no representations or warranties with respect to the contents hereof, and specifically disclaims any implied warranties of merchantability or fitness for a particular purpose. Elo TouchSystems reserves the right to revise this publication and to make changes from time to time in the content hereof without obligation of Elo TouchSystems to notify any person of such revisions or changes.
-
Page 5: Table Of Contents
Table of Contents Chapter 1 Introduction Product Description ....1 Precautions ....1 About the Product . -
Page 6: Introduction
Product Description Congratulations on your purchase of an Elo TouchSystems Entuitive touchmonitor. Your new touchmonitor combines the reliable performance of Elo’s touch technology with the latest advances in LCD display design. This combination of features creates a natural flow of information between a user and your touchmonitor. -
Page 7: About The Product
About the Product Your LCD Desktop Touchmonitor is a 12.1” SVGA TFT color display with the following features: • High contrast color TFT LCD display support resolution up to SVGA 800x600. Compatible with IBM VGA and VESA. • Power management system conforms to VESA DPMS standard. •... -
Page 8: Installation And Setup
This chapter discusses how to install your LCD touchmonitor and how to install Elo TouchSystems driver software. Unpacking Your Touchmonitor Check that the following 9 items are present and in good condition: Brick power supply Power cable US/Canada NSTALLATION AND... -
Page 9: Product Overview
Product Overview Main Unit Rear View E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e... -
Page 10: Touch Interface Connection
Touch Interface Connection Before connecting the cables to your touchmonitor and PC, be sure that the computer and touchmonitor are turned off. Connect one end of the power adapter to the monitor and the other end to the connector of the power cord. Connect one end of the video cable to the rear side of computer and the other to the LCD monitor. -
Page 11: Installing The Driver Software
Installing the Driver Software Elo TouchSystems provides driver software that allows your touchmonitor to work with your computer. Drivers are located on the enclosed CD-ROM for the following operating systems: • Windows XP • Windows 2000 • Windows Me • Windows 98 •... -
Page 12: Installing The Serial Touch Driver
Installing the Serial Touch Driver Installing the Serial Touch Driver for 95/98 and NT 4.0 For Windows 2000 and NT 4.0 you must have administrator access rights to install the driver. Insert the Elo CD-ROM in your computer’s CD-ROM drive. If the AutoStart feature for your CD-ROM drive is active, the system automatically detects the CD and starts the setup program. -
Page 13: Installing The Serial Touch Driver For Ms-Dos And Windows 3.1
Installing the Serial Touch Driver for MS-DOS and Windows 3.1 You must have a DOS mouse driver (MOUSE.COM) installed for your mouse if you wish to continue using your mouse along with your touchmonitor in DOS. To install Windows 3.x and MS-DOS from Windows 95/98, follow the directions below: Insert the Elo CD-ROM in your computer’s CD-ROM drive. -
Page 14: Operation
H A P T E R PERATION HAPTER About Touchmonitor Adjustments Your touchmonitor will unlikely require adjustment. Variations in video output and application may require adjustments to your touchmonitor to optimize the quality of the display. For best performance, your touchmonitor should be operating in native resolution, that is 800x600 at 60-75 Hz. - Page 15 Control Power Switch Down 3-10 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e Function Turns the display system power on or off. Displays the OSD menus on the screen and used to select (“Up”...
- Page 16 CONNECTIONS ON UNDERSIDE Power Connector Connect the power adapter. Video Connector This can be connected with the D-sub 15 pin signal connector. Touchscreen connector This is for connecting the touch panel RS232 connector. (optional) OSD Remote connector Connect the remote function key. 3-11...
-
Page 17: Controls And Adjustment
Controls and Adjustment OSD Menu Functions To Display and Select the OSD Functions: Press once to display the OSD function main menu. Press DOWN To Adjust the Va lue of the Control Option: Pressing + / - button changes the value of the selected OSD control option. After adjusting the values, the monitor will automatically save the changes when user selected Save Exit. -
Page 18: Osd Control Options
OSD Control Options OSD Menu Brightness • Adjust the brightness using and buttons. Contrast • Adjust the contrast using buttons Color • Adjust the value of color gain (RED, GREEN, or BLUE) using + and - buttons. Auto Tune • Press buttons to make LCD monitor adjust the related parameters automatically for optimal display status. -
Page 19: Frequency
Qualtity (included Frequency, Phase, Track and Text/GRP) Frequency This item is used to decrease the vertical interference. Select one display pattern from your computer. and buttons on the LCD monitor to decrease the vertical interference to get the optimal display. Phase This item is used to decrease the horizontal interference. -
Page 20: Horizontal
OSD Menu Position (included Horizontal and Vertical) Horizontal • Pressing moves the display image to the right; Pressing moves the display image to the left. Vertical • Pressing moves the display image upward; Pressing moves the display image downward. Language (included ENGLISH, CHINESE, JAPANESE) •... - Page 21 3-16 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e...
-
Page 22: Appendix A
If you are experiencing trouble with your touchmonitor, refer to the following table. If the problem persists, please contact your local dealer or our service center. Solutions to Common Problems Problem The monitor does not respond after you turn on the system. Characters on the screen are dim The screen is blank Screen flashes when initialized... - Page 23 4-18 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e...
-
Page 24: Native Resolution
The native resolution of a monitor is the resolution level at which the LCD panel is designed to perform best. For the Elo LCD touchmonitor, the native resolution is 800 x 600 for the 12.1 inch size. In almost all cases, screen images look best when viewed at their native resolution. - Page 25 As an example, a SVGA resolution LCD panel has 800 pixels horizontally by 600 pixels vertically. Input video is also represented by the same terms. XGA input video has a format of 1024 pixels horizontally by 768 pixels vertically. When the input pixels contained in the video input format match the native resolution of the panel, there is a one to one correspondence of mapping of input video pixels to LCD pixels.
-
Page 26: Touchmonitor Safety
Do not use a damaged power cord. Use only the power cord that comes with your Elo TouchSystems Touchmonitor. Use of an unauthorized power cord may invalidate your warranty. -
Page 27: Care And Handling Of Your Touchmonitor
Care and Handling of Your Touchmonitor The following tips will help keep your Elo Entuitive touchmonitor functioning at the optimal level. • To avoid risk of electric shock, do not disassemble the brick supply or display unit cabinet. The unit is not user serviceable. Remember to unplug the display unit from the power outlet before cleaning. -
Page 28: Technical Specifications
Display Modes Your Elo Entuitive touchmonitor is compatible with the following standard video modes: Item Resolution 640X350 640X350 720X400 720X400 640X480 640X480 640X480 640X480 800X600 800X600 800X600 800X600 800X600 ECHNICAL HAPTER Type H. Scan(KHz) V. Scan(Hz) 31.469 70.087 VESA85 37.861 85.080 31.469 70.087... -
Page 29: Touchmonitor Specifications
Touchmonitor Specifications Model LCD Display Display Size Pixel Pitch Display Mode Max. Resolution Contrast Ratio Brightness Response Time Display Color Viewing Angle Input Signal Video Sync Signal Connector Rear Control Plug & Play Touch Panel (optional) Power Adapter Temperature Operating Conditions Humidity Altitude Storage Conditions... -
Page 30: Accutouch Touchscreen Specifications
AccuTouch Touchscreen Specifications Mechanical Construction Top: Polyester with outside hard-surface coating with clear or antiglare finish. Inside: Transparent conductive coating. Bottom: Glass substrate with uniform resistive coating. Top and bottom layers separated by Elo-patented separator dots. Positional Accuracy Standard deviation of error is less than 0.080 in. (2.03 mm). This equates to less than ±1%. -
Page 31: Mounting Options
Mounting Options Horizontal Mount C-26 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e 254+1 4X Customer Option See Notes 193+1... -
Page 32: Vertical Mount
Vertical Mount 245+1 193+1 C-27... -
Page 33: No Bracketmount
No Bracket Mount 254+1 193+1 C-28 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e... -
Page 34: Electrical Safety Information
Centering Lip 26.4 *Noted dimensions are for non-touch, AccuTouch,and IntelliTouch only. For SecureTouch and Infrared add 3.5mm to each dimension Notes for all Mounting Options 1. All drawing centers are the center of the viewable area. 2. LCD Panel Cutout dimensions in option 1 applies to all mounting options. 3. - Page 35 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e...
-
Page 36: Regulatory Information
EGULATORY HAPTER I. Electrical Safety Information: A) Compliance is required with respect to the voltage, frequency, and current requirements indicated on the manufacturer’s label. Connection to a different power source than those specified herein will likely result in improper operation, damage to the equipment or pose a fire hazard if the limitations are not followed. - Page 37 D) General Information to all Users: This equipment generates, uses and can radi- ate radio frequency energy. If not installed and used according to this manual the equipment may cause interference with radio and television communications. There is, however, no guarantee that interference will not occur in any particular installation due to site-specific factors.
- Page 38 E141667 Tested To Comply With FCC Standards FOR HOME OR OFFICE USE N10051...
- Page 39 E l o E n t u i t i v e T o u c h m o n i t o r U s e r G u i d e...
-
Page 40: Warranty
ARRANTY HAPTER Except as otherwise stated herein or in an order acknowledgment delivered to Buyer, Seller warrants to Buyer that the Product shall be free of defects in materials and workmanship. The warranty for the touchmonitors and components of the product is 3 years. Seller makes no warranty regarding the model life of components. - Page 41 THESE REMEDIES SHALL BE THE BUYER’S EXCLUSIVE REMEDIES FOR BREACH OF WARRANTY. EXCEPT FOR THE EXPRESS WARRANTY SET FORTH ABOVE, SELLER GRANTS NO OTHER WARRANTIES, EXPRESS OR IMPLIED BY STATUTE OR OTHERWISE, REGARDING THE PRODUCTS, THEIR FITNESS FOR ANY PURPOSE, THEIR QUALITY, THEIR MERCHANTABILITY, THEIR NONINFRINGEMENT, OR OTHERWISE.
-
Page 42: Index
Numerics 12.1" LCD Touchmonitor (ET12-XXWC-1) Dimensions, 26 About the Product, 2 About Touchm onitor Adjustments, 9 AccuTouch Touchmonitor Specifications, 25 Auto Setup, 13 Brightness, 13 Care and Handling of Your Touchmonit or, 22 Cleaning Your Touchmonitor, 22 Construction, AccuTouch, 25 Contrast, 13 Controls and Adjustment, 12 Display Modes, 23... - Page 43 Touch Activation Force, AccuTouch, 25 Touch not working, 17 Touchmonitor Safety, 21 Touchmonitor Specifications, 24 Touchpoint Density, AccuTouch, 25 Troubleshooting, 17 Unpacking Your Touchmonitor, 3 UXGA, 19 Vertical, 14 Vertical Mount, 27 VGA, 19 Visual Resolution, AccuTouch, 25 Warranty, 33 XGA, 19 I n d e x - 3 8...
-
Page 44: Product Information
