Elo TouchSystems 1229L Specifications

1229L Multifunction 12" LCD Desktop Touchmonitor (3000 Series) - Elo TouchSy...
1229L Multifunction 12" LCD Desktop Touchmonitor (3000 Series)
The 1229L multifunction touchmonitor may be ordered with up to three integrated peripherals, including
an ergonomically-placed magnetic stripe reader (MSR), biometric fingerprint recognition device, and a
rear-facing customer display. All are incorporated into the monitor housing and designed to flow with its
elegant styling. Available with a choice of touch technologies, the 1229L is fully configurable for a variety
of applications in the retail, hospitality, medical, gaming, and amusement markets where its compact
design efficiently saves valuable work space as well as minimizing connections.
Features
Higher brightness, better contrast, and wider viewing angle than most 12" LCDs
"Designed for touch" features such as a stable tilt base
Available with AccuTouch Five-Wire Resistive Technology
credit cards, or any stylus) or, for the ultimate in optics,
Surface Capacitive Technology
Optional ergonomic 3 stripe MSR
with human interface driver (HID) class specification 1.1; and serial, which supports OPOS.
OPOS is only supported in serial version
Optional rear-facing customer display
Optional biometric fingerprint recognition device
Integrated USB hub with two available USB connections. Also allows a single USB cable to carry
the touch signal, MSR and fingerprint data, and output to the customer display. The serial version
has cables/external connectors to carry the touch and MSR data.
Single power supply for all optional devices
Cables hidden from user's view
Built-in speakers located in display head
Multilingual on-screen display (OSD) with extras including speaker volume, treble, bass, and
balance
Mounting holes on base bottom for tabletop security
Base removable,
Controls on the side rather than the front, plus lockout function for public use
Sealed touchscreen; CarrollTouch version features a seamless watertight seal due to its unique
co-molded construction
Diagnostic LEDs for touch and video
Long-lasting product cycle
Worldwide agency approvals
Specifications
1229L
Model
3000
Series
Availability Worldwide
Case/bezel color Dark gray
Size : 12.1" diagonal
Display
Type : Active matrix TFT LCD
Aspect ratio : 4 x 3
Horizontal : 9.69" (246 mm)
Useful screen
Vertical : 7.27" (184.5 mm)
area
Width : 13.9" (353 mm)
Monitor
dimensions Height (inc. base) : 11.6" (295 mm)
Depth (inc. base) : 11.8" (300 mm)
http://www.elotouch.com/common/pfp/pfp.asp?page=/products/lcds/1229l/default.asp
or CarrollTouch Infrared Technology
available in three versions: USB with keyboard emulation; USB
VESA mounting option
(activated with fingernails, gloves,
IntelliTouch Surface-Wave
Seite 1 von 6
Technology,
18.05.2006
