Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld
Telefon +49 (0) 521 / 9 25-00
Ausgabe / Edition:
Änderungsindex
03/2011
Rev. index: 00.0
Special Sewing Machine
•
Telefax +49 (0) 521 / 9 25 24 35 • www.duerkopp-adler.com
Printed in Federal Republic of Germany
868

Instruction manual

Teile-Nr./Part.-No.:
0791 868751

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 868 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Duerkopp Adler 868

Summary of Contents for Duerkopp Adler 868

  • Page 1: Instruction Manual

    Special Sewing Machine Instruction manual Postfach 17 03 51, D-33703 Bielefeld • Potsdamer Straße 190, D-33719 Bielefeld Telefon +49 (0) 521 / 9 25-00 • Telefax +49 (0) 521 / 9 25 24 35 • www.duerkopp-adler.com Ausgabe / Edition: Änderungsindex Teile-Nr./Part.-No.: 03/2011 Rev.
  • Page 2 All rights reserved. Property of Dürkopp Adler AG and copyrighted. Reproduction or publication of the content in any manner, even in extracts, without prior written permission of Dürkopp Adler AG, is prohibited. Copyright © Dürkopp Adler AG - 2011...
  • Page 3 Foreword This instruction manual is intended to help the user to become familiar with the machine and take advantage of its application possibilities in accordance with the recommendations. The instruction manual contains important information on how to operate the machine securely, properly and economically. Observation of the instructions eliminates danger, reduces costs for repair and down-times, and increases the reliability and life of the machine.

  • Page 4: General Safety Instructions

    General safety instructions The non-observance of the following safety instructions can cause bodily injuries or damages to the machine. 1. The machine must only be commissioned in full knowledge of the instruction book and operated by persons with appropriate training. 2.

  • Page 5: Table Of Contents

    Contents Page: Part 2: Installation Instructions Class 868 Scope of Delivery ..........General and transport packing .
  • Page 6 Contents Page: 6.8.3 Connection to the DA321G control unit ....... . 6.8.4 Connecting the sockets of the DA321G control unit .

  • Page 9: Scope Of Delivery

    Scope of Delivery What items are supplied depends on your order. Prior to setting up, please check that all the required parts are present. This description refers to a special sewing machine, of which all individual components can completely be delivered by Dürkopp Adler –...
  • Page 10 Observe the punch-marks of the table plate! 4,5x15 (x 4) 3,5x17 (x 6) 3,9x15 (x 5) 3,5x17 (x 2) B8x35 (x 4)

  • Page 11: Assembling The Stand

    Assembling the stand Assembling the stand components (Standard) – Assemble the individual stand components as shown in the illustration. – Adjust the set screws 8 to insure the stability of the stand. Make sure that the stand is safe by insuring that every single foot of the stand touches the ground.

  • Page 12: Setting The Working Height

    Setting the working height – The working height is adjustable between 750 and 900 mm (measured to the upper edge of the table plate). – Undo screws 1 on the stand braces. – Adjust the table plate horizontally to the required working height. To prevent tilting, pull the table plate out or push it in by the same distance on both sides.

  • Page 13: Sewing Drives

    Sewing drives 4. 1 Drive category, type and use The following sewing drives are available: Subclass Clutch motor DC-positioning drive 868-190020 FIR 1147-F.752.3 * Efka DC1550/DA321G 868-290020 FIR 1148-F.752.3 Efka DC1550/DA321G** 868-190322 Efka DC1550/DA321G 868-190341 Efka DC1550/DA321G** 868-290322 868-290341 868-390322 * This clutch motor incorporates an electromagnetic brake that rapidly stops the rotor when it runs on after the motor has been switched off.

  • Page 14: Fitting The Sewing Drive

    Fitting the sewing drive – Attach the sewing drive 2 with its base 1 on the bottom side of the table plate by screwing the three hexagonal screws (M8 x 15) with washers into the nuts 8 of the table plate bottom. Fitting the pedal –...

  • Page 15: Fitting The Sewing-Drive Control For Machines With Efka Dc 1550 / Da 321G

    Fitting the sewing-drive control for machines with Efka DC 1550 / DA 321G – Fix the sewing-drive control 1 with 4 screws underneath the table plate 2. – Fix the power supply cable of the sewing-drive control with the traction relief clip 3 underneath the table plate. Fitting the set value initiator –...

  • Page 16: Assembling The Machine Head

    Assembling the machine head The sewing machine heads of the class 868 can be fitted into the stand horizontally straight as well as inclined. Therefore the positions of the hinges on the machine head and the fastening of the direct drive must be considered. Fitting the hinges on the machine head Position of the hinges for the Position of the hinges for the...

  • Page 17: Fitting The Direct Drive (Efka Dc 1550/Da321G)

    Fitting the direct drive Position of the motor support for Position of the motor support for the inclined set-up of the machine the straight set-up of the machine 5.3 Tensioning the toothed belt of the direct drive Loosen the screws 1 in order to tighten the toothed belt. The belt tension can be altered by shifting the motor with its support in the oblong hole 2.

  • Page 18: Placing The Sewing Machine Head On The Stand

    Placing the sewing machine head on the stand – If the sewing machine is equipped with motor on the table plate bottom, place the machine head 1 vertically into the table plate’s cutout. – If the machine is equipped with motor on the machine head, incline the machine head 2 in order to place it into the table plate’s cutout.

  • Page 19: Fitting And Tensioning The V-Belt

    Fitting and tensioning the V-belt Only concerns machines with motor on the table plate bottom. V-belt 2, V-belt pulley 1 and belt guard are part of the drive set – Fix the V-belt pulley 1 on the shaft of the sewing drive. –...

  • Page 20: Fitting The Belt Cover

    Fitting the belt cover – Remove the handwheel 1. – When the machine’s motor is situated underneath the table plate mount the belt cover 2 on the machine head . (The belt cover is part of the drive package) – When the machine’s motor is situated on the sewing machine head mount the belt cover 4 and 5 .

  • Page 21: Fitting The Oil Suction Tube

    Fitting the oil suction tube – Remove the cap from the end of the suction tube 3. – Put the end of the suction tube 3 into the fitting of the cover 1. – Snap the tube into the tube holder 5 in the oil sump 2. –...

  • Page 22: Attaching The Knee Lever

    Attaching the knee lever The knee lever 2 mechanically raises the sewing foot. – Attach the knee lever 2. – Undo the screws on the joint 1. – Adjust the knee lever so that it can be conveniently operated with the right knee.

  • Page 23: Fitting The Operating Panel

    Fitting the operating panel – Fix the control panel fixing angle 1 together with the thread guide 2. – Remove the valve cap 4. – Lay the power supply cable 5 of the operating panel as follows: Lay the power supply cable behind valve cap 4 and arm cover 3 in the machine arm and down through the table plate cutout 6.

  • Page 24: Fitting The Sewing Lamp (Optional Equipment)

    5.10 Fitting the sewing lamp (optional equipment) Caution ! Turning off the main switch does not turn off the current for the sewing lamp. Remove the mains plug before connecting.
  • Page 25 The sewing lamp is mounted on the arm cover. In order to do so lift off the arm cover 3. Drill through the fastening holes with a 4,5 mm drill and fasten the holder. – Stick the safety warning label on the front of the main switch 7. –...

  • Page 26: Electrical Connection

    Electrical connection General Caution ! All work on the electrical equipment of this special sewing machine may only be carried out by qualified electricians or other appropriately trained persons. While working on the electrical equipment the mains plug must be removed! Checking the mains voltage Caution !

  • Page 27: Earthing

    Earthing The earthing cable 1 is in the machine’s accessory pack. The earthing cable 1 takes static charges from the machine head to earth via the motor base. – Connect the earthing cable 1 to the flat plug 2 (already screwed on the machine head) and lay it through the cable duct to the motor base.

  • Page 28: Connecting The Sewing Drive To The Mains

    Connecting the sewing drive to the mains Caution: The sewing machine must be connected to the mains with a plug. Clutch motors must be connected to a 3 x 380 - 415V 50/60Hz or 3 x 220 - 240V 50/60Hz three-phase AC. The connection is done according to the connection diagrams 9800 110002 A or 9800 120009 D.

  • Page 29: Connecting The Sewing Light Transformer (Optional Equipment)

    Connecting the sewing light transformer (optional equipment) – Remove the machine’s mains plug. – Pass the mains cable 1 of the sewing-lamp transformer through the cable duct 2 to the main switch. – It is connected to the mains-connection side of the main switch (or motor-protection switch).

  • Page 30: Connecting The Direct Drive

    Connecting the direct drive 6.8.1 Connecting the Hall-effect sensor (Optional Equipment) Only with DC 1550 drive: · Motor mounted under the table · Gear reduction motor - machine 1,55:1 Attention ! Turn off the main switch. Connect the Hall-effect sensor only with the sewing machine switched off.
  • Page 31 – Connect the 9-pole SuB-D plug of the Hall-effect sensor to the bushing “B18" (IPG / HSM / LSM) of the Efka control drive DA321G. – Set the correct machine class with parameter F-290 according to the corresponding parameter sheet 9800 331104 PBXX. –...

  • Page 32: Attaching And Connecting The Sewing Light Transformer (Optional Equipment)

    6.8.2 Attaching and connecting the sewing light transformer (optional equipment) – Remove the machine’s mains plug! – Connect the mains cable of the sewing light transformer to the mains input side of the control unit. Caution ! The sewing-light transformer is directly connected to the mains. It is therefore live even when the main switch is switched off.

  • Page 33: Connecting The Sockets Of The Da321G Control Unit

    6.8.4 Connecting the sockets of the DA321G control unit 6.8.5 Connecting the DA321G control unit – Plug the cable from the controller (pedal) into socket B80 of the controls. – Plug the cable from the motor sensor 1 into socket B2 of the controls.

  • Page 34: Checking The Direction Of Rotation Of The Sewing Drive

    6.8.6 Checking the direction of rotation of the sewing drive Caution ! Before putting the special sewing machine into operation, the direction of rotation of the sewing drive must imperatively be checked. Operating the special sewing machine in the wrong direction of rotation can lead to damages.

  • Page 35: Machine-Specific Parameters

    Position 2 – First push the pedal forward and then completely backwards. – The needle positions in position 2 ( about 66° on the handwheel). – Check the needle position. If one or both needle positions are not correct then carry out the correction of the needle position.

  • Page 37: Pneumatic Connection

    Pneumatic connection Caution: The pneumatic units will only operate properly at a supply pressure of 8 to 10 bar. The special sewing machine’s operating pressure is 6 bar. Pneumatic-connection pack A pneumatic connection pack for stands with compressed-air maintenance unit is available under order no. 0797 003031. It contains the following components: –...

  • Page 38: Lubrication

    Lubrication Caution: danger of injury ! Oil can cause skin eruptions. Avoid protracted contact with the skin. In the event of contact, thoroughly wash the affected area. CAUTION ! The handling and disposal of mineral oil is subject to legal regulation. Deliver used oil to an authorised collection point.

  • Page 39: Sewing Test

    Sewing test A sewing test must be carried out when setting-up is complete. – Insert the mains plug. Caution: danger of injury ! Turn off the main switch. The needle and looper threads may only be threaded with the sewing machine switched off. –...
