- Vehicle connections -
Tip
• • You will need to purchase the necessary vehicle component adapter wire for the vehicle so that the
power supplies can be utilized. (Contact the dealer for further details.)
• • Be sure to wrap the connection wires with electrical tape or another insulation method to insulate them.
- Example of using vehicle adapter wires -
Power supplies
for combined
equipment
From main unit
Vehicle component adapter wires
- 8 -
Vehicle harness
