E23CS75DSS0.eps N58FCCBBB3.eps N58RCFCHA1.eps N58BABAAD3.eps
N58SACKBB11.eps N58TAAAAD5.eps N58CAAAAC10.eps N58XDAAAA1.eps
N58YDAAAC5.eps N58I115TServo.eps W241516401A.eps S241516401A.eps
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FSC23LR5JM0
Series
counter depth
Color
silver mist
Volts
115
Wiring Diagram
241516401
Owner's Guide
241856000
Market
North America
Energy Guide
241615457
Service Data Sheet 241532603
Publication No.
5995510723
08/03/31
(EN/SERVICE/DCS)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23LR5J
©
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FSC23LR5J
Summary of Contents for Frigidaire FSC23LR5J
- Page 1 Product No. FSC23LR5JM0 Series counter depth Color silver mist Volts Wiring Diagram 241516401 Owner's Guide 241856000 Market North America Energy Guide 241615457 Service Data Sheet 241532603 SIDE-BY-SIDE E23CS75DSS0.eps N58FCCBBB3.eps N58RCFCHA1.eps N58BABAAD3.eps REFRIGERATOR N58SACKBB11.eps N58TAAAAD5.eps N58CAAAAC10.eps N58XDAAAA1.eps N58YDAAAC5.eps N58I115TServo.eps W241516401A.eps S241516401A.eps P.O.
-
Page 2: Freezer Door
Publication No: 5995510723 FSC23LR5JM0 FREEZER DOOR N58FCCBBB3 03/08... - Page 3 FSC23LR5JM0 Publication No: 5995510723 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241510204 Gasket-frzr door, black, magnetic 241511601 Bin-door 241837141 Door-frzr, silver mist, complete assy 240581906 Door Stop, black, frzr 241934305 Handle-door, black 218781101 Screw, pan head, 8-18 x 0.625 240598402 Screw, 10-32 x 1/2 240521304 Screw, #8-18 x 3/4...
-
Page 4: Refrigerator Door
Publication No: 5995510723 FSC23LR5JM0 REFRIGERATOR DOOR N58RCFCHA1 03/08... - Page 5 FSC23LR5JM0 Publication No: 5995510723 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241510203 Gasket-refr door, black, magnetic 241516101 Rack-can 241515901 Lug-dairy compartment 241515601 Door-dairy 240581905 Door Stop, black, ref 241534563 Door-refr, silver mist, complete assy 241934302 Handle-door, black 218781101 Screw, pan head, 8-18 x 0.625 240598402 Screw, 10-32 x 1/2 240521304...
- Page 6 Publication No: 5995510723 FSC23LR5JM0 CABINET N58BABAAD3 03/08...
- Page 7 FSC23LR5JM0 Publication No: 5995510723 CABINET POS. NO PART NO. DESCRIPTION 241509804 Cover-air duct 241719711 Cover-evap coil, lower 5303208309 Plug-hole, factory test 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240402702 Screw-#10-32 x 1/4 flat hd 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special 241603703...
- Page 8 Publication No: 5995510723 FSC23LR5JM0 SHELVES N58SACKBB11 03/08...
- Page 9 FSC23LR5JM0 Publication No: 5995510723 SHELVES POS. NO PART NO. DESCRIPTION 241510605 Trim-basket 241657605 Shelf-freezer, flip-up 241657505 Shelf-freezer, fixed wire 241657506 Shelf-freezer, fixed wire 241552801 Light Bulb 241622802 Socket-light 241523202 Harness-wiring 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625 240355240 Shelf-"Spill-Safe", fixed, (3) 240599301 Cover-crisper pan, upper...
- Page 10 Publication No: 5995510723 FSC23LR5JM0 CONTROLS N58TAAAAD5 03/08...
- Page 11 FSC23LR5JM0 Publication No: 5995510723 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241518301 Bushing, motor mounting 241509402 Motor, evaporator fan 241510501 Seal-diffuser 241517701 Clip, evap fan motor 241552801 Light Bulb 241622802 Socket-light 241522801...
- Page 12 Publication No: 5995510723 FSC23LR5JM0 SYSTEM N58CAAAAC10 03/08...
- Page 13 FSC23LR5JM0 Publication No: 5995510723 SYSTEM POS. NO PART NO. DESCRIPTION 240333605 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241516901 Cord-service 6* # 241510802 Harness-wiring, control box 6* # 241519902 Harness-wiring 6* # 241635603 Harness-wiring, machine compt 14 # 240316107 Heater-defrost 15 #...
-
Page 14: Ice And Water Dispenser
Publication No: 5995510723 FSC23LR5JM0 ICE & WATER DISPENSER 03/08... - Page 15 FSC23LR5JM0 Publication No: 5995510723 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976420 Tube-water inlet, inlet valve, to filter 218976421 Tube-water inlet, valve to door 218976915 Tube-water inlet, inlet valve, to filter 240561702 Seal-water inlet, inlet valve, to ice maker 241679003 Cover-module, black 241680507...
-
Page 16: Ice Container
Publication No: 5995510723 FSC23LR5JM0 ICE CONTAINER 37A 34 34 33 N58YDAAAC5 03/08... - Page 17 FSC23LR5JM0 Publication No: 5995510723 ICE CONTAINER POS. NO PART NO. DESCRIPTION 241684701 Auger-ice 241685201 Cam-drive 241515202 Container-ice, bucket only 241685101 Drum-ice disp 241515301 Front-ice container 241726501 Bar-drive 241685301 Gate 241555401 Light Bulb 241559801 Socket-light 241684501 Drive Blade 18 # 241676201 Motor-auger 241522901 Harness-wiring, icmkr/container...
-
Page 18: Ice Maker
Publication No: 5995510723 FSC23LR5JM0 ICE MAKER INSTALLATION PARTS N58I115TServo 03/08... - Page 19 FSC23LR5JM0 Publication No: 5995510723 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976420 Tube-water inlet, inlet valve, to filter 218976421 Tube-water inlet, valve to door 218976915 Tube-water inlet, inlet valve, to filter 240561702 Seal-water inlet, inlet valve, to ice maker 5304459922 Spring, shut-off arm 5304458380...
-
Page 20: Wiring Schematic
Publication No: 5995510723 FSC23LR5JM0 WIRING SCHEMATIC 03/08... -
Page 21: Wiring Diagram
FSC23LR5JM0 Publication No: 5995510723 WIRING DIAGRAM 03/08 # Functional Parts * Non-Illustrated Parts...
