ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FSC23BBDSB2 FSC23BBDSB3 FSC23BBDSB5
Series
counter depth
Color
stain/blk
Volts
115
Wiring Diagram
241516401A
Owner's Guide
241540301
Market
North America
Energy Guide
241538782
Service Data Sheet 241532603
Publication No.
5995426979
05/01/18
(EN/SERVICE/KHB)
357
counter depth
counter depth
stain/blk
stain/blk
115
115
241516401A
241516401A
241540301
241540301
North America
North America
241538782
241538782
241532603
241532603
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FSC23BBDS
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FSC23BBDS and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FSC23BBDS

Summary of Contents for Frigidaire FSC23BBDS

  • Page 1 Product No. FSC23BBDSB2 FSC23BBDSB3 FSC23BBDSB5 Series counter depth counter depth counter depth Color stain/blk stain/blk stain/blk Volts Wiring Diagram 241516401A 241516401A 241516401A Owner's Guide 241540301 241540301 241540301 Market North America North America North America Energy Guide 241538782 241538782 241538782 Service Data Sheet 241532603 241532603 241532603 SIDE-BY-SIDE...

  • Page 2: Freezer Door

    Publication No: 5995426979 FSC23BBDS FREEZER DOOR N58FFDCFA0 01/05...
  • Page 3 FSC23BBDS Publication No: 5995426979 FREEZER DOOR Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 241510204 A B C Gasket-frzr door, black, magnetic 241511602 A B C Bin-door 241545001 A B C Bin-tilt out, tilt-out 241615113 A - C Door-frzr, stainless, complete assy...

  • Page 4: Refrigerator Door

    Publication No: 5995426979 FSC23BBDS REFRIGERATOR DOOR N58RFDCIA0 01/05...
  • Page 5 FSC23BBDS Publication No: 5995426979 REFRIGERATOR DOOR Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 241510203 A B C Gasket-refr door, black, magnetic 241516102 A B C Rack-can 241515901 A B C Lug-dairy compartment 241515601 A B C Door-dairy...
  • Page 6 Publication No: 5995426979 FSC23BBDS CABINET N58BABAAD0 01/05...
  • Page 7 FSC23BBDS Publication No: 5995426979 CABINET Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 241509802 A B C Cover-air duct 240475907 A B C Cover-evap coil, lower 241529301 A B C Plug-hole, factory test 241547901 A B C Switch-light/lamp, frzr door...
  • Page 8 Publication No: 5995426979 FSC23BBDS SHELVES N58SEDLBI1 01/05...
  • Page 9 FSC23BBDS Publication No: 5995426979 SHELVES Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 241510605 A B C Trim-basket 240443357 A B C Shelf-freezer, glass, lower 240443358 A B C Shelf-freezer, glass, upper 241552801 A B C Light Bulb...
  • Page 10 Publication No: 5995426979 FSC23BBDS CONTROLS N58TBAAAB1 01/05...
  • Page 11 FSC23BBDS Publication No: 5995426979 CONTROLS Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 5308000010 A B C Fan Blade, red, evaporator fan 215474201 A B C Washer, "slinger", nylon, evap fan shaft 241518301 A B C Bushing, motor mounting...
  • Page 12 Publication No: 5995426979 FSC23BBDS SYSTEM N58CACBAA0 01/05...
  • Page 13 FSC23BBDS Publication No: 5995426979 SYSTEM Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 240333603 A B C Condenser 218679607 A B C Block-evap coil, styrofoam, (2) 218944001 A B C Drier-filter, R134a System 241516901 A B C Cord-service...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995426979 FSC23BBDS ICE & WATER DISPENSER 01/05...
  • Page 15 FSC23BBDS Publication No: 5995426979 ICE & WATER DISPENSER Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976903 A B C Tube-water inlet, inlet valve, to filter 218976912 A B C Tube-water inlet, valve to door 5304422012...

  • Page 16: Ice Container

    Publication No: 5995426979 FSC23BBDS ICE CONTAINER 37A 34 34 33 N58YDAAAC0 01/05...
  • Page 17 FSC23BBDS Publication No: 5995426979 ICE CONTAINER Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 5304436634 A B C Auger-ice 5304404343 A B C Cam-drive 241515201 A B C Container-ice, bucket only 5304404346 A B C Drum-ice disp 241515301...

  • Page 18: Ice Maker

    Publication No: 5995426979 FSC23BBDS ICE MAKER INSTALLATION PARTS N58I115T 01/05...
  • Page 19 FSC23BBDS Publication No: 5995426979 ICE MAKER Model Index: A FSC23BBDS (FSC23BBDSB2) B FSC23BBDS (FSC23BBDSB3) C FSC23BBDS (FSC23BBDSB5) POS. NO PART NO. DESCRIPTION 218976409 A B C Tube-water-DOOR 218976903 A B C Tube-water inlet, inlet valve, to filter 218976911 A B C Tube-water inlet, inlet valve, to filter 218976912 A B C...

  • Page 20: Wiring Schematic

    Publication No: 5995426979 FSC23BBDS WIRING SCHEMATIC 01/05...

  • Page 21: Wiring Diagram

    FSC23BBDS Publication No: 5995426979 WIRING DIAGRAM 01/05 # Functional Parts * Non-Illustrated Parts...
