Various Settings

How to operate the AUDIO CONTROL

Switching audio control modes

Various audio control modes may be fine-tuned using this procedure.
Press the [AUDIO CONTROL] button for less than one second to select the item
1
to be adjusted.
Modes will switch in the order shown below each time the button is pressed.
VOL ➔ BASS ➔ MID ➔ TREB ➔ BAL ➔ FAD ➔ NON-F*
➔ VOL
*1: NON-F (non-fader) Output is not affected by the settings of the BASS, MID,
TREBLE, loudness function or equalizer.
*2: Setting cannot be made in FM mode.
ATTENTION
Press the [MUTE] button for less than one second to cut the volume or restore it instantly.
WARNING
Do not adjust the volume or other controls while driving the vehicle. Do so only while parked in a
safe location.
Mode
VOL (VOLUME)
BASS
MID (MIDDLE)
TREB (TREBLE)
BAL (BALANCE)
FAD (FADER)
NON-F (NON-FADER)
36
Function
Adjusts volume.
Adjusts bass level. Bass mode can be
adjusted for each source
(CDP/CDC, FM ,AM).
Adjusts middle level. Mid mode can be
adjusted for each source
(CDP/CDC, FM , AM).
Adjusts treble level. Treble mode can be
adjusted for each source
(CDP/CDC, FM , AM).
Adjusts left/right speaker balance.
Adjusts front/rear speaker balance.
Adjusts non-fader level (for connected
sub-woofers, etc.).
1 2
➔ SVC* ➔ LOUD
[AUDIO CONTROL] button
Turn to the Left
Decreases the Increases the
volume. volume.
Emphasizes low
Softens low sounds.
sounds.
Softens medium Emphasizes medium
sounds. sounds.
Emphasizes high
Softens high sounds.
sounds.
Emphasizes left Emphasizes right
speakers. speakers.
Emphasizes rear Emphasizes front
speakers. speakers.
Decreases level. Increases level.
Turn to the Right
