SPECIFICATIONS
GENERAL
Highest quality sink seamlessly drawn of #18 gauge, type 304
(18-8) nickel bearing stainless steel. Underside of sink is fully
protected by heavy duty Sound Guard
Designed to accept waste disposer.
DESIGN FEATURES
Bowl Depth: 10" (Left Bowl), 5-9/16" (Center), 7-1/2" (Right
Bowl).
Finish: Exposed surfaces are hand blended to a lustrous
highlighted satin finish.
Underside: Fully protected by heavy duty Sound Guard
undercoating to prevent condensation and deaden sound.
OTHER
Drain Openings: 3-1/2".
Note: All Elkay undermount sinks are designed to affix easily to
the underside of any solid surface countertop.
OPTIONAL ACCESSORIES
Rinsing Baskets: LKRB715, LKRB1611 and LKERBSS.
Bottom Grid: LKOBG1716.
This sink complies with ANSI Standard A112.19.3M.
This sink is listed by the International Association of
Plumbing and Mechanical Officials as meeting the
U P
C
requirements of the Uniform Plumbing Code.
SINK DIMENSIONS (INCHES)*
Overall
Model
Number
L
W
L
ELUH3920
39
/
20
16
1
2
*Length is left to right. Width is front to back.
**Template and countertop mounting clips are packed with every sink.
1-1/4"
17-1/2"
20"
16"
1-1/4"
10"
12-7/8"
Model ELUH3920 Illustrated
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
undercoating.
™
Inside
Inside
Left
Center
Bowl
Bowl
W
D
L
W
D
L
17
/
10
7 14
/
5
/
11
1
1
9
1
2
8
16
39-1/2"
7"
11-1/2"
5-9/16"
10-1/2"
Lustertone
™
Inside
Right
Minimum
Bowl
Cutout in
Cabinet
W
D
Countertop
Size
See
/
15 7
/
45
1
2
2
Template**
1-1/4"
Installation Profile of ELUH Triple Bowl Models
The template provided with each ELUH sink provides
the only type of installation recommended by Elkay.
15"
17-1/2"
COUNTERTOP
1-1/4"
MOUNTING
BRACKET
7-1/2"
(ELUH Triple bowl)
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
2222 Camden Court
Oak Brook, IL 60523
Undermount Triple Bowl Sink
®
Model ELUH3920
Model ELUH3920
Ship.
Wt.
Lbs.
30
CONTOUR EDGE
TO CUSTOMER DESIRE
FASTENER
(NOT FURNISHED)
1-1/8"
1/2"
SILICONE CAULK
(NOT FURNISHED)
SINK
Printed in U.S.A.
©2003 Elkay
1-157A
(Rev. 9/03)
