Elkay Lustertone ELUH361710 Specifications

SPECIFICATIONS

GENERAL
Highest quality sink formed of #18 gauge, type 304 (18-8)
nickel bearing stainless steel.
DESIGN FEATURES
Bowl Depth: 10".
Finish: Exposed surfaces are hand blended to a lustrous high-
lighted satin finish.
Underside: Fully protected by heavy duty Sound Guard
coating to dampen sound and prevent condensation.
OTHER
Drain Opening: 3-1/2".
NOTE: All Elkay undermount sinks are designed to affix to the
underside of any solid surface countertop.
This sink complies with ASME A112.19.3.
OPTIONAL ACCESSORIES
Rinsing Baskets: LKWRB1316SS, LKWERBSS.
Utensil Caddy for Rinsing Basket: LKWUCSS.
Bottom Grid: LKWOBG1616SS.
Cutting Boards: CB1713, CBS1316.
SINK DIMENSIONS (INCHES)*
Overall
Model
Number L W
ELUH361710 35 3 / 18 1 /
4 2
*Length is left to right. Width is front to back.
**Template and countertop mounting clips are packed with every sink.
1-3/4" R
16"
35-3/4"
1-3/4" R
17-1/4"
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
elkayusa.com
®
Inside Each Bowl
Cutout in
L W D Countertop
See
16 16 10
Template
5"
16"
2222 Camden Court
Oak Brook, IL 60523
® under-
Minimum
Cabinet
Size
39
18-1/2"
COUNTERTOP
16"
MOUNTING
BRACKET
10"
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Lustertone ®
Deep Double Bowl Sink
Model ELUH361710
Model ELUH361710
Installation Profile of ELUH Models
The template provided with each
ELUH sink provides the only type of
installation recommended by Elkay.
FASTENER
(NOT FURNISHED)
1-1/8"
Undermount
1/2"
SILICONE CAULK
(NOT FURNISHED)
SINK
Printed in U.S.A.
©2007 Elkay
1-272
(3/07)
