Elkay Gourmet Cuisine Centré EGPI4322L Specifications

SPECIFICATIONS

GENERAL
Highest quality Gourmet sink bowls are seamlessly drawn of
#18 gauge, type 304 (18-8) nickel bearing stainless steel.
Self-rimming.
DESIGN FEATURES
Bowl Depths: 10" (large bowl) and 6-1/2" (small bowl),
recessed 1/2" below outside of sink.
Coved Corners: 1-1/2" radius.
Finish: Exposed surfaces are polished and hand blended to a
lustrous Lasting Beauty satin finish with a highlighted inside top
radius on the sink bowls.
Underside: Fully protected by heavy duty Sound Guard
coating to prevent condensation and deaden sound.
OTHER
Drain Opening: 3-1/2".
Faucet Holes: 1, 3 or 4 holes.
Cutting Board: CBP1116 cutting board surface furnished with
each sink.
OPTIONAL ACCESSORIES
Rinsing Baskets: LKRB1614 and LKERBSS.
Cutting Surface: CBP1319.
These sinks comply with ANSI Standard A112.19.3M.
These sinks are listed by the International Association
U P of Plumbing and Mechanical Officials as meeting the
C
requirements of the Uniform Plumbing Code.
SINK DIMENSIONS (INCHES)*
Overall
Model
Number L W L
EGPI4322L 43 22 16
EGPI4322R 43 22 7 /
1
*
Length is left to right. Width is front to back
43"
4" 4"
2"
18"
12-7/8"
2"
7-1/2"
12-7/8"
3-3/8"
2"
21-3/4"
2-13/16"
1-3/4" R
1-1/8" R
6-1/2"
1-3/4" R
14-3/8"
Model EGPI4322R4 Illustrated
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
Inside Each Bowl
Left Right
W D L W D
18 10 7 1 / 12 7 / 6 1 /
2 8 2
12 / 6 / 16 18 10
7 1
2 8 2
.
2" 2"
5"
18" 18"
22" 22"
2" 2"
FINISH
DIRECTION
2"
16" 2"
1-1/4"
10" 10"
2222 Camden Court
Oak Brook, IL 60523
Double Bowl Sink with Ribbed Area
Models EGPI4322L and EGPI4322R
under-
®
Model EGPI4322R4
Cutout in
Countertop
(1 / " Radius
1
2
Ribbed Number of
Corners)
Area 1 / " Dia.
1
2
Length L W Faucet Holes
12 7 / 42 3 / 21 3 / 1, 3 or 4
8 8 8
12 / 42 / 21 / 1, 3 or 4
7 3 3
8 8 8
43"
4" 4"
5"
FINISH 7-1/2"
12-7/8"
DIRECTION
16" 21-3/4"
1-1/4"
1-3/4" R
1-1/8" R
1-3/4" R
14-3/8"
Model EGPI4322L4 Illustrated
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Gourmet Cuisine Centré
Model EGPI4322L4
Minimum Ship.
Cabinet Wt.
Size Lbs.
48 35 1 /
2
48 35 /
1
2
5"
3 HOLE CONFIGURATION
MODEL EGPI4322L3
2"
5"
18"
12-7/8"
ONE HOLE CONFIGURATION
MODEL EGPI4322L1
2"
3-3/8"
2"
ONE HOLE CONFIGURATION
MODEL EGPI4322R1
2-13/16"
4"
6-1/2"
3 HOLE CONFIGURATION
MODEL EGPI4322R3
®
4" 4"
5"
4"
5"
Printed in U.S.A.
©2003 Elkay
1-23D
(Rev. 12/03)
