Elkay Lustertone ELU715 Specifications

SPECIFICATIONS

GENERAL

Highest quality sink seamlessly drawn of #18 gauge, type 304
(18-8) nickel bearing stainless steel. Underside of sink is fully
protected by heavy duty Sound Guard
to accept waste disposer.

DESIGN FEATURES

Bowl Depth: 5".
Finish: Exposed surfaces are hand blended to a lustrous high-
lighted satin finish. ELUH715 has highlighted inside top bowl
radius.
Underside: Fully protected by heavy duty Sound Guard
coating to prevent condensation and deaden sound.

OTHER

Drain Opening: 3-1/2".
NOTE: All Elkay custom design undermount sinks are designed
to affix easily to the underside of any solid surface countertop.
Installation: See illustrated profile below.
These sinks comply with ANSI Standard A112.193M.

SINK DIMENSIONS (INCHES)*

Overall
Model
Number L W
ELU715 9 17 / 7
1
4
ELUH715 10 18 1 / 7
4
*Length is left to right. Width is front to back.
**Template and countertop mounting clips are packed with every sink.
3/4" TYP
(8 SIDES)
17-1/4"
15-3/4"
7-1/2"
9"
Model ELU715 Illustrated
The template provided with each ELU/ELUH sink provides the only type of installation recommended by Elkay.
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
1/8" Countertop
Overhang
(ELU Single bowl)
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
undercoating. Designed
®
Inside Bowl
Cutout in
L W D Countertop
/ 15 / 5
1 3
2 4
See
Template**
1 / 15 3 / 5
2 4
5"

Installation Profile of ELU and ELUH Single Bowl Models

COUNTERTOP
SILICONE CAULK
(NOT FURNISHED)
SINK
1/8 (APPROX.)
1-3/8" + 1/4"
_ OVERHANG
2222 Camden Court
Oak Brook, IL 60523
Lustertone
under-
®
Minimum Ship.
Cabinet Wt.
Size Lbs.
15 6
15 6
1-1/4" TYP
(8 SIDES)
18-1/4"
15-3/4"
Model ELUH715 Illustrated
COUNTERTOP
MOUNTING
BRACKET
FASTENER
(NOT FURNISHED)
(ELUH Single bowl)
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
Undermount Single Bowl Sink
®
Models ELU715 and ELUH715
Model ELU715
7-1/2"
10"
CONTOUR EDGE
TO CUSTOMER DESIRE
