Elkay DRKRQ2822 Specifications

SPECIFICATIONS

GENERAL
Lustertone sink with triple ledge. Highest quality sink bowl
seamlessly drawn of #18 gauge, type 304 (18-8) nickel bearing
stainless steel. Self-rimming.
DESIGN FEATURES
DRKRQ Bowl Depth: 7-5/8".
DRKADQ Bowl Depths: 5-1/2", 6" or 6-1/2".
Coved Corners: 1-3/4" vertical and horizontal radius.
Bowl and Faucet Deck Recess: 3/16" below outside edge of
sink.
Finish: Exposed surfaces are hand blended to a lustrous
highlighted satin finish.
Underside: Fully undercoated to dampen sound and prevent
condensation.
OTHER
DRKRQ2822 Series drain opening is 3-1/2" and centered in
bowl as illustrated.
DRKADQ2822 Series drain opening is 3-1/2" and located cen-
tered left-to-right and off-centered front-to-back as illustrated.
Suffix "L" (left) and "R" (right) denotes location of slotted hole
side ledge.
NOTE: Unless otherwise specified, sink is furnished with 3
faucet holes as shown.
SINK DIMENSIONS (INCHES)*
Overall
L W L
Model
Number A B C
DRKRQ Series
DRKRQ2822L 28 22 19
DRKRQ2822R 28 22 19
DRKADQ Series
DRKADQ2822L 28 22 19
DRKADQ2822R 28 22 19
*
Length is left to right. Width is front to back
**
Available in 5-1/2", 6" and 6-1/2" depths. Please consult your sales representative for other depths or
modifications.
THIS PRODUCT, AS CONSTRUCTED IS SUBJECT TO INTERPRETATION OF A.D.A. REQUIREMENTS.
THE UNOBSTRUCTED KNEE SPACE REQUIRED TO SATISFY A.D.A. STANDARDS MAY NOT BE DESIRABLE.
ALL DIMENSIONS IN INCHES, TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay
www.elkayusa.com
®
Model DRKADQ2822 – A.D.A. Compliant Series Sinks
Cutout in
Inside
Countertop
3 1
Each Bowl
(1 1 / " Radius
2
Drain Opening Minimum
W D Corners)
(see above
D E L W for details)
16 7 5 ⁄ 27 3 ⁄ 21 3 ⁄ Centered
8 8 8
16 7 5 ⁄ 27 3 ⁄ 21 3 ⁄ Centered
8 8 8
16 ** 27 3 ⁄ 21 3 ⁄ Off-Centered
8 8
16 ** 27 3 ⁄ 21 3 ⁄ Off-Centered
8 8
.
SEE OTHER SIDE FOR PRODUCT DIMENSIONS.
Triple Ledge Model DRKRQ2822 Series
Model DRKRQ2822R
/ "
2
Ship.
Cabinet Wt.
Size Lbs.
30 16
30 16
30 16
30 16
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
2222 Camden Court
Oak Brook, IL 60523
Lustertone ® Single Bowl Sink
with Quick-Clip
®
Quick-Clip Mounting System
Printed in U.S.A.
©2003 Elkay
(8/03)
®
1-189
