Elkay Celebrity CDKAD2517C Specifications

Celebrity Single Bowl
®
Sink Package – Double Ledge
Model CDKAD2517C
SPECIFICATIONS
GENERAL
Celebrity sink with fountain. #20 gauge, type 304 stainless
steel, self-rimming.
CLASSROOM/INSTITUTIONAL SINK PACKAGE
Model CDKAD2517C features a stainless steel work sink,
LK Series faucet and No Lead Flexi-Guard
includes:
(1) LK208513L Single Wing Handle faucet with fixed
hi-spout and aerator. Outlet height: 9-3/8"; Reach: 4-3/4".
(1) LK1141A No Lead Flexi-Guard
valve design bubbler meets ANSI and ADA requirements.
Designed so that water never comes in contact with lead-
containing materials. Flexi-Guard safety bubbler flexes on
impact to prevent accidental injury when getting a drink.
Built-in adjustable water volume control.
(1) LK35 Duo strainer.
OTHER
Drain Opening: 3-1/2" centered.
SINK DIMENSIONS (INCHES)*
Overall
Model
Number L W
†CDKAD2517C 25 17 15
†CDKAD2517 25 17 15
* Length is left to right. Width is front to back.
† Unless otherwise specified, all sinks which do not have suffix "C" are less fittings (no
faucet, bubbler or drain), but are drilled for faucet, bubbler and drain as illustrated.
3" R
4-5/8"
15-3/4"
25"
2-1/4" R
Model CDKAD2517C Illustrated
ALL DIMENSIONS IN INCHES. TO CONVERT TO MILLIMETERS MULTIPLY BY 25.4.
In keeping with our policy of continuing product improvement, Elkay reserves the right to change
product specifications without notice.
Elkay Manufacturing Company
www.elkay.com
Bubbler. Package
®
Bubbler. Pushbutton
®
Cutout in
Countertop
(1 / " Radius
1
2
Inside Bowl Corners)
L W D L W
⁄ 14 6 ⁄ 24 ⁄ 16 ⁄
3 1 3 3
4 2 8 8
⁄ 14 6 ⁄ 24 ⁄ 16 ⁄
3 1 3 3
4 2 8 8
1-1/2"
14" 17"
4-5/8"
1-1/2"
6-1/2"
Model CDKAD2517C
Ship.
Wt.
Lbs.
17 ⁄
1
2
11
THIS PRODUCT, AS CONSTRUCTED IS SUBJECT TO
INTERPRETATION OF A.D.A. REQUIREMENTS. THE
UNOBSTRUCTED KNEE SPACE REQUIRED TO SATISFY
A.D.A. STANDARDS MAY NOT BE DESIRABLE.
This specification describes an Elkay product with design, quality and functional benefits to the
user. When making a comparison of other producers' offerings, be certain these features are not
overlooked.
2222 Camden Court
Oak Brook, IL 60523
®
Printed in U.S.A.
©2001 Elkay Mfg. Co.
1-89D
(Rev. 3/01)
