Frigidaire FRT185BS Factory Parts Catalog
Frigidaire FRT185BS Factory Parts Catalog

Frigidaire FRT185BS Factory Parts Catalog

Top-mount refrigerator
Hide thumbs Also See for FRT185BS:

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FRT185BSB0
FRT185BS
FRT185BSK0
FRT185BS
MARKET
North America
ENERGY GUIDE - 218791428
OWNER'S GUIDE - 240400108
SERVICE DATA SHEET - 240379010
ELECTROLUX HOME PRODUCTS,INC.
P.O. Box 212378, Augusta, GA 30917
COLOR
VOLTS
stainless (RH)
115
stainless (LH)
115
Publication No.
5995387585
030318
-EN/SERVICE /ECL
390
FACTORY
PARTS CATALO
TOP MOUNT
REFRIGERATOR
Model No.
FRT185BS
©2003 Electrolux Home Products, Inc.
All rights reserved
G

Advertisement

loading
Need help?

Need help?

Do you have a question about the FRT185BS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Frigidaire FRT185BS

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. COLOR VOLTS FRT185BSB0 FRT185BS stainless (RH) FRT185BSK0 FRT185BS stainless (LH) MARKET North America ENERGY GUIDE - 218791428 OWNER’S GUIDE - 240400108 TOP MOUNT SERVICE DATA SHEET - 240379010 REFRIGERATOR Model No. FRT185BS ELECTROLUX HOME PRODUCTS,INC.
  • Page 2 Publication No. FRT185BS 5995387585 DOOR 03/03...
  • Page 3 FRT185BS Publication No. 5995387585 DOOR A = FRT185BS (FRT185BSB0) B = FRT185BS (FRT185BSK0) POS. NO PART NO DESCRIPTION 240542109 Gasket-frzr door,black ,magnetic 240542112 Gasket-refr door,black ,magnetic 240337703 Door-dairy,w/o graphics ,clear 240412503 Door-frzr,stainless ,complete assy 240412504 Door-frzr,stainless ,complete assy 240416304 Nameplate,black 240312405 Door Stop,black ,refr 240312406...
  • Page 4 Publication No. FRT185BS 5995387585 CABINET 03/03...
  • Page 5 FRT185BS Publication No. 5995387585 CABINET A = FRT185BS (FRT185BSB0) B = FRT185BS (FRT185BSK0) POS. NO PART NO DESCRIPTION 240355401 Cover-fan 240367001 Knob-damper control 5303001028 Nut,push-on 240367401 Damper-fan cover 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 240462010 Cover-evap coil 240568601 Seal-coil cover...
  • Page 6 Publication No. FRT185BS 5995387585 SHELVES 03/03...
  • Page 7 FRT185BS Publication No. 5995387585 SHELVES A = FRT185BS (FRT185BSB0) B = FRT185BS (FRT185BSK0) POS. NO PART NO DESCRIPTION 240358002 Shelf-freezer,full width 5303299664 Spacer,shelf 240545001 Diffuser,air ,top 240362601 Diffuser,air ,bottom 14 # 240505801 Switch,light/lamp 240436702 Light Bulb/Lamp,A-15 ,clear ,40 W ,120 V,miniature 16 # 241500701 Socket-light/lamp...
  • Page 8 Publication No. FRT185BS 5995387585 SYSTEM 03/03...
  • Page 9 FRT185BS Publication No. 5995387585 SYSTEM A = FRT185BS (FRT185BSB0) B = FRT185BS (FRT185BSK0) POS. NO PART NO DESCRIPTION 240444401 Condenser,dynamic 218944001 Drier-filter,R134a System 240496101 Wiring Harness,machine compt ,w/electric cord 6* # 240524701 Wiring Harness,freezer section 6* # 240388701 Wiring Harness,control box 14 # 5303918208 Defrost Heater Kit...
  • Page 10: Ice Maker

    Publication No. FRT185BS 5995387585 ICE MAKER 03/03...
  • Page 11 FRT185BS Publication No. 5995387585 ICE MAKER A = FRT185BS (FRT185BSB0) B = FRT185BS (FRT185BSK0) POS. NO PART NO DESCRIPTION 218976901 Tube-water inlet,inlet valve ,to ice maker 240561701 Seal-water inlet,inlet valve ,to ice maker 5304420650 Spring,shut-off arm 3206299 Label,ID plate 3206301 Gear 3206303 Plate-mounting...
  • Page 12: Wiring Schematic

    Publication No. FRT185BS 5995387585 WIRING SCHEMATIC 03/03...
  • Page 13: Wiring Diagram

    FRT185BS Publication No. 5995387585 WIRING DIAGRAM # = Fast-moving Parts 03/03 * = Non-Illustrated Parts...
