Frigidaire FRT18S6A Factory Parts Catalog
Top mount refrigerator
Hide thumbs
Also See for FRT18S6A:
- Factory parts catalog (13 pages) ,
- Factory parts catalog (11 pages) ,
- Factory parts catalog (11 pages)
Advertisement
Quick Links
Download this manual
See also:
Factory Parts Catalog
PRODUCT NO.
BASE MODEL NO.
FRT18S6AB7
FRT18S6A
FRT18S6AQ7
FRT18S6A
FRT18S6AW7
FRT18S6A
MARKET
North America
WIRING DIAGRAM - 240379009
OWNER'S GUIDE - 240400105
SERVICE DATA SHEET - 240379009
ELECTROLUX HOME PRODUCTS,INC.
P.O. Box 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
bisque
R134a
white
Publication No.
5995372520
020521
-EN/SERVICE/DCS
357
FACTORY
PARTS CATALO
VOLTS
115
115
115
TOP MOUNT
REFRIGERATOR
Model No.
FRT18S6A
©2002 Electrolux Home Products, Inc.
All rights reserved
G
Advertisement
Related Manuals for Frigidaire FRT18S6A
Summary of Contents for Frigidaire FRT18S6A
- Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRT18S6AB7 FRT18S6A R134a black FRT18S6AQ7 FRT18S6A R134a bisque FRT18S6AW7 FRT18S6A R134a white MARKET North America WIRING DIAGRAM - 240379009 OWNER’S GUIDE - 240400105 TOP MOUNT SERVICE DATA SHEET - 240379009 REFRIGERATOR Model No.
- Page 2 Publication No. FRT18S6A 5995372520 DOOR 05/02...
- Page 3 FRT18S6A Publication No. 5995372520 DOOR A = FRT18S6A (FRT18S6AB7) B = FRT18S6A (FRT18S6AQ7) C = FRT18S6A (FRT18S6AW7) POS. NO PART NO DESCRIPTION 240514609 A - - Gasket-frzr door,black ,magnetic 240514605 - B C Gasket,frzr door seal ,white ,magnetic 240514612 A - - Gasket,refr door seal ,black ,magnetic 240514608 - B C...
- Page 4 Publication No. FRT18S6A 5995372520 CABINET 05/02...
- Page 5 FRT18S6A Publication No. 5995372520 CABINET A = FRT18S6A (FRT18S6AB7) B = FRT18S6A (FRT18S6AQ7) C = FRT18S6A (FRT18S6AW7) POS. NO PART NO DESCRIPTION 240355401 A B C Cover-fan 240367001 A B C Knob-damper control 5303001028 A B C Nut,push-on 240367401 A B C Damper-fan cover 5308000010 A B C...
- Page 6 Publication No. FRT18S6A 5995372520 SHELVES 05/02...
- Page 7 FRT18S6A Publication No. 5995372520 SHELVES A = FRT18S6A (FRT18S6AB7) B = FRT18S6A (FRT18S6AQ7) C = FRT18S6A (FRT18S6AW7) POS. NO PART NO DESCRIPTION 215667501 A B C Tray,ice cube ,plastic 240358002 A B C Shelf-freezer,full width 5303299664 A B C Spacer,shelf 240362502 A B C Diffuser,air ,top...
- Page 8 Publication No. FRT18S6A 5995372520 SYSTEM 05/02...
- Page 9 FRT18S6A Publication No. 5995372520 SYSTEM A = FRT18S6A (FRT18S6AB7) B = FRT18S6A (FRT18S6AQ7) C = FRT18S6A (FRT18S6AW7) POS. NO PART NO DESCRIPTION 240444401 A B C Condenser,dynamic 218944001 A B C Drier-filter,R134a System 240496101 A B C Wiring Harness, machine compt, w/electric cord 6 *# 240388701 A B C...
-
Page 10: Wiring Schematic
Publication No. FRT18S6A 5995372520 WIRING SCHEMATIC 05/02... -
Page 11: Wiring Diagram
FRT18S6A Publication No. 5995372520 WIRING DIAGRAM # = Fast-moving Parts 05/02 * = Non-Illustrated Parts...
