FGC30S4D.eps LA9922T15.eps LA00BR77490-1.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FGC30S4DBA
3775421264061
Series
30" gas
Color
black
Market
North America
Wiring Diagram
318047111
Owner's Guide
318200657
Installation Instructions 318201451
318047111.eps
Publication No.
5995424388
04/12/15
(EN/SERVICE/ECL)
377
GAS COOK-TOP
RANGE
Model No.
FGC30S4D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Frigidaire FGC30S4D
Summary of Contents for Frigidaire FGC30S4D
- Page 1 " " Product No. FGC30S4DBA 3775421264061 Series 30" gas Color black Market North America Wiring Diagram 318047111 Owner's Guide 318200657 Installation Instructions 318201451 GAS COOK-TOP FGC30S4D.eps LA9922T15.eps LA00BR77490-1.eps 318047111.eps RANGE ELECTROLUX HOME PRODUCTS, INC. Model No. P.O. Box 212378, Augusta, GA 30917 FGC30S4D Publication No.
- Page 2 Publication No: 5995424388 FGC30S4DBA COOK TOP 12/04...
- Page 3 FGC30S4DBA Publication No: 5995424388 COOK TOP POS. NO PART NO. DESCRIPTION 318159144 Panel, main top, black 318167903 Pan, burner, medium, black 318167904 Pan, burner, large, black 318167905 Pan, burner, small, black 318227002 Grate, burner, black, (4) 318076410 Cap, burner, black, medium LF & LR 318076420 Cap, burner, black, large RF 318076400...
- Page 4 Publication No: 5995424388 FGC30S4DBA BURNER 12/04...
- Page 5 FGC30S4DBA Publication No: 5995424388 BURNER POS. NO PART NO. DESCRIPTION 318177003 Manifold Pipe 318087040 Valve, top burner, 13000 BTU 2A # 318087001 Valve, top burner, 5000 BTU 2B # 5303935042 Valve, top burner, 2-position, 9100 BTU 318232604 Wiring Harness, w/igntr switch 318167714 Tube, burner, RF 318167700...
- Page 6 Publication No: 5995424388 FGC30S4DBA WIRING DIAGRAM 12/04...
