Frigidaire FGEF3055K Parts Catalog
30-inch freestanding electric range
Hide thumbs
Also See for FGEF3055K:
- Parts catalog (11 pages) ,
- Important safety instructions manual (36 pages) ,
- Install manual (9 pages)
Advertisement
Quick Links
Download this manual
See also:
Installation Manual
FGEF3055KBA.eps CLGEF3045KFA.eps VFGEF3055KBA.eps TLGEF3045KFA.eps
DFGEF3055KBA.eps
Electrolux Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FGEF3055KBA FGEF3055KWA
Series
30" f/s elec
Color
black
Market
North America
Owner's Guide
316902207
Installation Instructions 316454912
Service Data Sheet
316904401
Publication No.
5995539292
09/05/01
(EN/SERVICE/ECL)
369
30" f/s elec
white
North America
316902207
316454912
316904401
30-INCH FREE-
STANDING ELECTRIC
RANGE
Model No.
FGEF3055K
©
Copyright
2009 Home Products, Inc.
All rights reserved.
Advertisement
Related Manuals for Frigidaire FGEF3055K
Summary of Contents for Frigidaire FGEF3055K
- Page 1 Product No. FGEF3055KBA FGEF3055KWA Series 30" f/s elec 30" f/s elec Color black white Market North America North America Owner's Guide 316902207 316902207 Installation Instructions 316454912 316454912 Service Data Sheet 316904401 316904401 30-INCH FREE- FGEF3055KBA.eps CLGEF3045KFA.eps VFGEF3055KBA.eps TLGEF3045KFA.eps STANDING ELECTRIC DFGEF3055KBA.eps RANGE Electrolux Major Appliances...
- Page 2 Publication No: 5995539292 FGEF3055K BACKGUARD 14 14 CLGEF3045KFA 05/09...
- Page 3 FGEF3055K Publication No: 5995539292 BACKGUARD Model Index: A FGEF3055K (FGEF3055KWA) B FGEF3055K (FGEF3055KBA) POS. NO PART NO. DESCRIPTION 316557600 Shield, rear wall 13A# 316095503 Switch, infinite, warmer 316022500 Light/Lamp, indicator, 125 V 316546704 Cap, backguard, white, RH end 316546702 Cap, backguard, black, RH end 316546705 Cap, backguard, white, LH end 316546703...
- Page 4 Publication No: 5995539292 FGEF3055K BODY 8C 8A NOTE: Oven Liner N/A VFGEF3055KBA Ass. du four N/A 05/09...
- Page 5 FGEF3055K Publication No: 5995539292 BODY Model Index: A FGEF3055K (FGEF3055KWA) B FGEF3055K (FGEF3055KBA) POS. NO PART NO. DESCRIPTION 316401801 Panel, main back 316400116 Panel, bodyside, white, RH 316400117 Panel, bodyside, white, LH 316400118 Panel, bodyside, black, RH 316400119 Panel, bodyside, black, LH 316272900 Screw, leveling, plastic, rear, (2) 316498900...
- Page 6 Publication No: 5995539292 FGEF3055K BODY 8C 8A NOTE: Oven Liner N/A VFGEF3055KBA Ass. du four N/A 05/09...
- Page 7 FGEF3055K Publication No: 5995539292 BODY Model Index: A FGEF3055K (FGEF3055KWA) B FGEF3055K (FGEF3055KBA) POS. NO PART NO. DESCRIPTION 316542600 Plate, grounding strap 66 # 316430900 Element, broil, 4000W 67 # 316563600 Element, hidden bake 316525631 Harness, wiring, bake element, connector 316574100 Cover, terminal, upper, hidden bake 316563300...
- Page 8 Publication No: 5995539292 FGEF3055K TOP/DRAWER TLGEF3045KFA 05/09...
- Page 9 FGEF3055K Publication No: 5995539292 TOP/DRAWER Model Index: A FGEF3055K (FGEF3055KWA) B FGEF3055K (FGEF3055KBA) POS. NO PART NO. DESCRIPTION 316408703 Drawer, utility 316403300 Liner, drawer 316403505 Panel, drawer front, white 316403506 Panel, drawer front, black 316407400 Glide, drawer, rear 15 # 318178110 Element, surface, 6", 1200, (2), radiant 15A#...
- Page 10 Publication No: 5995539292 FGEF3055K DOOR DFGEF3055KBA 05/09...
- Page 11 FGEF3055K Publication No: 5995539292 DOOR Model Index: A FGEF3055K (FGEF3055KWA) B FGEF3055K (FGEF3055KBA) POS. NO PART NO. DESCRIPTION 5303935318 Trim kit-door, 3 sided, white, w/tape 5303935317 Trim kit-door, 3 sided, black, w/tape 316566404 Glass Assembly, outer, white, w/badge 316566405 Glass Assembly, outer, black, w/badge 316503800 Shield, wool 316021109...
