Frigidaire FGC30S4D Factory Parts Catalog

Gas cook-top range
Hide thumbs

Advertisement

Quick Links

"
"
FGC30S4DC.eps LA9922T15-1.eps LA00BR77490-1.eps
318047111.eps
ELECTROLUX HOME PRODUCTS, INC.
P.O. Box 212378, Augusta, GA 30917
Product No.
FGC30S4DCA
37754262740S1 37754262740S2
Series
30" gas
Color
stainless
Market
North America
Wiring Diagram
318047105
Owner's Guide
318200657
Installation Instructions 318201451
318047105.eps
Publication No.
5995417598
04/10/01
(EN/SERVICE/ECL)
377
FGC30S4DCB
30" gas
stainless
North America
318047111
318200657
318201451
GAS COOK-TOP
RANGE
Model No.
FGC30S4D
©
Copyright
2004 Electrolux Home Products, Inc.
All rights reserved.

Advertisement

loading

  Related Manuals for Frigidaire FGC30S4D

  Summary of Contents for Frigidaire FGC30S4D

  • Page 1 Market North America North America Wiring Diagram 318047105 318047111 Owner's Guide 318200657 318200657 Installation Instructions 318201451 318201451 318047105.eps Publication No. 5995417598 04/10/01 (EN/SERVICE/ECL) Copyright GAS COOK-TOP RANGE Model No. FGC30S4D © 2004 Electrolux Home Products, Inc. All rights reserved.
  • Page 2 Publication No: 5995417598 FGC30S4D COOK TOP 10/04...
  • Page 3 5303935029 5303285443 318163602 5303307980 # Functional Parts * Non-Illustrated Parts FGC30S4D COOK TOP A FGC30S4D (FGC30S4DCA) B FGC30S4D (FGC30S4DCB) DESCRIPTION Main Top, stainless Pan, burner, medium, black Pan, burner, large, black Pan, burner, small, black Grate, burner, black, (4) Cap, burner, black, medium LF & LR...
  • Page 4 Publication No: 5995417598 FGC30S4D BURNER 10/04...
  • Page 5 318127407 5303311532 5304403558 # Functional Parts * Non-Illustrated Parts FGC30S4D BURNER A FGC30S4D (FGC30S4DCA) B FGC30S4D (FGC30S4DCB) DESCRIPTION Manifold Pipe Screw, 10-24 x 0.375, square drive Valve, top burner, 13000 BTU Valve, top burner, 5000 BTU Valve, top burner, 2-position, 9100 BTU...
  • Page 6 Publication No: 5995417598 FGC30S4D WIRING DIAGRAM FGC30S4DCA 10/04...
  • Page 7 FGC30S4D Publication No: 5995417598 WIRING DIAGRAM FGC30S4DCB 10/04 # Functional Parts * Non-Illustrated Parts...
