- Page 1 BDW10 USER AND INSTALLATION INSTRUCTIONS...
-
Page 2: Before Using The Appliance
BEFORE USING THE APPLIANCE SAFETY INSTRUCTIONS Norms and regulations to be respected • The dishwasher may only be used to clean household dishes. If the appliance is used for other purposes or in a wrong manner, the manufacturer declines all responsibilities for possible damages. •... -
Page 3: Unpacking - Disposal
UNPACKING – DISPOSAL 2.1 UNPACKING Remove the external plastic packaging material, the corner re-enforcements, and the styrofoam base. Open the door and remove the styrofoam blocks from the inside baskets. Collect and recycle the packaging materials. This will preserve primary materials and help reduce the amount of waste. -
Page 4: General Parts
DESCRIPTION OF THE APPLIANCE 4.1 GENERAL PARTS salt container rinse aid container fan forced drying (for BDW10)* container for detergent data tag filters lower spray-arm upper spray-arm electric connection lead 10) water supply hose 11) water drainage hose 12) lower basket 13) upper basket 14) cutlery container 15) hook for door closing mechanism... -
Page 5: Installation
INSTALLATION 5.1 LEVELLING Place the appliance in the spot where you want to install it. Use feet P (unscrew or screw in) to regulate (if necessary) the height of each foot to assure that the appliance is in a fully level position. If the appliance is positioned in a level position, its correct functioning is assured. -
Page 6: Electric Connections
5.3 CONNECTION OF DRAINAGE WATER The curved end of drainage hose T, should be hooked into the drainage stand pipe or alternatively over the edge of your sink. During installation, the following precautions should be taken: - the drainage hose must not be bent to or crushed; - the hose end, relative to the top surface of the dishwasher (fig. - Page 7 6.1 BEFORE USING THE APPLIANCE Before turning on the appliance, make sure that the plug attached to the electric cable is connected to the electric outlet, the water supply tube is connected to the faucet, the faucet is turned on, the drainage tube has been connected according to the instructions. Opening of the door Pull the handle forward.
- Page 8 Indication of salt level (if present) The green mark under the cap indicates that there is still enough salt in the container. If the green mark is no longer visible, the salt container needs to be refilled with special dishwasher salt. Refilling of rinse aid The rinse aid, which is released automatically dur- ing the final phase of the wash cycle, guarantees...
-
Page 9: Adding The Detergent
Regulation of rinse aid dosage The regulation R of the quantity of rinse aid that is released can be found in the refill opening of the rinse aid container. It can be adjusted with a screwdriver. The possible settings range from 1 to 4,1 corresponds to a release of one ml of rinse aid, 4 to four ml, etc. - Page 10 How to load and unload the dishwasher There are two dish baskets that allow you to store all different kinds of dishes. • Remove from the dishes any larger pieces of food to avoid an obstruction of the filter and the development of bad odours.
- Page 11 Use of the upper basket The upper basket can be pulled out all the way. It holds small and medium sized dishes such as glasses, small plates, tea and coffee cups, small salad bowls, and small pans and pots that are not very dirty.
- Page 12 Pulling out the upper basket The upper basket can be pulled out and removed as shown in the figure. Description of control buttons and indication lights Led Display Control buttons 11) Pre-wash cancel selection Indication of delayed start On/Off 12) Drying selection Indication of half load Programme selection 13) Start/Stop/Pause programme...
- Page 13 Options (Note: the various options must be selected before initiating the wash cycle) • Delayed start : time delays for the initiation of the wash cycle can be set ranging from 1 to 16 hours. On the display, the delay period that was selected will be shown. The LED display will be blinking during the entire delay period.
-
Page 14: Maintenance
Table of wash programmes Turn on & * Add Detergent Select Prog. Dishes Programme Duration* degree of dirt descriptions Rinse 11’ Pans and dishes until Short cold wash to prevent food residues from the next wash cycle drying up and forming crusts on the dishes Very dirty dishes (except Intensive 70 º... - Page 15 7.2 CLEANING OF FILTERS After each wash the filter group should be checked in order to remove possible dirt residues. Proceed as follows: • remove the external water filter 1. • take out the central filter 2. • take out mobile grid 3. Clean all these components under running water.
-
Page 16: What To Do In Case Of Malfunctions
WHAT TO DO IN CASE OF MALFUNCTIONS You should first check whether it is possible to rectify some minor problems yourself. Follow these instructions. If you are unable to identify or remove the problem, you should contact the technical client assistance service. - Page 17 The conditions of the guarantee, which applies, to your Baumatic appliance are as follows: All ‘Work’ in relation to the Guarantee must be carried out by Baumatic Ltd or an approved service agent of Baumatic Ltd. Any claims made under the terms of the guarantee must be supported by the original invoice / bill of sale issued at the time of purchase.
