- Page 1 For warranty information including product registration, see our website at www.rolls.com. Also included on the website are application notes and connec- tion diagrams for the PM50s as well as the PM52 and PM351. Schematic MADE IN USA www.rolls.com 02/09...
- Page 2 Rolls Bridge Clip/Jumper Wire explanation OFF - POSITION Rolls utilizes a way of switching with a three pin jumper wire system attached to the P.C.B. It uses an external bridge clip to act as a switch for changing between two preset unit options.
