Frigidaire FRS6LC8F Parts Catalog

Frigidaire FRS6LC8F Parts Catalog

R134a series
Hide thumbs Also See for FRS6LC8F:
Table of Contents

Advertisement

Quick Links

N58L00002.eps N58FFDBGA0.eps N58RFCBBC9.eps N58BAAAAB3.eps
N58SKDCBE1.eps N58TCAAAB3.eps N58CAAAAA10.eps N58XEAAAA1.eps
N58YAAAAA3.eps N58I1151.eps W241689601.eps S241689601.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS6LC8FS3
Series
R134a
Color
stainless
Volts
115
Wiring Diagram
241689601
Owner's Guide
241695101
Market
North America
Energy Guide
241649291
Service Data Sheet 240389631
Publication No.
5995475265
06/09/28
(EN/SERVICE/DCS)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6LC8F
©
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS6LC8F and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS6LC8F

Summary of Contents for Frigidaire FRS6LC8F

  • Page 1 Product No. FRS6LC8FS3 Series R134a Color stainless Volts Wiring Diagram 241689601 Owner's Guide 241695101 Market North America Energy Guide 241649291 Service Data Sheet 240389631 SIDE-BY-SIDE N58L00002.eps N58FFDBGA0.eps N58RFCBBC9.eps N58BAAAAB3.eps REFRIGERATOR N58SKDCBE1.eps N58TCAAAB3.eps N58CAAAAA10.eps N58XEAAAA1.eps N58YAAAAA3.eps N58I1151.eps W241689601.eps S241689601.eps Model No. North &...

  • Page 2: Freezer Door

    Publication No: 5995475265 FRS6LC8FS3 FREEZER DOOR N58FFDBGA0 09/06...
  • Page 3 FRS6LC8FS3 Publication No: 5995475265 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241674806 Gasket-frzr door, black, magnetic 240334201 Bin-door, frzr-upper 240351601 Bin-door 240351701 Bin-door, frzr-dispenser 241545005 Bin-tilt out, tilt-out 241668500 Door-frzr, stainless, complete assy 240581906 Door Stop, black, frzr 240536818 Handle-door, stainless steel, with insert, & set screw 240598402 Screw, 10-32 x 1/2 240328204...

  • Page 4: Refrigerator Door

    Publication No: 5995475265 FRS6LC8FS3 REFRIGERATOR DOOR N58RFCBBC9 09/06...
  • Page 5 FRS6LC8FS3 Publication No: 5995475265 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241674805 Gasket-refr door, black, magnetic 240323002 Bin-door, pseudo, bottom 240326203 Door-dairy 240581905 Door Stop, black, ref 241534541 Door-refr, stainless steel, complete assy 240536818 Handle-door, stainless steel, with insert, & set screw 240598402 Screw, 10-32 x 1/2 240328203...
  • Page 6 Publication No: 5995475265 FRS6LC8FS3 CABINET N58BAAAAB3 09/06...
  • Page 7 FRS6LC8FS3 Publication No: 5995475265 CABINET POS. NO PART NO. DESCRIPTION 240435912 Cover-air duct 240475911 Cover-evap coil, lower 5303208309 Plug-hole, factory test 240505801 Switch, light/lamp 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240402702 Screw-#10-32 x 1/4 flat hd 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special...
  • Page 8 Publication No: 5995475265 FRS6LC8FS3 SHELVES 140A N58SKDCBE1 09/06...
  • Page 9 FRS6LC8FS3 Publication No: 5995475265 SHELVES POS. NO PART NO. DESCRIPTION 241510604 Trim-basket 240350668 Shelf-freezer, glass, lower 240350667 Shelf-freezer, glass, upper 240324101 Shelf-pizza 241552801 Light Bulb 241555401 Light Bulb 240590401 Socket-light 16*# 241537504 Harness-wiring 16A# 241513901 Socket-light 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625, 21 240355203 Shelf-"Spill-Safe", fixed 240350106...
  • Page 10 Publication No: 5995475265 FRS6LC8FS3 CONTROLS N58TCAAAB3 09/06...
  • Page 11 FRS6LC8FS3 Publication No: 5995475265 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241563601 Bushing-motor mtg, (2) 240369702 Motor-evap fan 241517701 Clip, evap fan motor 241555401 Light Bulb 16 # 241513901 Socket-light 241608801...
  • Page 12 Publication No: 5995475265 FRS6LC8FS3 SYSTEM N58CAAAAA10 09/06...
  • Page 13 FRS6LC8FS3 Publication No: 5995475265 SYSTEM POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241586801 Harness-wiring, machine compt 241651601 Harness-wiring 6* # 241737801 Harness-wiring, control box 14 # 240316107 Heater-defrost 15 # 5303918284 Evaporator Kit 5308000110 Strap-evap/heater, aluminum, (2)

  • Page 14: Ice And Water Dispenser

    Publication No: 5995475265 FRS6LC8FS3 ICE & WATER DISPENSER N58XEAAAA1 09/06...
  • Page 15 FRS6LC8FS3 Publication No: 5995475265 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976901 Tube, water inlet, valve to IM 218976903 Tube-water inlet, inlet valve, to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 241678703 Cover-module, black 241680503...

  • Page 16: Ice Container

    Publication No: 5995475265 FRS6LC8FS3 ICE CONTAINER 37A 34 34 33 N58YAAAAA3 09/06...
  • Page 17 FRS6LC8FS3 Publication No: 5995475265 ICE CONTAINER POS. NO PART NO. DESCRIPTION 241716101 Auger-ice 241685201 Cam-drive 241734001 Container-ice, bucket only 241685101 Drum-ice disp 241735301 Front-ice container 241624801 Bar-drive 241685301 Gate 241555401 Light Bulb 241559801 Socket-light 241684501 Drive Blade 18 # 241676202 Motor-auger, 115V 18*# 240352601...

  • Page 18: Ice Maker

    Publication No: 5995475265 FRS6LC8FS3 ICE MAKER 09/06...
  • Page 19 FRS6LC8FS3 Publication No: 5995475265 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube-water-DOOR 218976901 Tube, water inlet, valve to IM 218976903 Tube-water inlet, inlet valve, to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 5304456650 Spring-shutoff arm, ICE MAKER 5304456657...
  • Page 20 Publication No: 5995475265 FRS6LC8FS3 ICE MAKER 09/06...
  • Page 21 FRS6LC8FS3 Publication No: 5995475265 ICE MAKER POS. NO PART NO. DESCRIPTION 5303207328 Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 Bracket-leveling, ICE MAKER 5304456687 Screw-IM brkt mtg, special, 8-32D x 0.375 5303001549 Clamp, 0.31 ID, steel, copper wtr line 218888001 Adapter, water line, w/fittings 240352102...

  • Page 22: Wiring Schematic

    Publication No: 5995475265 FRS6LC8FS3 WIRING SCHEMATIC ( L I N E ) ( N E U T R A L ) D A M P E R M O T O R E V A P . F A N D E F R O S T C O I L H E A T E R T H E R M .

  • Page 23: Wiring Diagram

    FRS6LC8FS3 Publication No: 5995475265 WIRING DIAGRAM L T . B L U Y E L / R E D D I O D E D I O D E S E E C O M P R E S S O R W I R I N G G R N / Y E L P U R P L E...
