Frigidaire FRS6LC8F Parts Catalog

Frigidaire FRS6LC8F Parts Catalog

134a series
Hide thumbs Also See for FRS6LC8F:
Table of Contents

Advertisement

Quick Links

Download this manual
N58L00002.eps N58FFDBGA0.eps N58RFCBBC9.eps N58BAAAAB3.eps
N58SKDCBE1.eps N58TCAAAB3.eps N58CAAAAA10.eps N58XEAAAA1.eps
N58YAAAAA4.eps N58I1151.eps W241689601.eps S241689601.eps
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS6LC8FS5
Series
134A
Color
stain/blk
Volts
115
Wiring Diagram
241689601
Owner's Guide
241692101
Market
North America
Energy Guide
241649291
Service Data Sheet 240389627
Publication No.
5995484192
07/02/13
(EN/SERVICE/)
137
Copyright
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6LC8F
©
All rights reserved.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS6LC8F and is the answer not in the manual?

Questions and answers

Related Manuals for Frigidaire FRS6LC8F

Summary of Contents for Frigidaire FRS6LC8F

  • Page 1 Product No. FRS6LC8FS5 Series 134A Color stain/blk Volts Wiring Diagram 241689601 Owner's Guide 241692101 Market North America Energy Guide 241649291 Service Data Sheet 240389627 SIDE-BY-SIDE N58L00002.eps N58FFDBGA0.eps N58RFCBBC9.eps N58BAAAAB3.eps REFRIGERATOR N58SKDCBE1.eps N58TCAAAB3.eps N58CAAAAA10.eps N58XEAAAA1.eps N58YAAAAA4.eps N58I1151.eps W241689601.eps S241689601.eps Model No. North &...

  • Page 2: Freezer Door

    Publication No: 5995484192 FRS6LC8FS5 FREEZER DOOR N58FFDBGA0 02/07...
  • Page 3 FRS6LC8FS5 Publication No: 5995484192 FREEZER DOOR POS. NO PART NO. DESCRIPTION 241674806 Gasket-frzr door, black, magnetic 240334201 Bin-door, frzr-upper 240351601 Bin-door 240351701 Bin-door, frzr-dispenser 241545005 Bin-tilt out, tilt-out 241668500 Door-frzr, stainless, complete assy 240581906 Door Stop, black, frzr 240536818 Handle-door, stainless steel, with insert, & set screw 240598402 Screw, 10-32 x 1/2 240328204...

  • Page 4: Refrigerator Door

    Publication No: 5995484192 FRS6LC8FS5 REFRIGERATOR DOOR N58RFCBBC9 02/07...
  • Page 5 FRS6LC8FS5 Publication No: 5995484192 REFRIGERATOR DOOR POS. NO PART NO. DESCRIPTION 241674805 Gasket-refr door, black, magnetic 240323002 Bin-door, pseudo, bottom 240326203 Door-dairy 240581905 Door Stop, black, ref 241534541 Door-refr, stainless steel, complete assy 240536818 Handle-door, stainless steel, with insert, & set screw 240598402 Screw, 10-32 x 1/2 240328203...
  • Page 6 Publication No: 5995484192 FRS6LC8FS5 CABINET N58BAAAAB3 02/07...
  • Page 7 FRS6LC8FS5 Publication No: 5995484192 CABINET POS. NO PART NO. DESCRIPTION 240435912 Cover-air duct 240475911 Cover-evap coil, lower 5303208309 Plug-hole, factory test 240505801 Switch, light/lamp 241547901 Switch-light/lamp, frzr door 218252201 Screw, #8 truss hd, 10-32CA x 0.500 240457702 Plate-door closer 240402702 Screw-#10-32 x 1/4 flat hd 240335502 Bolt-roller adj, hex washer head, 1/4-20 x 4.020, (2), special...
  • Page 8 Publication No: 5995484192 FRS6LC8FS5 SHELVES 140A N58SKDCBE1 02/07...
  • Page 9 FRS6LC8FS5 Publication No: 5995484192 SHELVES POS. NO PART NO. DESCRIPTION 241510604 Trim-basket 240350668 Shelf-freezer, glass, lower 240350667 Shelf-freezer, glass, upper 240324101 Shelf-pizza 241552801 Light Bulb 241555401 Light Bulb 240590401 Socket-light 16*# 241537504 Harness-wiring 16A# 241513901 Socket-light 5304455658 Screw, hx wshr hd sems, 8-15A x 0.625, 21 240355203 Shelf-"Spill-Safe", fixed 240350106...
  • Page 10 Publication No: 5995484192 FRS6LC8FS5 CONTROLS N58TCAAAB3 02/07...
  • Page 11 FRS6LC8FS5 Publication No: 5995484192 CONTROLS POS. NO PART NO. DESCRIPTION 5308000010 Fan Blade, red, evaporator fan 215474201 Washer, "slinger", nylon, evap fan shaft 241563601 Bushing-motor mtg, (2) 240369702 Motor-evap fan 241517701 Clip, evap fan motor 241555401 Light Bulb 16 # 241513901 Socket-light 241608801...
  • Page 12 Publication No: 5995484192 FRS6LC8FS5 SYSTEM N58CAAAAA10 02/07...
  • Page 13 FRS6LC8FS5 Publication No: 5995484192 SYSTEM POS. NO PART NO. DESCRIPTION 240333603 Condenser 218679607 Block-evap coil, styrofoam, (2) 218944001 Drier-filter, R134a System 241586801 Harness-wiring, machine compt 6* # 241651601 Harness-wiring 241663601 Harness-wiring, control box 14 # 240316107 Heater-defrost 15 # 5303918284 Evaporator Kit 5308000110 Strap-evap/heater, aluminum, (2)

  • Page 14: Ice And Water Dispenser

    Publication No: 5995484192 FRS6LC8FS5 ICE & WATER DISPENSER N58XEAAAA1 02/07...
  • Page 15 FRS6LC8FS5 Publication No: 5995484192 ICE & WATER DISPENSER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976901 Tube, water inlet, valve to IM 218976903 Tube-water inlet, inlet valve, to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 241678703 Cover-module, black 241680503...

  • Page 16: Ice Container

    Publication No: 5995484192 FRS6LC8FS5 ICE CONTAINER 37A 34 34 33 N58YAAAAA4 02/07...
  • Page 17 FRS6LC8FS5 Publication No: 5995484192 ICE CONTAINER POS. NO PART NO. DESCRIPTION 241716101 Auger-ice 241685201 Cam-drive 241734001 Container-ice, bucket only 241685101 Drum-ice disp 241735301 Front-ice container 241726501 Bar-drive 241685301 Gate 241555401 Light Bulb 16 # 241559801 Socket-light 241684501 Drive Blade 18 # 241676202 Motor-auger, 115V 240352602...

  • Page 18: Ice Maker

    Publication No: 5995484192 FRS6LC8FS5 ICE MAKER 02/07...
  • Page 19 FRS6LC8FS5 Publication No: 5995484192 ICE MAKER POS. NO PART NO. DESCRIPTION 218976409 Tube, water, door 218976901 Tube, water inlet, valve to IM 218976903 Tube-water inlet, inlet valve, to filter 218976907 Tube-water inlet, valve to door 240561701 Seal-water inlet, inlet valve, to ice maker 5304456650 Spring-shutoff arm, ICE MAKER 5304456657...
  • Page 20 Publication No: 5995484192 FRS6LC8FS5 ICE MAKER 02/07...
  • Page 21 FRS6LC8FS5 Publication No: 5995484192 ICE MAKER POS. NO PART NO. DESCRIPTION 5303207328 Screw, hex washer head, 8-15A x 1.000, (2) 5304456686 Bracket-leveling, ICE MAKER 5304456687 Screw-IM brkt mtg, special, 8-32D x 0.375 5303001549 Clamp, 0.31 ID, steel, copper wtr line 218888001 Adapter, water line, w/fittings 240352102...

  • Page 22: Wiring Schematic

    Publication No: 5995484192 FRS6LC8FS5 WIRING SCHEMATIC ( L I N E ) ( N E U T R A L ) D A M P E R M O T O R E V A P . F A N D E F R O S T C O I L H E A T E R T H E R M .

  • Page 23: Wiring Diagram

    FRS6LC8FS5 Publication No: 5995484192 WIRING DIAGRAM L T . B L U Y E L / R E D D I O D E D I O D E S E E C O M P R E S S O R W I R I N G G R N / Y E L P U R P L E...
