N58L00001.eps N58FCCBBC5.eps N58RCCBBB17.eps N58BAAAAB1.eps
N58SKBCBD12.eps N58TAAAAB4.eps N58CAAAAC10.eps N58XBAAAB1.eps
N58YAAAAA4.eps N58I1151-1.eps W241970401.eps S241970401.eps
P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS6LF7JB2 FRS6LF7JM2 FRS6LF7JS2 FRS6LF7JW2
Series
R134a
Color
black
Volts
115
Wiring Diagram
241970401
Owner's Guide
241856000
Market
North America North America North America North America
Energy Guide
241868019
Service Data Sheet 240389636
Publication No.
5995521613
08/08/14
(EN/SERVICE/DCS)
R134a
R134a
R134a
silver mist
stainless
white
115
115
115
241970401
241970401
241970401
241856000
241856000
241856000
241868019
241868019
241868019
240389636
240389636
240389636
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6LF7J
137
©
Copyright
All rights reserved.
Advertisement
Table of Contents
Related Manuals for Frigidaire FRS6LF7J
Summary of Contents for Frigidaire FRS6LF7J
- Page 1 Product No. FRS6LF7JB2 FRS6LF7JM2 FRS6LF7JS2 FRS6LF7JW2 Series R134a R134a R134a R134a Color black silver mist stainless white Volts Wiring Diagram 241970401 241970401 241970401 241970401 Owner's Guide 241856000 241856000 241856000 241856000 Market North America North America North America North America Energy Guide 241868019 241868019 241868019...
-
Page 2: Freezer Door
Publication No: 5995521613 FRS6LF7J FREEZER DOOR Stainless Handle N58FCCBBC5 08/08... - Page 3 FRS6LF7J Publication No: 5995521613 FREEZER DOOR Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 241786006 A B C - Gasket-frzr door, black, magnetic 241786002 - - - D Gasket-frzr door, white, magnetic 240334201 A B C D Bin-door, frzr-upper...
-
Page 4: Refrigerator Door
Publication No: 5995521613 FRS6LF7J REFRIGERATOR DOOR Stainless Handle N58RCCBBB17 08/08... - Page 5 FRS6LF7J Publication No: 5995521613 REFRIGERATOR DOOR Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 241786005 A B C - Gasket-refr door, black, magnetic 241786001 - - - D Gasket-refr door, white, magnetic 240323002 A B C D Bin-door, pseudo, bottom...
- Page 6 Publication No: 5995521613 FRS6LF7J CABINET N58BAAAAB1 08/08...
- Page 7 FRS6LF7J Publication No: 5995521613 CABINET Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 240435912 A B C D Cover-air duct 241719711 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 240505801...
- Page 8 Publication No: 5995521613 FRS6LF7J SHELVES N58SKBCBD12 08/08...
- Page 9 FRS6LF7J Publication No: 5995521613 SHELVES Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 241510604 A B C D Trim-basket 241657602 A B C D Shelf, flip up, wire 241657504 A B C D Shelf, fixed, upper, freezer 240324101...
- Page 10 Publication No: 5995521613 FRS6LF7J CONTROLS 08/08...
- Page 11 FRS6LF7J Publication No: 5995521613 CONTROLS Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 215474201 A B C D Washer, "slinger", nylon, evap fan shaft 241563601 A B C D Bushing-motor mtg, (2)
- Page 12 Publication No: 5995521613 FRS6LF7J SYSTEM N58CAAAAC10 08/08...
- Page 13 FRS6LF7J Publication No: 5995521613 SYSTEM Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 240333603 A B C D Condenser 218679607 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 241586801...
-
Page 14: Ice And Water Dispenser
Publication No: 5995521613 FRS6LF7J ICE & WATER DISPENSER N58XBAAAB1 08/08... - Page 15 FRS6LF7J Publication No: 5995521613 ICE & WATER DISPENSER Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube, water, door 218976418 A B C D Tube-water inlet, inlet valve, to filter 218976419 A B C D...
-
Page 16: Ice Container
Publication No: 5995521613 FRS6LF7J ICE CONTAINER 37A 34 34 33 N58YAAAAA4 08/08... - Page 17 FRS6LF7J Publication No: 5995521613 ICE CONTAINER Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 241716101 A B C D Auger-ice 241685201 A B C D Cam-drive 241734001 A B C D Container-ice, bucket only 241685101 A B C D...
-
Page 18: Ice Maker
Publication No: 5995521613 FRS6LF7J ICE MAKER L O C L O C A R M A R M K E D K E D U N T U N T I N T I N T L A C L A C INSTALLATION PARTS N58I1151-1 08/08... - Page 19 FRS6LF7J Publication No: 5995521613 ICE MAKER Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube, water, door 218976418 A B C D Tube-water inlet, inlet valve, to filter 218976419 A B C D Tube-water inlet, valve to door...
- Page 20 Publication No: 5995521613 FRS6LF7J ICE MAKER L O C L O C A R M A R M K E D K E D U N T U N T I N T I N T L A C L A C INSTALLATION PARTS N58I1151-1 08/08...
- Page 21 FRS6LF7J Publication No: 5995521613 ICE MAKER Model Index: A FRS6LF7J (FRS6LF7JB2) B FRS6LF7J (FRS6LF7JM2) C FRS6LF7J (FRS6LF7JS2) D FRS6LF7J (FRS6LF7JW2) POS. NO PART NO. DESCRIPTION 218709101 A B C D Screw, hex head, 10-32 x 0.500 240363602 A B C D Screw-shoulder 240542901 A B C D...
-
Page 22: Wiring Schematic
Publication No: 5995521613 FRS6LF7J WIRING SCHEMATIC 08/08... -
Page 23: Wiring Diagram
FRS6LF7J Publication No: 5995521613 WIRING DIAGRAM 08/08 # Functional Parts * Non-Illustrated Parts...
