Electrolux EWMGD70J IW Specifications

27" gas front load dryers
Hide thumbs

Advertisement

Gas Front Load Dryers
EWMGD70J RR / MB / TS / SS / IW
®
Wave-Touch
Electronic Controls Featuring Perfect Steam™
Turquoise Sky
EWMGD70J TS
Largest Capacity Dryer
Dry the most in one load with
8.0 cu. ft. capacity.
Fastest Dry Time
Fourteen minutes to dry.
Specialty Cycles
A cycle for virtually anything including pet beds,
stuffed animals, workout gear and more.
Perfect Steam
The latest technology removes wrinkles and
freshens clothes. "Add Steam" option can be
used with select cycles.
1
Based on manufacturer specifications.
2
Fastest time based on smallest load / Fast Wash and Fast Dry cycles selected for
various load compositions.
Red Hot Red
Mediterranean
Blue
Turquoise Sky
Silver Sands
Island White
Optional Luxury-Glide
®
Touch-2-Open
Pedestals Shown in
Available Colors.
1
2
Dryer
27" GAS FRONT LOAD DRYERS
Capacity IEC
Features
Signature Soft-Arc Door Design
Wave-Touch
®
Electronic Controls with LCD Display
Perfect Steam
Dry System
Perfect Tumble
Dry System
Luxury-Quiet
Sound System
Luxury-Design
®
Lighting
Luxury-Dry
System
Touch-2-Open
/ (Close) Door
Exact Dry
Moisture Sensor
Stainless Steel Dryer Drum
Tumble Speed (RPM)
Reversible Door
Adjustable Leveling Legs
NSF
®
Certified
Cycles
Fast Dry, My Favorites (3), Heavy Duty* , Bulky / Bedding* ,
Mixed Load* , Towels, Normal* , Active Wear* , Casual* , Delicate* ,
Perfect Steam
* , Timed Dry
(*Can be used with Add Steam option)
Specialty Cycles –
Jeans, Warm Up, Stuffed Animals* , Pet Beds, Fast Steam,
Comforter, Kids Wear, Air Clean, Wool
(*Can be used with Add Steam option)
Individual Custom Options (3) –
Additional user settings, each with 11 cycles, 9 Specialty
and 3 My Favorites (23)
Total Cycles Available
Options
Temperature Selections
Add Steam
Electronic Auto Dry System
Manual Timed Dry Selections
Delay Start (Hours)
End-of-Cycle Chime
Eco-Friendly
Anti-Static
Line Dry
Installation Options
Freestanding, Under Counter*,
Stacked (Above Washer), Pedestal, Hidden (In Closet),
Second Floor, 4-Way Dryer Venting
Accessories
Luxury-Glide
®
Touch-2-Open
/ (Close) Pedestal –
See Back for Part Numbers
Dryer Stacking Kit – PN # ESTACKIT
LP Gas Conversion Kit – PN # PCK4300
Mobile Home Installation Kit – PN # 137067200
Drying Rack – PN # 134912700
Specifications
Color –
Red Hot Red
Mediterranean Blue
Turquoise Sky
Silver Sands
Island White
Product Dimensions –
Height (Without 15" Pedestal)
(With 15" Pedestal)
Width
Depth (to Center of Arc Including Door and Exhaust)
(with 90° Door Open)
Gas / Power Supply Connection Location
Voltage Rating
Connected Load (kW Rating) @ 120 Volts
Amps @ 120 Volts
Heating Element (BTU / HR)
Shipping Weight (Approx.)
*Side-by-Side units in under-counter installation require custom-built countertop and/or cabinetry.
For use on adequately wired 120V, dedicated circuit having 2-wire service with a separate
ground wire. Appliance must be grounded for safe operation.
NOTE: Always consult local and national electric, gas & plumbing codes. Refer to Product
Installation Guide for detailed installation instructions on the web at www.electroluxappliances.com.
Specifications subject to change.
8.0 Cu. Ft.
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
50
Yes
Yes
Sanitize
14
9
69
92
7
9
Yes
6
22
Adjustable
Yes
Yes
Yes
Yes
Optional
Optional
Optional
Optional
Included
RR
MB
TS
SS
IW
38"
53"
27"
31-1/2"
50-5/8"
Bottom Center Rear /
Bottom Right Rear
120V / 60 Hz / 15A
1.1
9
22,000
140 Lbs.
electroluxappliances.com
