Frigidaire FRS26H5AS Factory Parts Catalog

Frigidaire FRS26H5AS Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26H5AS:
Table of Contents

Advertisement

Quick Links

PRODUCT NO.
BASE MODEL NO.
FRS26H5ASB5
FRS26H5AS
MARKET
North America
WIRING DIAGRAM - 240389607
OWNER'S GUIDE - 240389306
SERVICE DATA SHEET - 240389607
ELECTROLUX HOME PRODUCTS, INC
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
stain/black
Publication No.
5995384327
030120
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26H5AS
©2003 Electrolux Home Products, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26H5AS and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS26H5AS

Summary of Contents for Frigidaire FRS26H5AS

  • Page 1 FACTORY PARTS CATALO PRODUCT NO. BASE MODEL NO. SERIES COLOR VOLTS FRS26H5ASB5 FRS26H5AS R134a stain/black MARKET North America WIRING DIAGRAM - 240389607 OWNER’S GUIDE - 240389306 SERVICE DATA SHEET - 240389607 SIDE BY SIDE REFRIGERATOR ELECTROLUX HOME PRODUCTS, INC Model No. P.O.

  • Page 2: Freezer Door

    Publication No. FRS26H5ASB5 5995384327 FREEZER DOOR 01/03...
  • Page 3 FRS26H5ASB5 Publication No. 5995384327 FREEZER DOOR POS. NO PART NO DESCRIPTION 240390606 Gasket-frzr door,black ,magnetic 240334201 Bin-door,frzr-upper 240351601 Bin-door 240451874 Door-frzr, stainless steel, complete assy 240537106 Door Stop, black, frzr 240359108 Handle-door, black, LH 218781100 Screw, pan head, 8-18 x 0.625 5308016566 Screw, hex washer head, 8-15A x 0.625, low profile 240521302...

  • Page 4: Refrigerator Door

    Publication No. FRS26H5ASB5 5995384327 REFRIGERATOR DOOR 01/03...
  • Page 5 FRS26H5ASB5 Publication No. 5995384327 REFRIGERATOR DOOR POS. NO PART NO DESCRIPTION 240390605 Gasket-refr door,black ,magnetic 240323001 Bin-door,pseudo ,bottom 240326203 Door-dairy 240537105 Door Stop,black ,ref 240451942 Door-refr, stainless steel, complete assy 240359103 Handle-door,black ,RH 218781100 Screw,pan head ,8-18 x 0.625 5308016566 Screw,hex wshr hd, 8-15A x 0.625, low profile 240521302 Screw,#8-18 x 3/4...
  • Page 6 Publication No. FRS26H5ASB5 5995384327 CABINET 01/03...
  • Page 7 FRS26H5ASB5 Publication No. 5995384327 CABINET POS. NO PART NO DESCRIPTION 240435902 Cover-air duct 240475902 Cover-evap coil,lower 5303208309 Plug-hole,factory test 14 # 240505801 Switch,light/lamp 14A# 215486600 Switch-light/lamp 218252200 Screw,#8 truss hd ,10-32CA x 0.500 240457701 Plate-door closer 240402701 Screw-#10-32 x 1/4 flat hd 240335501 Bolt-roller adj,hex wshr hd, 1/4-20 x 4.020, (2), special 240419103...
  • Page 8 Publication No. FRS26H5ASB5 5995384327 SHELVES 01/03...
  • Page 9 FRS26H5ASB5 Publication No. 5995384327 SHELVES POS. NO PART NO DESCRIPTION 240434604 Trim-basket 240338802 Shelf-freezer,flip-up 240338704 Shelf-freezer,fixed wire 240324101 Shelf-pizza 240355207 Shelf-"Spill-Safe",cantilever, half width,fixed 240350108 Shelf-"Spill-Safe",cantilever ,sliding 240350702 Cover-crisper pan,upper 240362101 Clip-slide,cover-crisper 240350902 Cover-crisper pan,lower 240351005 Pan-crisper,upper 240349801 Clip-slide,pan-crisper 240362201 Control-humidity 240351205 Pan-crisper,lower 240430706...
  • Page 10 Publication No. FRS26H5ASB5 5995384327 CONTROLS 01/03...
  • Page 11 FRS26H5ASB5 Publication No. 5995384327 CONTROLS POS. NO PART NO DESCRIPTION 5308000010 Fan Blade,red ,evaporator fan 5300157666 Bushing-motor mtg,(2) 5303292396 Bracket-motor mtg,front 13 # 240315802 Motor-evap fan 215474201 Washer,"slinger" ,nylon ,evap fan shaft 5303292397 Bracket-motor mtg,rear 240436702 Light Bulb/Lamp, A-15, clear, 40 W, 120 V, miniature 218906801 Socket-light/lamp 240317701...
  • Page 12 Publication No. FRS26H5ASB5 5995384327 SYSTEM 01/03...
  • Page 13 FRS26H5ASB5 Publication No. 5995384327 SYSTEM POS. NO PART NO DESCRIPTION 240333603 Condenser 218679607 Block-evap coil,styrofoam ,(2) 218944001 Drier-filter,R134a System 240346402 Harness-wiring,machine compt 240449601 Harness-wiring 240439902 Harness-wiring,control box 14 # 5303918253 Defrost Heater Kit 15 # 5303918284 Evaporator Kit 5308000110 Strap-evap/heater,aluminum ,(2) 5303918214 Thermostat-defrost,kit 240330003...
  • Page 14 Publication No. FRS26H5ASB5 5995384327 DISPENSER 01/03...
  • Page 15 FRS26H5ASB5 Publication No. 5995384327 DISPENSER POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 5304422012 Cover-module,black 5304422013 Module-dispenser 5304421626 Spring-torsion 240323910 Label-module cover,black 5304421616 Light Bulb...

  • Page 16: Ice Container

    Publication No. FRS26H5ASB5 5995384327 ICE CONTAINER 01/03...
  • Page 17 FRS26H5ASB5 Publication No. 5995384327 ICE CONTAINER POS. NO PART NO DESCRIPTION 5304428402 Auger-ice 5304404343 Cam-drive 218815300 Container-ice,bucket only 5304404346 Drum-ice disp 218815400 Front-ice container 5304404337 Bar-drive 5304404359 Gate 5303001179 Light Bulb/Lamp,40 W 5303289050 Socket-light/lamp 5304404345 Drive Blade 18 # 240326903 Motor-auger 5304404335 Wiring Harness,auger motor...

  • Page 18: Ice Maker

    Publication No. FRS26H5ASB5 5995384327 ICE MAKER 01/03...
  • Page 19 FRS26H5ASB5 Publication No. 5995384327 ICE MAKER POS. NO PART NO DESCRIPTION 218976409 Tube-water 218976901 Tube-water inlet, inlet valve to ice maker 218976903 Tube-water inlet, inlet valve to filter 218976907 Tube-water inlet, valve to door 5304420650 Spring,shut-off arm 3206299 Label,ID plate 3206301 Gear 3206303...

  • Page 20: Wiring Schematic

    Publication No. FRS26H5ASB5 5995384327 WIRING SCHEMATIC 01/03...

  • Page 21: Wiring Diagram

    FRS26H5ASB5 Publication No. 5995384327 WIRING DIAGRAM # = Fast-moving Parts 01/03 * = Non-Illustrated Parts...
