PRODUCT NO.
BASE MODEL NO.
FRS26HR4AB0
FRS26HR4A
FRS26HR4AB1
FRS26HR4A
FRS26HR4AQ0
FRS26HR4A
FRS26HR4AQ1
FRS26HR4A
FRS26HR4AW0
FRS26HR4A
FRS26HR4AW1
FRS26HR4A
MARKET
North American
WIRING DIAGRAM - 240389604
OWNER'S GUIDE - 0 = 240389302 & 1 = 240389303
SERVICE DATA SHEET - 240389604
ELECTROLUX HOME PRODUCTS NORTH AMERICA
P.O. BOX 212378, Augusta, GA 30917
SERIES
COLOR
R134a
black
R134a
black
R134a
bisque
R134a
bisque
R134a
white
R134a
white
Publication No.
5995360897
011112
-EN/SERVICE/KHB
357
PARTS CATALO
VOLTS
115
115
115
115
115
115
SIDE BY SIDE
REFRIGERATOR
Model No.
FRS26HR4A
©2001 White Consolidated Industries, Inc.
All rights reserved
FACTORY
G

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FRS26HR4A and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Frigidaire FRS26HR4A

Summary of Contents for Frigidaire FRS26HR4A

  • Page 1 PRODUCT NO. BASE MODEL NO. FRS26HR4AB0 FRS26HR4A FRS26HR4AB1 FRS26HR4A FRS26HR4AQ0 FRS26HR4A FRS26HR4AQ1 FRS26HR4A FRS26HR4AW0 FRS26HR4A FRS26HR4AW1 FRS26HR4A MARKET North American WIRING DIAGRAM - 240389604 OWNER’S GUIDE - 0 = 240389302 & 1 = 240389303 SERVICE DATA SHEET - 240389604 ELECTROLUX HOME PRODUCTS NORTH AMERICA P.O.

  • Page 2: Freezer Door

    Publication No. FRS26HR4A 5995360897 FREEZER DOOR 11/01...
  • Page 3 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 240390606 240390602 240334201 240351601 240451815 240451807 240451801 240456906 240456904 240456902 218762703 218762706 218762701 5308016566...

  • Page 4: Refrigerator Door

    Publication No. FRS26HR4A 5995360897 REFRIGERATOR DOOR 11/01...
  • Page 5 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 240390605 240390601 240323001 240326203 240456905 240456903 240456901 240451930 240451905 240451901 218762703 218762706 218762701 5308016566...
  • Page 6 Publication No. FRS26HR4A 5995360897 CABINET 11/01...
  • Page 7 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 240435902 240475902 5303208309 14 # 240413601 14A# 215486600 218252200 240457701 240402701 240335501 240419103 240419104...
  • Page 8 Publication No. FRS26HR4A 5995360897 SHELVES 11/01...
  • Page 9 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 5308016566 # = Fast-moving Parts * = Non-Illustrated Parts FRS26HR4A SHELVES PART NO 240434602...
  • Page 10 Publication No. FRS26HR4A 5995360897 CONTROLS 11/01...
  • Page 11 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 5308000010 5300157666 5303292396 13 # 5303292397 21 # 5304421768 23 # 5303001259 5308000039 5303209814...
  • Page 12 Publication No. FRS26HR4A 5995360897 SYSTEM 11/01...
  • Page 13 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 6* # 14 # 15 # 29 # 30 # 55 # 60 #...
  • Page 14 Publication No. FRS26HR4A 5995360897 DISPENSER 11/01...
  • Page 15 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 218976405 218976901 218976904 218976907 5304422012 5304421848 5304421822 5304422013 5304421849 5304422030 5304421626 240323910 240323905 240323904...

  • Page 16: Ice Container

    Publication No. FRS26HR4A 5995360897 ICE CONTAINER 11/01...
  • Page 17 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 5304404344 5304404343 218815300 5304404346 218815400 5304404337 5304404359 5303001179 5303289050 5304404345 18 # 240326903 5304404335...

  • Page 18: Ice Maker

    Publication No. FRS26HR4A 5995360897 ICE MAKER 11/01...
  • Page 19 A = FRS26HR4A (FRS26HR4AB0) B = FRS26HR4A (FRS26HR4AB1) C = FRS26HR4A (FRS26HR4AQ0) D = FRS26HR4A (FRS26HR4AQ1) E = FRS26HR4A (FRS26HR4AW0) F = FRS26HR4A (FRS26HR4AW1) POS. NO 218976405 218976901 218976904 218976907 5304420650 11 # 12 # 240352601 13 # 5304420652 15 #...

  • Page 20: Wiring Schematic

    Publication No. FRS26HR4A 5995360897 WIRING SCHEMATIC 11/01...

  • Page 21: Wiring Diagram

    FRS26HR4A Publication No. 5995360897 WIRING DIAGRAM # = Fast-moving Parts 11/01 * = Non-Illustrated Parts...
