Frigidaire FRS26HR4D Factory Parts Catalog
  1. Manuals
  2. Brands
  3. Frigidaire Manuals
  4. Refrigerator
  5. FRS26HR4D
  6. Factory parts catalog
Frigidaire FRS26HR4D Factory Parts Catalog

Frigidaire FRS26HR4D Factory Parts Catalog

Side by side refrigerator
Hide thumbs Also See for FRS26HR4D:
Table of Contents

Advertisement

Quick Links

Download this manual
Product No.
Series
Color
Volts
Wiring Diagram
Owner's Guide
Market
Energy Guide
Service Data Sheet 240389616
N58L00001.eps N58FACBBB4.eps N58RACBBB6.eps N58BAAAAA0.eps
N58SJCAAB1.eps N58TAAAAA6.eps N58CAAAAC1.eps N58XDAAAA1.eps
N58YBAAAA1.eps N58I115.eps W241526901A.eps S241526901A.eps
u
x Major Appliances
North & Latin America
P.O. BOX 212378
AUGUSTA, GA 30917
FRS26HR4DB9 FRS26HR4DQ7 FRS26HR4DQ9 FRS26HR4DW7 FRS26HR4DW9
R134a Gallery
R134a Gallery
R134a Gallery
black
bisque
bisque
115
115
115
241526901
241526901
241526901
241661500
241661500
241661500
North America
North America
North America
241538730
241538730
241538730
240389616
240389616
Publication No.
5995447561
05/09/08
(EN/SERVICE/WC)
357
R134a Gallery
R134a Gallery
white
white
115
115
241526901
241526901
241661500
241661500
North America
North America
241538730
241538730
240389616
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS26HR4D
©
Copyright
2005 Home Pr
All rights reserved.
oducts, Inc.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS26HR4D

Summary of Contents for Frigidaire FRS26HR4D

  • Page 1 Product No. FRS26HR4DB9 FRS26HR4DQ7 FRS26HR4DQ9 FRS26HR4DW7 FRS26HR4DW9 Series R134a Gallery R134a Gallery R134a Gallery R134a Gallery R134a Gallery Color black bisque bisque white white Volts Wiring Diagram 241526901 241526901 241526901 241526901 241526901 Owner's Guide 241661500 241661500 241661500 241661500 241661500 Market North America North America North America...

  • Page 2: Freezer Door

    Publication No: 5995447561 FRS26HR4D FREEZER DOOR 09/05...
  • Page 3 FRS26HR4D Publication No: 5995447561 FREEZER DOOR Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 241569806 A - - - - Gasket-frzr door, black, magnetic 241569802 - B C D E Gasket-frzr door, white, magnetic 240334201 A B C D E...

  • Page 4: Refrigerator Door

    Publication No: 5995447561 FRS26HR4D REFRIGERATOR DOOR 09/05...
  • Page 5 FRS26HR4D Publication No: 5995447561 REFRIGERATOR DOOR Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 241569805 A - - - - Gasket-refr door, black, magnetic 241569801 - B C D E Gasket-refr door, white, magnetic 240323001 A B C D E...
  • Page 6 Publication No: 5995447561 FRS26HR4D CABINET 09/05...
  • Page 7 FRS26HR4D Publication No: 5995447561 CABINET Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 240435906 A B C D E Cover-air duct 240475907 A B C D E Cover-evap coil, lower 5303208309 A B C D E...
  • Page 8 Publication No: 5995447561 FRS26HR4D SHELVES 09/05...
  • Page 9 FRS26HR4D Publication No: 5995447561 SHELVES Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 241657602 A B C D E Shelf, flip up, wire 241657502 A B C D E Shelf, fixed, freezer 241657504 A B C D E...
  • Page 10 Publication No: 5995447561 FRS26HR4D CONTROLS N58TAAAAA6 09/05...
  • Page 11 FRS26HR4D Publication No: 5995447561 CONTROLS Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 5308000010 A B C D E Fan Blade, red, evaporator fan 215474201 A B C D E Washer, "slinger", nylon, evap fan shaft 241563601 A B C D E...
  • Page 12 Publication No: 5995447561 FRS26HR4D SYSTEM N58CAAAAC1 09/05...
  • Page 13 FRS26HR4D Publication No: 5995447561 SYSTEM Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 240333603 A B C D E Condenser 218679607 A B C D E Block-evap coil, styrofoam, (2) 218944001 A B C D E...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995447561 FRS26HR4D ICE & WATER DISPENSER 09/05...
  • Page 15 FRS26HR4D Publication No: 5995447561 ICE & WATER DISPENSER Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 218976409 A B C D E Tube-water-DOOR 218976901 A B C D E Tube-water inlet, inlet valve, to ice maker 218976904 A B C D E...

  • Page 16: Ice Container

    Publication No: 5995447561 FRS26HR4D ICE CONTAINER 37A 34 34 33 N58YBAAAA1 09/05...
  • Page 17 FRS26HR4D Publication No: 5995447561 ICE CONTAINER Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 5304428402 A B C D E Auger-ice 5304404343 A B C D E Cam-drive 218815300 A B C D E...

  • Page 18: Ice Maker

    Publication No: 5995447561 FRS26HR4D ICE MAKER 09/05...
  • Page 19 FRS26HR4D Publication No: 5995447561 ICE MAKER Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 218976409 A B C D E Tube-water-DOOR 218976901 A B C D E Tube-water inlet, inlet valve, to ice maker 218976904 A B C D E...
  • Page 20 Publication No: 5995447561 FRS26HR4D ICE MAKER 09/05...
  • Page 21 FRS26HR4D Publication No: 5995447561 ICE MAKER Model Index: A FRS26HR4D (FRS26HR4DB9) B FRS26HR4D (FRS26HR4DQ7) C FRS26HR4D (FRS26HR4DQ9) D FRS26HR4D (FRS26HR4DW7) E FRS26HR4D (FRS26HR4DW9) POS. NO PART NO. DESCRIPTION 240387101 A B C D E Tube-water, ice mold fill, extension 55 # 240531101 A B C D E Valve-water, triple solenoid...

  • Page 22: Wiring Schematic

    Publication No: 5995447561 FRS26HR4D WIRING SCHEMATIC 09/05...

  • Page 23: Wiring Diagram

    FRS26HR4D Publication No: 5995447561 WIRING DIAGRAM 09/05 # Functional Parts * Non-Illustrated Parts...
