Specifications
CONTROL BOARD
BD2-2220/2221
MODEL
Rev. 1.00 Issued on October 10, 2006

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the BD2-2220 and is the answer not in the manual?

Questions and answers

Related Manuals for Citizen BD2-2220

Summary of Contents for Citizen BD2-2220

  • Page 1 Specifications CONTROL BOARD BD2-2220/2221 MODEL Rev. 1.00 Issued on October 10, 2006...
  • Page 2 Revision Rev. Date Comment 1.00 2006.10.10 Newly issued CITIZEN is a registered trade mark of CITIZEN WATCH CO., LTD., Japan. CITIZEN es una marca registrada de CITIZEN WATCH CO., LTD., Japón.

  • Page 3: Table Of Contents

    CONTENTS GENERAL OUTLINE..................1 ........................1 EATURES ......................2 CCESSORIES ....................2 ODEL LASSIFICATION )................3 ONFIGURATION LOCK IAGRAM BASIC SPECIFICATIONS ................4 ..................4 RINTING PECIFICATIONS ..............5 HARACTER AND ARCODE PECIFICATIONS )............6 RINT APER PECIFICATIONS HERMAL APER .................7 ECHANISM AND ERIPHERALS ......................7 OWER UPPLY 2.5.1 Specifications ........................7 2.5.2...
  • Page 4 INTERFACES ....................28 (IEEE1284) ...........28 IDIRECTIONAL ARALLEL NTERFACE 6.1.1 Specification ........................28 6.1.2 Description of Input/Output Signals .................29 6.1.3 Connection to Parallel Port ....................32 RS-232C S ..................33 ERIAL NTERFACE 6.2.1 Specification ........................33 6.2.2 Description of Input/Output Signals .................33 6.2.3 Connection to Serial Port....................36 USB I .....................36 NTERFACE...

  • Page 5: General Outline

    * This specification applies only to control board BD2-2220/2221 * The information contained herein is subject to change without prior notice. * Transfer, copy, reproduction, or alteration of this document is prohibited without permission of Citizen Systems Japan Co., Ltd. Features 1) Ultra-small design 2) High speed (150 mm/sec) printing 3) Applicable to the width of 80 mm (LT232X) and 58 mm (LT222X).

  • Page 6: Accessories

    Accessories After unpacking the product, make sure the following components are present. Control board ... 1 Interface cable ... 1 (A cable of 300 mm long)* Mech FFC ... 1 (With 100-mm-long cable) * Mini-USB cable is not supplied for USB model. Model Classification BD2 ―...

  • Page 7: Configuration (Block Diagram)

    Configuration (Block Diagram) BD2-2220/2221 BLOCK DIAGRAM MECHANISM HEAD Thermistor SENSOR CUTTER CUTTER CUTTER HEAD UP PRINTER STEPPING MOTOR SENSOR HEAD MOTOR DRIVER DRIVER ERROR SDRAM FLASH MEMORY 16Mbit 8Mbit: Foreign 16Mbit: Domestic PE LED DC3.3V DC5.0V DC24.0 V SENSOR FEED POWER SUPPLY DIP SW RESET...

  • Page 8: Basic Specifications

    2. BASIC SPECIFICATIONS Printing Specifications 1) Print method: Line thermal print method (Thermal printing system) 2) Dot configuration: LT222X: 432 dots/line, LT232X:576 dots/line 3) Dot density: 8 dots/mm (203 dpi) 4) Print area: LT222X: Max. 54 mm, LT232X: Max. 72 mm 5) Number of print columns: LT222X: Max.

  • Page 9: Character And Barcode Specifications

    Character and Barcode Specifications 1) Character type ANK characters: 96characters Code pages: 128 characters × 12 pages International characters: 12 characters × 14 countries Japanese Kanji: JIS (JIS C6226-1983) Non-kanji: 577 characters JIS level 1: 2965 characters JIS level 2: 3388 characters (Only when destination is Japan) 2) Character size/configuration Table 1 Character Size...

  • Page 10: Print Paper Specifications (Thermal Paper)

    Print Paper Specifications (Thermal Paper) 1) Paper width : LT222X: 58 +0,-1mm, LT232X: 80 +0,-1mm 2) Paper thickness : 60µｍ ~ 150µｍ 3) Recommended paper Nippon Paper Industries TF50-KS-E2D Mitsubishi Paper P220AC Or equivalent Print density setting should be changed according to the type and thickness of paper. Change the density setting by the Customize value setting GS ( E command.

  • Page 11: Mechanism And Peripherals Used

    Mechanism and Peripherals Used The following mechanism and peripheral units can be connected to this control board. 1) Thermal mechanism 58 mm Paper: LT222X 80 mm Paper: LT232X 2) Auto cutter ACS-220/230 series 3) Paper near-end sensor (Option) * For the details of specification, etc., refer to the relevant manual. Power Supply 2.5.1 Specifications 1) Operating voltage...

  • Page 12: Environment: Temperature, Humidity

    Cautions ・Using the power supply other than specified, bad effect may occur in printing operation, etc. ・Using the current without removing peak current may result in degradation of printing quality depending on the printing status or occurrence of low-voltage error. ・Use the power supply that can be turned off easily to prepare for emergencies.

  • Page 13: Appearance Specifications

    3. APPEARANCE SPECIFICATIONS Weight : Approx. 37g (Only main body) Dimensions Unit: mm * Board size and screw hole position are common to all models.

  • Page 14: Connector Connection

    4. Connector Connection Interface Connectors 4.1.1 Interface Connector Pin Assignment (CN1) Pin assignment Signal Name Input/Output Function Circuit PS (+5V) － Circuit GND － 5-10 Drive PS (+24V) － 11-16 P-GND Drive GND － nFEED-SW Input FEED Switch (Paper feed) ERROR output (directly nERROR Output...

  • Page 15: Usb Interface Connector Pin Assignment (Cn8) * Only Usb Model

    4.1.2 USB Interface Connector Pin Assignment (CN8) * Only USB model Pin assignment Signal Input/Output Function Name VBus(+5V) USB PS － 1 2 3 4 5 -Data(D-) Input/Output USB D- +Data(D+) Input/Output USB D+ Not connectable － USB GND － Series Min B plug * Do not use a cable of longer than 5 m.

  • Page 16: Cn1 Connection Example

    4.1.3 CN1 Connection Example * For each interface connection, refer to each item. AC100~240V 1、2 3、 4 Constant voltage +24V 5~10 P-GND 11~16 10kΩ FEED SW GND for power supply or CN1-3, 4 100Ω 1000pF 330Ω ERROR LED 5V line of PS or CN1-1, 2 PEOUT LED 330Ω...

  • Page 17: Mechanism Connector (Cn2)

    Mechanism Connector (CN2) 4.2.1 Mechanism Connector Pin Assignment (CN2) Pin assignment Signal Name Input/Output Function LT222X LT232X LT222X LT232X LT222X LT232X 1 ~ 4 Thermal head PS Output Clock signal for data transmission Output Print data latch signal STB2 Output Strobe signal 2 STB1 Output...

  • Page 18: Ffc-Compliant Cable

    4.2.2 FFC-compliant Cable 36.25±0.1 33.75±0.1 1.25±0.05 0.8±0.03 0.3±0.05 Conductive side Reinforcing board dimension Min.4 Unit: mm Head Up, Paper-End Detecting Connector (CN3, CN7) Pin assignment Signal Sensor Input/Output Function Name LT2X20 LT2X21 CN3-1 HU-A Output Head Up sensor CN3-2 CN7-1 －...

  • Page 19: Motor Connector (Cn4)

    Motor Connector (CN4) Pin assignment Signal Input/Output Function Name MOTOR A+ Output Motor driving signal A+ MOTOR B- Output Motor driving signal B- MOTOR A- Output Motor driving signal A- MOTOR B+ Output Motor driving signal B+ Connector used: 53047-0410 (Molex) Auto Cutter Connector (CN5) Pin assignment Signal...

  • Page 20: Paper Near-End Sensor Connector (Cn6) * Option

    Paper Near-End Sensor Connector (CN6) * Option 4.6.1 Paper Near-End Sensor Connector Pin Assignment (CN6) Pin assignment Signal Input/Output Function Name PNE-A Output Photo interrupter anode PNE-C Input Photo interrupter collector Photo interrupter cathode, emitter － Connector used: 5267-03A-X (Molex) * At the time of shipment, pins 2 and 3 are short-circuited by JP5 and paper detection is disabled (always paper present is defined).

  • Page 21: Operation Panel

    5. OPERATION PANEL Output LED 1) PE LED : Paper-End detection OFF : Paper Present detection 2) ERROR LED : Head Up (LT2220/2320 is used), Platen Open (LT2221/2321 is used). Paper-End Blinking : Hex dump mode, memory switch setting mode, various errors, waiting for macro execution : Normal operation Details on Error and LED Indication...
  • Page 22 (2) Head Up error (LT2220/2320 is used and MSW3-8 OFF is set.) Explanation: ERROR LED blinks during printing and when Head Up is set (with Head Up lever raised). PE LED: ERROR LED: Blinks with long illumination at ON Restore Condition: Set Head Down (with Head Up lever down). PE LED ERROR LED Blinks with long...
  • Page 23 2) Restorable error (1) Head Up error (LT2220/2320 is used and MSW3-8 ON is set.) Explanation: ERROR LED blinks during printing and with Head Up. PE LED: ERROR LED: Blinks with long illumination at ON Restore Condition: After Head Down, clear the error by a command. * For details of DLE ENQ 1, DLE ENQ 2, and DLE DC4 (fn=8), refer to Command Reference.
  • Page 24 (3) Cutter lock error Explanation: Cutter operation is disabled. Abnormality occurred. PE LED: ERROR LED: ERROR LED repeats blinking 2 times fast and blinking 1 time slow. Restore Condition: Remove the fault and restore by pressing the FEED switch (with MSW3-1 set to OFF) or by DLE EMQ 1 or 2 command (with MSW3-1 set to ON).
  • Page 25 (2) Low voltage error Explanation: Occurs when the Vp voltage supplied to the printer is lowered. If occurred, immediately turn the power OFF. PE LED: ERROR LED: ERROR LED repeats blinking 3 times fast and blinking 1 time slow. Restore Condition: Irreparable However, it can be restored by turning the power OFF and then raising the Vp voltage to the range of DC 16.9 to 27.8 V.
  • Page 26 4 ) Others (1) Paper near-end Explanation of status: When the diameter of the roll paper deceases to a certain degree (* differs with the status of using Near-End sensor), the Paper Near-End sensor responds and allows PE LED to light to indicate roll paper is low.
  • Page 27 (3) Head Up (when LT2220/2310 is used) Explanation: When Head Up is set, ERROR LED lights. PE LED: ERROR LED: ON Restore Condition: Set Head Down. PE LED ERROR LED (3) Platen Open (when LT2221/2321 is used) Explanation: When Platen is opened, ERROR LED lights. PE LED: ERROR LED: ON Restore Condition: Close Platen.

  • Page 28: Feed Switch

    Feed Switch Function • When pressed once, paper feed of one line occurs based on the amount of line feed set by ESC 2 and ESC 3. However, paper feed is not available in the following cases. (1) When the FEED switch is set to disable by ESC c 5 (2) When paper-end detector detected no paper (3) With Head Up.

  • Page 29: Self-Printing

    5.3.1 Self-printing 1) Function Function to enable the printer setting status to be verified by printing 2) Start of self-printing When the power is turned on with the FEED switch pressed and held in print ready state, printer status is printed on the roll paper. Explanation of printed item is as shown below.

  • Page 30: Hexadecimal Dump Printing

    5.3.2 Hexadecimal Dump Printing 1) Function Prints the data sent from the host in hexadecimal code and the corresponding characters. 2) Starting hexadecimal dump With paper set and Head Up (or Platen Open), turn the power on while pressing and holding the FEED switch.

  • Page 31: Memory Switch Setting Mode

    5.3.3 Memory Switch Setting Mode 1) Settable memory switch MSW1、MSW2、MSW3 2) Starting memory switch setting mode With paper set and Head Up (or Platen Open), turn the power on while pressing and holding the FEED switch and then press the FEED switch twice, set Head Down (or Platen Close) to start the setting mode.

  • Page 32: Interfaces

    6. INTERFACES Bidirectional Parallel Interface (IEEE1284) 6.1.1 Specification 1) Compatibility Mode (Host → Printer Communication: Centronics Compliant) (1) Outline Compatibility Mode is a standard of Centronics interface that has been used for long. (2) Specification Data transfer system: 8 bit parallel Synchronization: By the nStrobe signal supplied from outside Handshake:...

  • Page 33: Description Of Input/Output Signals

    6.1.2 Description of Input/Output Signals 1) Input/Output Signals Explanation of input/output signals [1] Input/Output Signals (Compatibility Mode) (1) Input signals to the printer ・DATA0 ~ 7: 8 bit parallel signal (positive logic) Strobe signal for reading out 8-bit data (negative logic) ・nSTROBE: Applies reset by the nRESET signal in Compatibility Mode.
  • Page 34 Always non-active (“LOW”). ・SELECT: Signal to set “LOW” when the printer is in the error state (negative ・nFAULT: logic). Signal to be output with No paper or near-end state (by command ・PE: setting) (positive logic) Note: When using a command followed by FROM writing, printer may temporarily become BUSY (DTR) at the time of write operation.
  • Page 35 3) Timing chart (Compatibility Mode) Data input and print timing Power supply DATA nSTROBE BUSY nACK (Note) T1，T2，T3 : 0.5 µs MIN : 270ns MAX : 2.3 µs TYP : 1200ms MIN (At power on) Figure Timing Chart Note: ACK output position can be changed to ACK in BUSY, ACK while BUSY, or ACK after BUSY by the setting of customize value.

  • Page 36: Connection To Parallel Port

    5) Reverse Mode (Nibble/Byte) mode allows status to be transmitted from the printer. (Using GS a, DLE EOT n, GS r, of GS I command) ・The transmitting buffer of the printer is 99 bytes. The host must transfer to Reverse Mode to prevent loss of status.

  • Page 37: Rs-232C Serial Interface

    RS-232C Serial Interface 6.2.1 Specification 1) Synchronization: Asynchronous 2) Baud rate 2400, 4800, 9600, 19200, 38400, 57600, 115200 bps (User selection) 3) Word configuration Start bit: 1 bit Data bit: 7 bits or 8 bits (User selection) Parity bit: Odd, even, or no parity (User selection) Stop bit: 1 bit or more 4) Signal polarity RS-232C...
  • Page 38 ・State to become BUSY 1．Period from Reset (including reset by NV memory write command, I/F signal, and test print command) or just after printer power on to printer operation ready state. 2．Under test printing 3．Input buffer full state (Refer to “(2) Buffer full state”.) 4．During Head Up (or Platen Open) 5．Under line feeding with FEED switch 6．Waiting for pressing FEED switch at the execution of macro...
  • Page 39 2) Buffer full state Buffer full state is when the remaining capacity of input buffer is as shown below. Table Input Buffer Full Set Value Buffer Full Clear 4K bytes Remaining 128 bytes Remaining 256 bytes 45 bytes Remaining 16 bytes Remaining 26 bytes ・When the remaining capacity of input buffer is 0 byte, data received is read and discarded.

  • Page 40: Connection To Serial Port

    6.2.3 Connection to Serial Port 1) Connection to 25-pin/9-pin serial port 25-pin 9-pin Serial interface Serial interface *The above wiring is an example of standard connection to the host. If the cable is relayed, it is necessary to take such measures as connecting DTR/DSR and RXD/TXD reversely, etc.

  • Page 41: Function Selection

    7. Function Selection When using this control board, some functions can be set to default. Jumper Turn the printer power off before changing jumper setting. Jumper No. Function Open Short Auto cutter Enable ●Disable Mechanism used ●LT2220/2221 LT2320/2331 Auto loading ●Enable Disable JP4*...

  • Page 42: Memory Switches

    Memory Switches Memory switch is a generic name for the following: Memory switches MSW1, MSW2, and MSW3 Customize value Serial Interface Communication Conditions 1) Memory switches MSW1, MSW2, and MSW3 Memory switch setting table Function MSW1-1 Power ON notice setting ●...
  • Page 43 2) Customize value Customize value can be set by the GS (E command. Function Value 1K bytes 64K bytes Specify the user NV memory capacity 128K bytes ● 192K bytes Select the print density ● 100% 105% 110% 115% 120% 125% 130% ―...

  • Page 44: Print Control Commands

    8. PRINT CONTROL COMMANDS ○ Print Control Commands Control Function Mode GS P Command S・P Printing and paper feed S・P Back to printing Printing in page mode and recovery ESC FF Printing data in PAGE MODE S・P ESC J Printing and feeding paper in minimum pitch ○...
  • Page 45 ○ Line Feed Span Commands Control Function Mode GS P Command ESC 2 Specifying 1/6-inch line feed rate S・P S・P ESC 3 Setting line feed rate of minimum pitch ○ ○ Bit Image Commands Control Function Mode GS P Command S・P ESC * Specifying the bit image mode...
  • Page 46 Bar Code Commands ○ Control Function Mode GS P Command S・P Selecting of printing position of HRI characters S・P Selecting the font of HRI characters S・P Specifying the height of the bar code S・P Printing the bar code Specifying the horizontal size (magnification) of bar code S・P ○...

  • Page 47: Character Code Table

    9. CHARACTER CODE TABLE Code Page 9.1.1 Codepage 00H to 7FH & PC437 (USA, Europe Standard) Ç É á ░ └ ╨ α ≡ ü æ í ▒ ┴ ╤ β ± " é Æ ó ▓ ┬ ╥ Γ ≧ â...

  • Page 48: Codepage 00H To 7Fh & Katakana

    9.1.2 Codepage 00H to 7FH & Katakana ▁ ┴ SP － タ ミ ═ × ▂ ┬ º ア チ ム ╞ 円 " ▃ ┤ ┌ イ ツ メ ╪ 年 ▅ ├ ┘ ウ テ モ ╡ 月 ▆...

  • Page 49: Codepage 00H To 7Fh & Pc850/858 (Multilingual)

    9.1.3 Codepage 00H to 7FH & PC850/858 (Multilingual) Ç É á ░ └ ð Ó ― ü æ í ▒ ┴ Ð β ± " é Æ ó ▓ ┬ Ê Ô ＝ â ô ú │ ├ Ë Ò ¾...

  • Page 50: Codepage 00H To 7Fh & Pc860 (Portuguese)

    9.1.4 Codepage 00H to 7FH & PC860 (Portuguese) Ç É á ░ └ ╨ α ≡ ü À í ▒ ┴ ╤ β ± " é È ó ▓ ┬ ╥ Γ ≧ â ô ú │ ├ ╙ π ≦ ã...

  • Page 51: Codepage 00H To 7Fh & Pc863 (Canadian-French)

    9.1.5 Codepage 00H to 7FH & PC863 (Canadian-French) Ç É ￤ ░ └ ╨ α ≡ ü È ´ ▒ ┴ ╤ β ± " é Ê ô ▓ ┬ ╥ Γ ≧ â ô ú │ ├ ╙ π ≦ Â...

  • Page 52: Codepage 00H To 7Fh & Pc865 (Nordic)

    9.1.6 Codepage 00H to 7FH & PC865 (Nordic) Ç É á ░ └ ╨ α ≡ ü æ í ▒ ┴ ╤ β ± " é Æ ó ▓ ┬ ╥ Γ ≧ â ô ú │ ├ ╙ π ≦ ä...

  • Page 53: Codepage 00H To 7Fh & Pc852 (Eastern Europe)

    9.1.7 Codepage 00H to 7FH & PC852 (Eastern Europe) Ç É á ░ └ đ ó ü Ĺ í ▒ ┴ Đ β ” " é í ó ▓ ┬ Ď Ó 、 â ú ú │ ├ Ë Ń ˇ...

  • Page 54: Codepage 00H To 7Fh & Pc866 (Russian)

    9.1.8 Codepage 00H to 7FH & PC866 (Russian) Α Р а ░ └ ╨ р Ë Б С б ▒ ┴ ╤ с ë " В Т в ▓ ┬ ╥ т Є Г У г │ ├ ╙ у є...

  • Page 55: Codepage 00H To 7Fh & Pc857 (Turkish)

    9.1.9 Codepage 00H to 7FH & PC857 (Turkish) Ç É á ░ └ ó ― ü æ í ▒ ┴ β ± " é Æ ó ▓ ┬ Ê ô â ô ú │ ├ Ë ò ¾ à ö ñ...

  • Page 56: Codepage 00H To 7Fh & Pc864 (Arabic)

    9.1.10 Codepage 00H to 7FH & PC864 (Arabic)

  • Page 57: Codepage 00H To 7Fh & Wpc1252

    9.1.11 Codepage 00H to 7FH & WPC1252 € ° À Ð à ð ‘ ¡ ± Á Ñ á ñ " ¸ ’ ¢ ² Â Ò â ò ƒ “ £ ³ Ã Ó ã ó ,, ” ¤ ´...

  • Page 58: Codepage 00H To 7Fh & Thaicode18

    9.1.12 Codepage 00H to 7FH & Thaicode18...

  • Page 59: International Character Code Table

    International Character Code Table Country 23 24 40 5B 5C 5D 5E 60 7B 7C 7D 7E ＃ ＄ ＠ ╲ France ＃ ＄ à ° ç § é ù È ¨ Germany ＃ ＄ § Ä Ö Ü ä ö...
