  • Page 1 Printer Module Unit MODEL PMU3300 User’s Manual...
  • Page 2 WEEE MARK If you want to dispose of this product, do not mix it with general household waste. There is a separate collection systems for used electronics products in accordance with legislation under the WEEE Directive and is effective only within European Union. Wenn Sie dieses Produkt entsorgen wollen, dann tun Sie dies bitte nicht zusammen mit dem Haushaltsmüll.
  • Page 3 Low Voltage Directive (2014/35/EU), EMC Directive (2014/30/EU), and RoHS directive (2011/65/EU) Full text of the EU declaration of conformity is available at the following internet address: http://www.citizen-systems.co.jp/en/printer/download/eu_doc.html IMPORTANT: This equipment generates, uses, and can radiate radio frequencyenergy and if not installed and used in accordance with the instruction manual, maycause interference to radio communications.
  • Page 4 Data is basically for temporary use and not stored for an extended period of time or permanently. Please note that Citizen Systems is not responsible for damage or lost profit resulting from the loss of data caused by accidents, repairs, tests or other occurrences.
  • Page 5 Warning ● Do not use or store this product in place where it will be exposed to: -Flames or moist air -Direct sunlight -Hot airflow or radiation from a heating device -Ill-ventilated atmosphere -Chemical reactions in a laboratory -Airborne oil, steel particles, or dust -Static electricity or strong magnetic field ●...
  • Page 6 ● Connect the printer to a ground. Electric leakage may cause an electric shock. ● Do not connect the printer’s ground to any of the following: Gas piping - A gas explosion could result. Telephone line ground Lightning rod - If lightning strikes a large surge of current may cause fire or shock. Water pipes - Plastic water pipes should not be used for grounding.

  • Page 7: Table Of Contents

    Contents 1. PRODUCT OUTLINE ..............2 1.1 F ..........................................2 EATURE 1.2 M ....................................2 ODEL LASSIFICATIONS 1.3 I ....................................2 TEMS IN THE PACKAGE 2. GENERAL SPECIFICATION ............3 2.1 P ....................................3 RINTING SPECIFICATION 2.2 P ) ..........................4 RINTING APER PECIFICATION...

  • Page 8: Product Outline

    8) Printing layout can be freely adjusted by page mode 9) Barcode printing is available. The two-dimensional barcode is supported. 10) Dedicated paper holder unit PHU-500 is available as an option. 1.2 Model Classifications PMU3300 U X X Interface U: USB+Serial Paper width...

  • Page 9: General Specification

    2. GENERAL SPECIFICATION 2.1 Printing specification Item PMU3300 U2 (2 inch) PMU3300U2 (3 inch) Printing Method Line thermal (thermal printing method) Dot configuration 576 dots/line Dot density 8 dots / mm Printing speed *1 MAX 150mm/ sec. (1200 dot line / sec.) Paper feed 0.125mm...

  • Page 10: Printing Paper Specification (Thermal Paper)

    2.2 Printing Paper Specification (Thermal paper) 1) Paper width 2 Inch: 58 / 60 (+0, -1) mm 3 Inch: 80 (+0, -1) mm 2) External dimensions Less than φ213mm Roll diameter: Core inner dieameter φ 12 / Outer diameter φ 18 or Core diameter: Core inner diameter φ...

  • Page 11: External View

    3. EXTERNAL VIEW AND NOTE ON THE ENCLOSURE 3.1 Dimensions Paper center...
  • Page 12 Print Position 3.3 Notes on the enclosure side The PMU3300 is a printer that can be installed in various devices。Please pay attention to the following points regarding the enclosure design and so on. - Please consider the shape to prevent dust and water droplets from getting in from the outside.

  • Page 13: Operation Panel

    4. OPERATION PANEL 4.1 LED There are three LEDs on the operation panel. 1）POWER LED (Green) Indicates the power status. Power is supplied. Blinking: Memory check error. Hexadecimal dump mode, Memory switch setting mode OFF: Power is not supplied. 2）ERROR LED（Red）Indicates the status of various errors, etc. Cover open Blinking: Various kinds of error, Macro execution wait OFF:...

  • Page 14: Details On Error And Led Indication

    4.2 Details on Error Indication by LED POWER LED ERROR LED PAPER Error (Green) (Red) (Orange) Automatically Head overheat error Unlit recoverable error Cover open error Unlit (MSW3-8 is set to OFF) Low voltage error Unlit High voltage error Unlit Recoverable error Cover open error Unlit...

  • Page 15: Feed Button

    The self-printing is started in three methods shown below. Hold FEED BUTTON and turn ON the power supply Contents of Self printing are as follows. (1) Name of the printer: PMU3300 (2) ROM version: E00-XXXX=Firm ware version (3) DATE 20XX-XX-XX=Date (4) BOOT version XXX.XX=Boot version...

  • Page 16: Hexadecimal Dump Mode Printing

    4.3.2 Hexadecimal Dump Mode Printing 1) Function It prints the data sent from the host in hexadecimal and its corresponding characters. 2) Starting hexadecimal dump -With the paper loaded and the printer cover open, press and hold the FEED button and turn on the printer.

  • Page 17: Memory Switch Setting Mode

    4.3.3 Memory Switch Setting Mode Memory switches are used to set various printer settings. Memory switches can be set manually, or by utilities or commands. This section explains how to perform manual settings. For information on how to set the memory switches using commands, please refer to the Command Reference.

  • Page 18: Test Button

    9) Open the paper cover and close it. The changed memory switch settings are printed. 10) Repeat steps 4 to 9 to change functions for a different memory switch number. 11) Press the FEED button until “Save To Memory” is printed. 12) Press the FEED button for at least two seconds.

  • Page 19: Setting Paper, Paper Guide And Maintenance

    5. SETTING PAPER, PAPER GUIDE and MAINTENANCE 5.1 Manual loading Lift the lever up. Open the cover. Put the roll paper in the place. Close the cover. (Paper leading edged to the arrowed position.) 5.2 Auto Loading Insert the roll paper and push it until the leading edge hits the platen.

  • Page 20: Changing Of Paper Width

    Caution •Never open the printer cover during printing operation. •Always use recommended rolled paper. • Use of paper not recommended may not secure print quality and life. • Set the roll paper straightly without surface waviness. • Do not touch the print head by hand just after printing as it is heated during printing. •...

  • Page 21: Connector And Interface

    6. CONNECTOR AND INTERFACE Power Connector Serial Interface PNE Connector USB Interface 6.1 Power connector Connector: 2-1445089-2 / Tyco electronics Pin No. Signal Function DC24V Input t Common ground on circuit *The above pins must be connected. 6.2 Serial Interface 6.2.1 Specifications 1) Synchronization: Asynchronization 2) Baud rate...

  • Page 22: Connector Pin

    6.2.2 Connector PIN Connector: XG4A-1034 / OMRON Pin No. Signal Input /Output Signal Level Function Common signal on circuit Output : +3.9V to +5.2V Transferred data 0V to +0.4V Common signal on circuit Input -15V to +15V Received data MODE Input : +2.0V to +5.5V Mode selection signal...

  • Page 23: Usb Interface

    6.3 USB Interface Pin No. Signal name VBus（+5V） -Data（D-） +Data（D+） NC：None Connect * USB communication monitoring is possible with the USB printer class. If there is no communication with the PC for a certain period, it is determined that the USB connection is in This is a ‘watchdog’...

  • Page 24: Memory Switches

    7. MEMORY SWITCHES Memory switch is a generic name for the following: Memory switches (MSW1, MSW2, MSW3, MSW4, MSW5, MSW6) Customize value (MSW7, MSW8, MSW9, MSW10)  Memory switches (MSW1, MSW2, MSW3, MSW4, MSW5, MSW6) Function MSW1-1 Power ON Info Valid Not Send MSW1-2...
  • Page 25  Customize value (MSW7, MSW8, MSW9, MSW10) Customize value can be set by the GS (E command.) Function Value MSW7-1 Baud Rate 1200bps 2400bps 4800bps 9600bps 19200bps 38400bps 57600bps 115200bps MSW7-2 Data Length 7 bits 8 bits MSW7-3 Stop Bit 1 bit 2 bits MSW7-4...
  • Page 26 Function Value MSW10-1 Print Density 100% 105% 110% 115% 120% 125% 130% 135% 140% MSW10-2 Print Speed Level1 Level2 Level3 Level4 Level5 Level6 Level7 Level8 Level9 MSW10-4 Emulation mode ESC/POS Axiohm (* Note 1) ・・・Default (factory shipment setting) Note 1: Target emulation of driver, SDK and Utility is ESC/POS only..

  • Page 27: Print Control Commands (Esc/Pos)

    8. PRINT CONTROL COMMANDS (ESC/POS) Refer to “Command reference” for further details on command. • Print Control Commands Control Function MODE GS P Command Printing and paper feed S·P Back to printing S·P Printing in page mode and recovery ESC FF Printing data in PAGE MODE ...
  • Page 28 • Print Position Commands Control Function MODE GS P Command Horizontal tab S·P  ESC $ Specifying the absolute positions S·P ESC D Setting horizontal tab position S·P ESC T Selecting the character printing direction in PAGE MODE  ESC W Defining the print area in PAGE MODE ...
  • Page 29 • Panel Switch Commands Control Function MODE GS P Command ESC c 5 Enabling/disabling the panel switches S·P • Macro Commands Control Function MODE GS P Command GS : Starting/ending macro definition S·P GS ^ Executing the macro S·P • Cutter Commands Control Function MODE...
  • Page 30 • Commands for Flash Memory Control Function MODE GS P Command FS p Printing the bit image in user NV memory FS q Defining the bit image in user NV memory • Printer Setting Commands Control Function MODE GS P Command GS ( E User-defined command...

  • Page 31: Option: Paper Holder Unit

    9. OPTION: PAPER HOLDER UNIT PHU-500 PHU-500 Paper Holder Unit The paper holder arms can be mounted on either the left or right side of the frame and can be used at seven different angles in each position. Arm fixed at left side Arm fixed at right side PHU-500 Paper holder unit: The arm for paper holder can be mounted on the right or left side of the frame and can be used at 7 different angles.
