Contents
1
Product Configuration as a MIDI Device.......................................................................................... 6
1.1
System Section.................................................................................................................................... 6
1.2
Sound Generator Section .................................................................................................................... 6
1.2.1
Sound generator common section .......................................................................................................... 7
1.2.2
Sound Generator Parts............................................................................................................................ 7
1.2.3
MIDI Receive and Registration..............................................................................................................8
1.3
Performance Controller Section .......................................................................................................... 8
1.3.1
Auto Performance MIDI Send ............................................................................................................... 8
1.3.2
MIDI Send by Registration ....................................................................................................................8
1.3.3
MIDI Send by Assignable Buttons.........................................................................................................9
2
Conditions that Disable Message Send and Receive ...................................................................... 9
3
Timbre Type Specific Operation ...................................................................................................... 9
Part II
4
Send Channel ................................................................................................................................ 10
5
Receive Channel ........................................................................................................................... 10
6
Note Off ......................................................................................................................................... 10
7
Note On ......................................................................................................................................... 11
8
Polyphonic Key Pressure............................................................................................................... 11
9
Control Change.............................................................................................................................. 11
9.1
Bank Select (00H, 20H)..................................................................................................................... 12
9.2
Modulation (01H) ............................................................................................................................... 12
9.3
Portamento Time (05H) ..................................................................................................................... 12
9.4
Data Entry (06H, 26H) ....................................................................................................................... 13
9.5
Volume (07H) .................................................................................................................................... 13
9.6
Pan (0AH).......................................................................................................................................... 13
9.7
Expression (0BH) .............................................................................................................................. 14
9.8
General Use Controllers 1 through 8 (10H through 13H, 50H through 53H)..................................... 14
9.9
Hold1 (40H) ....................................................................................................................................... 15
9.10
Portamento Switch (41H) .................................................................................................................. 15
9.11
Sostenuto (42H) ................................................................................................................................ 16
9.12
Soft (43H) .......................................................................................................................................... 16
9.13
Filter Resonance (47H) ..................................................................................................................... 17
PX-3 MIDI Implementation
CASIO COMPUTER CO., LTD.
1
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Casio PX-3BK
Summary of Contents for Casio PX-3BK
-
Page 1: Table Of Contents
PX-3 MIDI Implementation CASIO COMPUTER CO., LTD. Contents Part I MIDI Message Overview Product Configuration as a MIDI Device..................6 System Section............................ 6 Sound Generator Section ........................6 1.2.1 Sound generator common section ......................7 1.2.2 Sound Generator Parts..........................7 1.2.3... - Page 2 9.14 Release Time (48H) .......................... 17 9.15 Attack Time (49H)..........................17 9.16 Filter Cut Off (4AH)..........................18 9.17 Vibrato Rate (4CH) ..........................18 9.18 Vibrato Depth (4DH) .......................... 18 9.19 Vibrato Delay (4EH)........................... 19 9.20 Portamento Control (54H) ......................... 19 9.21 Reverb Send (5BH) ...........................
- Page 3 Part IV Instrument-Specific System Exclusive Messages 16 Format ............................31 16.1 Message Classifications ........................31 16.2 Basic Message Structure........................31 16.3 Field Formats............................. 32 16.3.1 SX : System Exclusive Message Status ....................32 16.3.2 MAN : Manufacturer’s ID........................32 16.3.3 MOD : Model ID..........................
- Page 4 22 Scale Tune............................. 44 23 Registration Parameter ........................44 23.1 Assignable Button 1 Parameter......................44 23.2 Assignable Button 2 Parameter......................44 23.3 Common Parameter .......................... 45 23.4 Equalizer Parameter.......................... 46 24 Registration Bank Parameter......................46 24.1 Bank Common........................... 46 Part VI DSP Parameter List 25 DSP Algorithm ID Tables .......................
- Page 5 26.34 Multi17 (Compressor - Phaser) ......................58 26.35 Multi18 (Phaser - Distortion)......................59 26.36 Multi19 (Phaser - Chorus - Auto Pan) ....................59 26.37 Multi20 (LFO Wah - Chorus) ......................60 26.38 Multi21 (Auto Wah - Chorus) ......................60 26.39 Multi22 (Compressor - Distortion - Chorus)..................
-
Page 6: Part I
Part I MIDI Message Overview Product Configuration as a MIDI Device As a MIDI device, this Instrument consists of the System Section, Sound Generator Section, and Performance Controller Section described below. Each of these sections sends and receives specific MIDI Messages in accordance with its function. System Section •... -
Page 7: Sound Generator Common Section
1.2.1 Sound generator common section The common section consists of sound generator setting blocks that do not depend on the sound generator part, such as system effects, mixer master control, etc. These can be controlled by system exclusive messages that are basically exclusive to this particular Instrument, but several parameters also can be controlled by general universal system exclusive messages. -
Page 8: Midi Receive And Registration
1.2.3 MIDI Receive and Registration The registration (setup) can be switched by MIDI message. For details about messages, see “19.1 Panel Parameter”. When switching the registration by MIDI message, the parts reflected by the zone parameters are determined in accordance with the MIDI send channel setting values of the zone parameters. -
Page 9: Midi Send By Assignable Buttons
1.3.3 MIDI Send by Assignable Buttons The message(s) sent when an assignable button is pressed depends on the function assigned to the button. Also, any control change message can be assigned to an assignable button. Since messages that can be sent by an assignable button operation are so diverse and wide-ranging, messages are not covered in detail here. -
Page 10: Channel Message
Part II Channel Message Send Channel For information about the MIDI channels of the channel messages that are sent when this Instrument is played, see “1.2.2 Sound Generator Parts”. Note, however, that the MIDI channel of the performance information that corresponds to the keyboard main part can be changed by zone editing. -
Page 11: Note On
Note On Format Message Format: 9nH kkH vvH n: MIDI Channel Number kk: Key Number vv: Velocity Send Sent when a key is pressed. Receive Recognized as key press information. Polyphonic Key Pressure Format Message Format: AnH kkH vvH n: MIDI Channel Number kk: Key Number vv: Pressure Value Send... -
Page 12: Bank Select (00H, 20H)
Bank Select (00H, 20H) Format Message Format: BnH 00H mmH (MSB) BnH 20H llH (LSB) n: MIDI Channel Number mm: Value ll: Value Send Sent in the following cases. When a tone selection is made • When a program change message is specified by a zone edit operation •... -
Page 13: Data Entry (06H, 26H)
Data Entry (06H, 26H) Format Message Format: BnH 06H vvH (MSB) BnH 26H vvH (LSB) n: MIDI Channel Number vv: Value Send Sent when there is a change in the parameters assigned to NRPN and RPN. For details about information assigned to parameters that correspond to NRPN and RPN, see “9.23 NRPN (62H, 63H)” and “9.24 RPN (64H, 65H)”. -
Page 14: Expression (0Bh)
Expression (0BH) Format Message Format: BnH 0BH vvH n: MIDI Channel Number vv: Value Send See “1.3.3 MIDI Send by Assignable Buttons”. Receive Receipt changes the part volume level. How this message differs from Volume (07H) Though this message is operationally identical to that of “9.5 Volume (07H),” the purposes of the two messages are different. This message is used, for example, for crescendo/decrescendo, and other forms of expression while playing. -
Page 15: Hold1 (40H)
Hold1 (40H) Format Message Format: BnH 40H vvH n: MIDI Channel Number vv: Value Send Sent in the following cases. When a pedal that has a sustain (damper) function is operated • Sent when a MIDI channel is specified by a zone edit operation. •... -
Page 16: Sostenuto (42H)
9.11 Sostenuto (42H) Format Message Format: BnH 42H vvH n: MIDI Channel Number vv: Value (Note1) Note 1: For information about the relationship between setting values and send/receive values, see the “27.1 Off/On Setting Value Table” in “Part VII Setting Values and Send/Receive Values”. Send Sent in the following cases. -
Page 17: Filter Resonance (47H)
9.13 Filter Resonance (47H) Format Message Format: BnH 47H vvH n: MIDI Channel Number vv: Value (Note1) Note 1: For information about the relationship between setting values and send/receive values, see “27.6 –64 - 0 - +63 Setting Value Table” in “Part VII Setting Values and Send/Receive Values”. Send See “1.3.3 MIDI Send by Assignable Buttons”. -
Page 18: Filter Cut Off (4Ah)
9.16 Filter Cut Off (4AH) Format Message Format: BnH 4AH vvH n: MIDI Channel Number vv: Value (Note1) Note 1: For information about the relationship between setting values and send/receive values, see “27.6 –64 - 0 - +63 Setting Value Table” in “Part VII Setting Values and Send/Receive Values”. Send Sent when filter is specified by a zone edit operation. -
Page 19: Vibrato Delay (4Eh)
9.19 Vibrato Delay (4EH) Format Message Format: BnH 4EH vvH n: MIDI Channel Number vv: Value (Note1) Note 1: For information about the relationship between setting values and send/receive values, see “27.6 –64 - 0 - +63 Setting Value Table” in “Part VII Setting Values and Send/Receive Values”. Send Sent when the vibrato delay is specified by a zone edit operation. -
Page 20: Chorus Send (5Dh)
9.22 Chorus Send (5DH) Format Message Format: BnH 5DH vvH n: MIDI Channel Number vv: Value Send Sent when the portamento on/off setting is specified by a zone edit operation. Receive Receipt changes the Cho Send Part Parameter. 9.23 NRPN (62H, 63H) Format Message Format: BnH 62H vvH (LSB) BnH 63H vvH (MSB) -
Page 21: Pitch Bend Sensitivity
9.24.1 Pitch Bend Sensitivity Format Message Format: BnH 64H 00H 65H 00H 06H mmH 26H llH n: MIDI Channel Number Value 0 - 24 Send: 00H, Receive: Ignored Send Sent when the pitch bend range is changed. Receive Receipt changes Pitch Bend Sensitivity. 9.24.2 Fine Tune Format... -
Page 22: Modulation Depth
9.24.4 Modulation Depth Format Message Format: BnH 64H 05H 65H 00H 06H mmH 26H 00H n: MIDI Channel Number mm: Value Send This message is not sent by this Instrument. Receive Receipt changes Vib Mod Depth of the LFO Parameter. 9.24.5 Null Format... -
Page 23: All Notes Off (7Bh)
10.3 All Notes Off (7BH) Format Message Format: BnH 7BH 00H n: MIDI Channel Number Send Sent when a MIDI channel is specified by a zone edit operation. Receive Receipt of this message releases the currently sounding voice (same as releasing the keyboard key). 10.4 Omni Off (7CH) Format... -
Page 24: Poly (7Fh)
10.7 Poly (7FH) Format Message Format: BnH 7FH 00H n: MIDI Channel Number Send This message is not sent by this Instrument. Receive Receipt of this message stops the currently sounding voice. Program Change Format Message Format: CnH ppH n: MIDI Channel Number pp: Program Number Send Sent in the following cases. -
Page 25: About Dsp
11.2 About DSP 11.2.1 DSP Line Structure and Assignment This Instrument has two DSP lines that can be used simultaneously. Selecting multiple tones with DSP at the same time creates the possibility that there will not be enough DSP lines. If this happens, DSP lines will be assigned in accordance with the DSP line assignment priority specified for each part. -
Page 26: System Messages
Part III System Messages Active Sensing Format Message Format: FEH Send This message is not sent by this Instrument. Receive Once this message is received, the Active Sensing mode is entered. If no MIDI message is received for a specified amount of time, voices being sounded by this Instrument’s sound source are released, the controller is reset, and the Active Sensing mode is exited. -
Page 27: Master Balance
15.1.2 Master Balance Format Message Format: F0H 7FH 7FH 04H 02H llH mmH F7H ll: Value LSB (Note1) mm: Value MSB (Note1) Note 1: For information about the relationship between setting values and send/receive values, see “27.8 Pan Setting Value Table” in “Part VII Setting Values and Send/Receive Values”. -
Page 28: Reverb Parameter
15.1.5 Reverb Parameter Format Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H ppH vvH F7H pp: Parameter vv: Value Type Format Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 01H 00H vvH F7H vv: Value (Note1) Note 1: For information about the relationship between setting values and send/receive values, see “27.9 Reverb Type Setting Value... - Page 29 Send This message is sent when the System Chorus Type setting is changed. Receive Receipt changes the System Chorus Type parameter. Rate Format Message Format: F0H 7FH 7FH 04H 05H 01H 01H 01H 01H 02H 01H vvH F7H vv: Value Send This message is not sent by this Instrument.
-
Page 30: Gm System Message
15.1.7 GM System Message GM System On Format 1 Message Format: F0H 7EH 7FH 09H 01H F7H Send This message is not sent by this Instrument. Receive Receipt puts the sound source into a GM sound source mode. Also, the Scale Tune Enable setting shown under “20.7 Part Parameters”... -
Page 31: Instrument-Specific System Exclusive Messages
Part IV Instrument-Specific System Exclusive Messages Format This section explains the format of the Instrument-specific System Exclusive Messages. See “Part V Parameter List” for information about what type of data can actually be sent. 16.1 Message Classifications Basically, the operation that corresponds to Instrument-specific system exclusive messages is parameter data transfer. The following operations can be performed from an external device using this parameter transfer message. -
Page 32: Field Formats
SX : System Exclusive Message Status Format: 11110000B (F0H) This is the System Exclusive Message status byte established by the MIDI standard. 16.3.2 MAN : Manufacturer’s ID Format: 01000100B (CASIO = 44H) Indicates this Instrument’s manufacturer ID. 16.3.3 MOD : Model ID Format: MSB... -
Page 33: Cat : Category
16.3.6 cat : Category Format: 0cccccccB 0cccccccB = Category (7bit) The category indicates the categories of data handled by the System Exclusive Message. The ID number (ID) of the category is indicated on the left, while the communication operation (Action) is indicated on the right. Category Transfer ID (c) -
Page 34: Prm : Parameter Id
Block Bit Field Division Case 1 • When an array has three or fewer nesting levels and the number of arrays in each dimension is 128 or less, they are assigned below the three 7-bit fields. Unused regions are filled with zeros. Example: parameter [A][B][C] With a 3-dimensional array parameter that consists of A=8 (3 bits), B=5 (3 bits) and C=10 (4 bits), the block bit... -
Page 35: Data : Parameter Data
16.3.13 data : Parameter Data Format: index0 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB) index1 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB) index2 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB) indexN 0dddddddB (0eeeeeeeB) (0fffffffB) (0gggggggB) (0hhhhhhhB) Parameter data indicates the parameter value. The data array is a list of len + 1 data items. For a one data item structure, the length depends on the data bit width, as shown below. -
Page 36: Parameter Transfer
Parameter Transfer There are two parameter operations: Individual Parameter Transfer and Individual Parameter Request. A single session is concluded only when this Instrument returns an IPS (Individual Parameter Send) in response to an IPR (Individual Parameter Request) from an external device, or when an external device or this Instrument spontaneously sends an IPS. -
Page 37: System Parameters
Part V Parameter List How to Read the Tables Number Base Notation “Size” indicates the parameter value bit width as a decimal value. The bit field position of “Block” as a decimal value. Values used in the explanations under “Description” are all decimal values, unless specified otherwise. Values other than those described above are all hexadecimal. -
Page 38: Setup Parameter
Setup Parameter Setup Parameters put a device into the setup mode. 19.1 Panel Parameter Parameter Block Size Array Min-Def-Max Description Registration 0024 R/W 000000 00-00-FF 0...Bank1 Registration1 Number For Midi 1...Bank1 Registration2 8...Bank2 Registration1 9...Bank2 Registration2 63...Bank8 Registration8 (Note1) Note 1: Operation is not guaranteed for values of 64 (40H) or greater. -
Page 39: System Chorus Parameter
20.3 System Chorus Parameter Parameter Block Size Array Min-Def-Max Description Cancel 0050 000000 00-00-01 0...Normal 1...Cancel Type 0051 00-02-0F 1-16 (Note1) Rate 0052 00-0B-7F 0-127 Depth 0053 00-21-7F 0-127 Feedback 0054 00-00-7F 0-127 Tone 0055 00-4B-7F 0-127 Note 1:... -
Page 40: Master Equalizer Parameter
20.6 Master Equalizer Parameter Parameter Block Size Array Min-Def-Max Description Low Freq 00A1 000000 00-00-02 0-2 (Note1) Low Gain 00A2 00-0C-18 -12 - 0 - +12 (Note2) Mid1 Freq 00A3 00-04-07 0-7 (Low-Mid) (Note3) Mid1 Gain 00A4 00-0C-18 -12 - 0 - +12 (Low-Mid) (Note2) ... -
Page 41: Part Registration Parameter
20.8 Part Registration Parameter Parameters that have the same names as Part Parameters have the same functions as well. Parameter Block Size Array Min-Def-Max Description Tone Num 0100 20-6: 0 0000-0000-3FFF 0-16383 5-0: Part # Internal External 0102 00-03-03 00(0)...Both Off Select 01(1)...External Only... -
Page 42: Tone Parameters
Tone Parameters 21.1 Basic Parameters Parameter Block Size Array Min-Def-Max Description Name 0000 000000 00-20-7F Ascii Character Timbre Type 0001 00-00-0F 0...Melody 1...Piano 2...Drum 3...reserved 4...LM Piano Timbre Num 0002 0000-0000-3FFF 0-16383 Oct Shift 0003 02-04-06 –2 - 0 - +2 ... -
Page 43: Lfo Parameters
21.2 LFO Parameters Parameter Block Size Array Min-Def-Max Description Vib Wave 000D 000000 00-00-0F 0...Sin 1...Tri 2...Saw Up 3...Saw Down 4...Pulse 1:3 5...Pulse 2:2 6...Pulse 3:1 15...Depends on original Vib Rate 000E 00-40-7F –64 - 0 - +63 (Note1) ... -
Page 44: Scale Tune
Scale Tune Parameter Block Size Array Min-Def-Max Description Note 0000 000000 00-80-FF –128 - 0 - 127 Array : Note 0..C 1..C# 2..D 3..D# 4..E 5..F 6..F# 7..G 8..G# 9..A 10...A# 11...B A Key Mode 0001 00-00-01 0...Relative 1...Absolute Registration Parameter Registration parameters are this Instrument’s registration setting data. -
Page 45: Common Parameter
23.3 Common Parameter Parameter Block Size Array Min-Def-Max Description Layer Onoff 0022 000000 00-00-01 0...Off 1...On Split Onoff 0023 00-00-01 0...Off 1...On Split Point 0024 15-30-6C 21..A0 22..B b 0 107...B7 108...C8 Reverb Onoff 0025 00-00-01 0...Off 1...On ... -
Page 46: Equalizer Parameter
23.4 Equalizer Parameter This is a registration parameter whose operation is basically the same as the Master Equalizer Parameter. Parameter R/W Block Size Array Min-Def-Max Description Equalizer Low Gain 003A 000000 34-40-4C -12 - 0 - +12 (Note1) Equalizer Lowmid Gain 003B 34-40-4C -12 - 0 - +12 (Note1) -
Page 47: Part Vi Dsp Parameter List
Part VI DSP Parameter List DSP Algorithm ID Tables The lists in this section show the DSP algorithms that are built into this Instrument. 25.1 Stereo Tone DSP Number Algorithm Input Output Parameter Set Type 2001 Equalizer Stereo Stereo Equalizer 2002 Compressor Stereo... -
Page 48: Dsp Parameter Set Types
DSP Parameter Set Types This section describes the DSP parameter combination patterns of each algorithm specified in the “Parameter Set Type” column of “25 DSP Algorithm ID Tables”. Note: The characteristics of a DSP are different depending on the tone, even if the same algorithm is used. Because of this, the same algorithm may not produce the same effect for different tones. -
Page 49: Chorus
26.5 Chorus Parameter Number Parameter Name Value Notes Parameter7[00] Rate 00 - 7F Parameter7[01] Depth 00 - 7F Parameter7[02] Feedback 00 - 7F Note1 Parameter7[03] Wet Level 00 - 7F Parameter7[04] Polarity 00 - 7F Note2 Note 1: See “27.6 –64 - 0 +63 Setting Value Table”. Note 2: See “27.2 –... -
Page 50: Drive Rotary
26.9 Drive Rotary Parameter Number Parameter Name Value Notes Parameter7[00] Overdrive Gain 00 - 7F Parameter7[01] Overdrive Level 00 - 7F Parameter7[02] Speed 00 - 7F Note1 Parameter7[03] Brake 00 - 7F Note2 Parameter7[04] Fall Accel 00 - 7F Parameter7[05] Rise Accel 00 - 7F Parameter7[06]... -
Page 51: Phaser
26.13 Phaser Parameter Number Parameter Name Value Notes Parameter7[00] Resonance 00 - 7F Parameter7[01] Manual 00 - 7F Note1 Parameter7[02] Rate 00 - 7F Parameter7[03] Depth 00 - 7F Parameter7[04] Wet Level 00 - 7F Note 1: See “27.6 –64 - 0 +63 Setting Value Table”. 26.14 Distortion Parameter Number... -
Page 52: Multi01 (Enhancer - Chorus)
26.18 Multi01 (Enhancer - Chorus) Parameter Number Parameter Name Value Notes Parameter7[00] EnLowFreq 00 - 7F Parameter7[01] EnLowGain 00 - 7F Parameter7[02] En HiFreq 00 - 7F Parameter7[03] En HiGain 00 - 7F Parameter7[04] Cho Rate 00 - 7F Parameter7[05] Cho Depth 00 - 7F Parameter7[06]... -
Page 53: Multi04 (Compressor - Chorus)
26.21 Multi04 (Compressor - Chorus) Parameter Number Parameter Name Value Notes Parameter7[00] Cmp Depth 00 - 7F Parameter7[01] CmpAttack 00 - 7F Parameter7[02] Cmp Reles 00 - 7F Parameter7[03] Cmp Level 00 - 7F Parameter7[04] Cho Rate 00 - 7F Parameter7[05] Cho Depth 00 - 7F... -
Page 54: Multi06 (Phaser - Auto Pan)
26.23 Multi06 (Phaser - Auto Pan) Parameter Number Parameter Name Value Notes Parameter7[00] Pha Reso 00 - 7F Parameter7[01] PhaManual 00 - 7F Note1 Parameter7[02] Pha Rate 00 - 7F Parameter7[03] Pha Depth 00 - 7F Parameter7[04] PhaWetLvl 00 - 7F Parameter7[05] APan Rate 00 - 7F... -
Page 55: Multi08 (Auto Wah - Phaser)
26.25 Multi08 (Auto Wah - Phaser) Parameter Number Parameter Name Value Notes Parameter7[00] AWh Input 00 - 7F Parameter7[01] AWh Reso 00 - 7F Parameter7[02] AWhManual 00 - 7F Parameter7[03] AWh Depth 00 - 7F Note1 Parameter7[04] Pha Reso 00 - 7F Parameter7[05] PhaManual 00 - 7F... -
Page 56: Multi10 (Distortion - Chorus)
26.27 Multi10 (Distortion - Chorus) Parameter Number Parameter Name Value Notes Parameter7[00] Dist Gain 00 - 7F Parameter7[01] Dist Low 00 - 7F Parameter7[02] Dist High 00 - 7F Parameter7[03] DistLevel 00 - 7F Parameter7[04] Cho Rate 00 - 7F Parameter7[05] Cho Depth 00 - 7F... -
Page 57: Multi12 (Compressor - Lfo Wah)
26.29 Multi12 (Compressor - LFO Wah) Parameter Number Parameter Name Value Notes Parameter7[00] Cmp Depth 00 - 7F Parameter7[01] CmpAttack 00 - 7F Parameter7[02] Cmp Reles 00 - 7F Parameter7[03] Cmp Level 00 - 7F Parameter7[04] LWh Input 00 - 7F Parameter7[05] LWh Reso 00 - 7F... -
Page 58: Multi15 (Compressor - Auto Pan)
26.32 Multi15 (Compressor - Auto Pan) Parameter Number Parameter Name Value Notes Parameter7[00] Cmp Depth 00 - 7F Parameter7[01] CmpAttack 00 - 7F Parameter7[02] Cmp Reles 00 - 7F Parameter7[03] Cmp Level 00 - 7F Parameter7[04] APan Rate 00 - 7F Parameter7[05] APanDepth 00 - 7F... -
Page 59: Multi18 (Phaser - Distortion)
26.35 Multi18 (Phaser - Distortion) Parameter Number Parameter Name Value Notes Parameter7[00] Pha Reso 00 - 7F Parameter7[01] PhaManual 00 - 7F Note1 Parameter7[02] Pha Rate 00 - 7F Parameter7[03] Pha Depth 00 - 7F Parameter7[04] PhaWetLvl 00 - 7F Parameter7[05] Dist Gain 00 - 7F... -
Page 60: Multi20 (Lfo Wah - Chorus)
26.37 Multi20 (LFO Wah - Chorus) Parameter Number Parameter Name Value Notes Parameter7[00] LWh Input 00 - 7F Parameter7[01] LWh Reso 00 - 7F Parameter7[02] LWhManual 00 - 7F Parameter7[03] LWh Rate 00 - 7F Parameter7[04] LWh Depth 00 - 7F Parameter7[05] Cho Rate 00 - 7F... -
Page 61: Multi22 (Compressor - Distortion - Chorus)
26.39 Multi22 (Compressor - Distortion - Chorus) Parameter Number Parameter Name Value Notes Parameter7[00] Cmp Depth 00 - 7F Parameter7[01] CmpAttack 00 - 7F Parameter7[02] Cmp Reles 00 - 7F Parameter7[03] Cmp Level 00 - 7F Parameter7[04] Dist Gain 00 - 7F Parameter7[05] Dist Low 00 - 7F... -
Page 62: Multi24 (Auto Wah - Distortion - Chorus)
26.41 Multi24 (Auto Wah - Distortion - Chorus) Parameter Number Parameter Name Value Notes Parameter7[00] AWh Input 00 - 7F Parameter7[01] AWh Reso 00 - 7F Parameter7[02] AWhManual 00 - 7F Parameter7[03] AWh Depth 00 - 7F Note1 Parameter7[04] Dist Gain 00 - 7F Parameter7[05] Dist Low... -
Page 63: Multi26 (Compressor - Distortion - Tremolo)
26.43 Multi26 (Compressor - Distortion - Tremolo) Parameter Number Parameter Name Value Notes Parameter7[00] Cmp Depth 00 - 7F Parameter7[01] CmpAttack 00 - 7F Parameter7[02] Cmp Reles 00 - 7F Parameter7[03] Cmp Level 00 - 7F Parameter7[04] Dist Gain 00 - 7F Parameter7[05] Dist Low 00 - 7F... -
Page 64: Part Vii Setting Values And Send/Receive Values
Part VII 27.6 –64 - 0 - +63 Setting Value Table Transmit/Receive Value Parameter Setting Values and Send/ –64 Receive Values –63 Setting Value Tables 27.1 Off/On Setting Value Table 27.7 –100 - 0 - +99 Setting Value Table Transmit Value Receive Value Parameter 00H - 3FH... -
Page 65: Reverb Type Setting Value Table
27.9 Reverb Type Setting Value Table 27.11 Equalizer Low Frequency Setting Value Table Transmit / Parameter Display Receive Value Parameter Value Frequency Room1 200Hz Room2 Room 400Hz Room3 800Hz Hall1 Large Hall Hall2 Hall 27.12 Equalizer Mid Frequency Setting Plate1 Value Table Delay Parameter Value... -
Page 66: Equalizer Gain Setting Value Table
27.14 Equalizer Gain Setting Value 27.15 DSP Equalizer Gain Setting Value Table Table Parameter Value Gain Parameter Value Gain –12 –12 –11 –11 –10 –10 –9 –9 –8 –8 –7 –7 –6 –6 –5 –5 –4 –4 –3 –3 –2 –2 –1 –1... -
Page 67: Part Viii Midi Implementation Notation
Part VIII 28.2 Binary Notation When a MIDI implementation data value is expressed in MIDI Implementation binary, the letter “B” (for “binary”) is affixed at the end of the value. The table below shows the binary equivalents for Notation the decimal values 0 through 127, which are often used for settings. - Page 68 CASIO COMPUTER CO.,LTD. 6-2, Hon-machi 1-chome Shibuya-ku, Tokyo 151-8543, Japan MA1007-A...
