OWNER'S MANUAL
37" WIDE TFT LCD TELEVISION
WITH DIGITAL TUNER
HDLCD3700C
If you purchase a universal remote control from your local retailer, please contact the remote manufac-
turer for the required programming code.
When shipped from the factory, the Signal Type option is set to the "Cable" (Cable Television) mode. If
not using Cable TV, set this menu option to the "Air" position.
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
Before operating the unit, please read this manual thoroughly.
ATTENTION
Air/Cable MODE SELECTION
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
www.orionsalesinc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDLCD3700C and is the answer not in the manual?

Questions and answers

Related Manuals for Sansui HDLCD3700C

Summary of Contents for Sansui HDLCD3700C

  • Page 1 OWNER’S MANUAL 37" WIDE TFT LCD TELEVISION WITH DIGITAL TUNER HDLCD3700C ATTENTION If you purchase a universal remote control from your local retailer, please contact the remote manufac- turer for the required programming code. Air/Cable MODE SELECTION When shipped from the factory, the Signal Type option is set to the “Cable” (Cable Television) mode. If not using Cable TV, set this menu option to the “Air”...

  • Page 2: Location Of The Required Marking

    The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock. CAUTION: TO REDUCE THE RISK OF ELECTRIC The exclamation point within an...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a clean dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS 19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

  • Page 5: Safety Precautions

    IMPORTANT SAFETY INSTRUCTIONS CONDENSATION Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired.

  • Page 6: Table Of Contents

    Contents PREPARATIONS IMPORTANT SAFETY INSTRUCTIONS ........3 SAFETY PRECAUTIONS .............. 5 Contents ..................6 Features ..................7 Power source ................. 7 Parts and functions ................ 8 Remote control ................9 Antenna connections ..............10 Cable TV connections ..............11 Connections to other equipment ..........12 Setting the language ..............

  • Page 7: Features

    Features • Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box. • Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for hearing impaired viewers. •...

  • Page 8: Parts And Functions

    Parts and functions Front Right side CHANNEL ▲/▼ buttons VOLUME +/– buttons MENU button INPUT button POWER button Remote sensor POWER indicator Red: Standby Green: On (It alternately blinks to red and green while starting.) Left side RF (ANT) IN jack VAR (VARIABLE) AUDIO OUT jacks COAXIAL DIGITAL AUDIO OUT jack HDMI-2 IN jack...

  • Page 9: Remote Control

    Remote control 6.CH (CHANNEL) + / – / CURSOR ▲ / ▼ Buttons - Used to operate the menu functions of the LCD TV, and to change the channels of the LCD TV. 7.MENU Button - Use to display the On-Screen menu function.

  • Page 10: Antenna Connections

    Antenna connections If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see page 11 for Cable TV connections. Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire) Connect the 75 ohm cable from the combination Antenna VHF/UHF antenna to the antenna jack.

  • Page 11: Cable Tv Connections

    Cable TV connections This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

  • Page 12: Connections To Other Equipment

    Connections to other equipment The exact arrangement you use to interconnect various video and audio components to the LCD TV is dependent on the model and features of each component. Check the Owner’s Manual provided with each component for the location of video and audio inputs and outputs. The connection diagrams below are offered as suggestions.
  • Page 13 Connections to other equipment To connect the LCD TV to a DVD player /Satellite receiver If your DVD player or Satellite receiver has a S-Video out jack, connect cords as shown. Left side of the LCD TV To S-VIDEO IN To S-Video OUT S-Video cord (not supplied) Audio cord (not supplied)
  • Page 14 Connections to other equipment To connect the LCD TV to a DTV receiver/set-top box If you connect a DTV receiver/set-top box, connect your LCD TV to a DTV receiver/set-top box using a component video cord. Left side of the LCD TV To AV2 AUDIO (L/R) IN To Audio OUT Audio cord (not supplied)
  • Page 15 Connections to other equipment To connect the LCD TV to a Game or a Camcorder The LCD TV can also be used as a TV device for many video games or camcorders. However, due to the wide variety of signals generated by these devices and subsequent hook-up variations required, they have not all been included in the suggested connection diagrams.
  • Page 16 Connections to other equipment To connect an audio system This connection allows you to use an audio amplifier and external speakers, and adjust the audio level using the TV’s remote control. To control the audio, turn on the TV and the stereo amplifier, and turn off the TV’s built-in speakers (see “Turning off the built-in speakers”...

  • Page 17: Setting The Language

    Setting the language Auto Ch Memory Signal Type Cable Automatic Search Start You can choose from three different languages (English, French and Spanish) for the on-screen displays. Select the language you prefer first, then : Select : Adjust proceed with the other menu options. Press EXIT to return to the normal screen.

  • Page 18: Tv Operation

    Adding Channel Add/Delete If you find a new channel unregistered, you can add Adding Channel >> the new channel into the channel memory. Add/Delete >> Clear All >> Tune in the new channel. Press MENU. The menu screen will appear. : Select ENTER:Set Press EXIT to return to the normal screen.

  • Page 19: Labeling Channels

    RECALL NOTE: • If a channel with no broadcast is selected, the This button allows you to go back to the last channel sound will automatically be muted. selected by pressing RECALL. Press RECALL again • It may take a few seconds for a digital channel to return to the last channel you were watching.

  • Page 20: Labeling Video Inputs

    To register a password , () @ / + = - Press MENU. The menu screen will appear. SPACE Press ▲ or ▼ to select “Lock”, then press ▶ or If the character which you desire appears, press ENTER. ENTER. Select and enter your password (4 digits) using Repeat this step to enter the rest of the Number buttons (0-9), then press ENTER.

  • Page 21: Closed Caption

    Movie Rating If the TV is not storing the additional rating system, the TV will begin downloading it, which may take some time to be completed. Movie Rating Set your preferred content rating limits for the PG-13 additional rating system. NC-17 You also need “Update”...

  • Page 22: Cc Advanced

    Press ▲ or ▼ to select “Closed Caption”, then Press ▲ or ▼ to select “Analog Caption” or “Digital press ▶ or ENTER. Caption”. The Closed Caption menu will appear. When you select “Analog Caption”, you can Press ▲ or ▼ to select “Digital CC Preset”, then choose C1, C2, C3, C4, T1, T2, T3 and T4.

  • Page 23: Picture Control Adjustment

    Mode Picture Quality Press ▲ or ▼ to select “Picture Setting”, then press ▶ or ENTER. Sports Bright and dynamic picture (factory-set) The Picture Setting menu will appear. Standard Standard picture quality (factory-set) Press ▲ or ▼ to select “Color Temperature”, then Movie Movie-like picture setting (factory-set) press ◀...

  • Page 24: Film Mode

    Film Mode Cinema Wide1 picture size (for 4:3 format programs) To fill the screen, the right and left edges are A smoother motion may be obtained by setting extended, the Film Mode to “On” when you view a DVD from however;...

  • Page 25: Dnr

    Selecting Stereo/Second After adjusting, press ENTER to return to the PC Setting menu. Then continue to adjust the other Audio Program (SAP) items. Press EXIT to return to the normal screen. The multi-channel TV sound (MTS) feature provides high-fidelity stereo sound. MTS also NOTE: can transmit a second audio program (SAP) containing a second language or other audio...

  • Page 26: Selecting The Hdmi Audio Input Source

    Selecting the HDMI Setup audio input source Closed Caption >> Language English Video Label >> Backlight Auto Shut Off Reset >> When you use PC/HDMI-1 AUDIO IN jacks with HDMI or DVI device, you must select HDMI audio : Select : Adjust Press ◀...

  • Page 27: Reception Disturbances

    Reception disturbances Most types of television interference can be remedied by adjusting the height and position of the VHF/ UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

  • Page 28: Troubleshooting

    Troubleshooting Use the following checklist for troubleshooting if you have problems with your LCD TV. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POSSIBLE SOLUTIONS SYMPTOMS POSSIBLE SOLUTIONS •...

  • Page 29: Specifications

    Specifications Power supply: AC 120 V 60 Hz Power consumption: Operation: 175 W Stand by: 1 W Weight: 50.7 lbs (23.0 kg) Dimensions: Width: 37-3/8 inches (949 mm) Height: 27-3/8 inches (695 mm) Depth: 13-1/16 inches (332.5 mm) Inputs: VIDEO: 1 V (p-p)/75 ohms AUDIO: –8 dBm/50k ohms...
