OWNER'S MANUAL
32" WIDE TFT LCD TELEVISION
WITH DIGITAL TUNER
HDLCD3200B
If you purchase a universal remote control from your local retailer, please contact the remote manufac-
turer for the required programming code.
When shipped from the factory, the Tuning Band menu option is set to the "Cable" (Cable Television)
mode. If not using Cable TV, set this menu option to the "Air" position.
PLEASE HAVE THE MODEL NUMBER READY PRIOR TO THE CALL
FOR INFORMATION ON OUR OTHER PRODUCTS, PLEASE VISIT OUR WEBSITE AT
Before operating the unit, please read this manual thoroughly.
ATTENTION
Air/Cable MODE SELECTION
IF CONTACT WITH CUSTOMER SERVICE IS REQUIRED
CUSTOMER SERVICE – 1-800-289-0980
ORION WEBSITE
www.orionsalesinc.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the HDLCD3200B and is the answer not in the manual?

Questions and answers

Related Manuals for Sansui HDLCD3200B

Summary of Contents for Sansui HDLCD3200B

  • Page 1 OWNER’S MANUAL 32" WIDE TFT LCD TELEVISION WITH DIGITAL TUNER HDLCD3200B ATTENTION If you purchase a universal remote control from your local retailer, please contact the remote manufac- turer for the required programming code. Air/Cable MODE SELECTION When shipped from the factory, the Tuning Band menu option is set to the “Cable” (Cable Television) mode.

  • Page 2: Location Of The Required Marking

    The lightning flash with arrowhead symbol, within an equilateral triangle is intended to alert the user to the presence of uninsulated dangerous voltage within the product's enclosure that may be of sufficient magnitude to constitute a risk of electric shock. CAUTION: TO REDUCE THE RISK OF ELECTRIC The exclamation point within an...

  • Page 3: Important Safety Instructions

    IMPORTANT SAFETY INSTRUCTIONS 1) Read these instructions. 2) Keep these instructions. 3) Heed all warnings. 4) Follow all instructions. 5) Do not use this apparatus near water. 6) Clean only with a clean dry cloth. 7) Do not block any ventilation openings. Install in accordance with the manufacturer's instructions. 8) Do not install near any heat sources such as radiators, heat registers, stoves, or other apparatus (including amplifiers) that produce heat.
  • Page 4 IMPORTANT SAFETY INSTRUCTIONS 19) If an outside antenna or cable system is connected to the unit, be sure the antenna or cable system is grounded to provide some protection against voltage surges and built-up static charges, Section 810 of the National Electrical Code, ANSI/NFPA 70, provides information with respect to proper grounding of the mast and supporting structure, grounding of the lead-in wire to an antenna discharge unit, size of grounding conductors, location of antenna discharge unit, connection to grounding electrodes, and requirements for the grounding electrode.

  • Page 5: Safety Precautions

    IMPORTANT SAFETY INSTRUCTIONS CONDENSATION Moisture will form in the operating section of the player if the player is brought from cool surroundings into a warm room or if the temperature of the room rises suddenly. When this happens, player's performance will be impaired.

  • Page 6: Table Of Contents

    Contents PREPARATIONS IMPORTANT SAFETY INSTRUCTIONS ........3 SAFETY PRECAUTIONS .............. 5 Contents ..................6 Features ..................7 Power source ................. 7 Parts and functions ................ 8 Remote control ................9 Antenna connections ..............10 Cable TV connections ..............11 Connections to other equipment ..........12 Setting the language ..............

  • Page 7: Features

    Features • Integrated Digital Tuner - You can view digital broadcasts without using a Digital TV Set-Top Box. • Closed Caption Decoder With Full Text Mode - Displays text captions or full screen text on the screen for hearing impaired viewers. •...

  • Page 8: Parts And Functions

    Parts and functions MENU button To display the menu screen. CHANNEL ▲/▼ buttons Press MENU button to display the menu INPUT button VOLUME +/– buttons screen. POWER button CHANNEL ▲/▼ buttons and VOLUME +/– buttons can be used to select the desired setting during the menu screen operations.

  • Page 9: Remote Control

    Remote control 6.CH (CHANNEL) + / – / CURSOR ▲ / ▼ Buttons - Used to operate the menu functions of the LCD TV, and to change the channels of the LCD TV. 7.MENU Button - Use to display the On-Screen menu function.

  • Page 10: Antenna Connections

    Antenna connections If you are using an indoor or outdoor antenna, follow the instructions below that correspond to your antenna system. If you are using a Cable TV service, see page 11 for Cable TV connections. Combination VHF/UHF Antenna (Single 75 ohm cable or 300 ohm twin-lead wire) Connect the 75 ohm cable from the combination VHF/UHF antenna to the antenna jack.

  • Page 11: Cable Tv Connections

    Cable TV connections This TV has an extended tuning range and can tune most cable channels without using a Cable TV Converter box. Some cable companies offer “premium pay channels” where the signal is scrambled. Descrambling these signals for normal viewing requires the use of a descrambler device which is generally provided by the Cable TV company.

  • Page 12: Connections To Other Equipment

    Connections to other equipment The exact arrangement you use to interconnect various video and audio components to the LCD TV is dependent on the model and features of each component. Check the Owner’s Manual provided with each component for the location of video and audio inputs and outputs. The connection diagrams below are offered as suggestions.
  • Page 13 Connections to other equipment To connect the LCD TV to a DVD player /Satellite receiver If your DVD player or Satellite receiver has a S-Video out jack, connect cords as shown. Rear of the LCD TV To S-VIDEO IN To S-Video OUT S-Video cord (not supplied) Audio cord (not supplied) To AV1 AUDIO (L/R) IN...
  • Page 14 Connections to other equipment To connect the LCD TV to a DTV receiver/set-top box If you connect a DTV receiver/set-top box, connect your LCD TV to a DTV receiver/set-top box using a component video cord. Left side of the LCD TV To COMPONENT IN To Component OUT Video cord (not supplied)
  • Page 15 Connections to other equipment To connect the LCD TV to a Game or a Camcorder The LCD TV can also be used as a TV device for many video games or camcorders. However, due to the wide variety of signals generated by these devices and subsequent hook-up variations required, they have not all been included in the suggested connection diagrams.
  • Page 16 Connections to other equipment To connect the LCD TV to a PC (Personal Computer) Before you connect this LCD TV to your PC, change the adjustment of your PC’s Resolution and Refresh rate (60 Hz). Connect one end of a (male to male) VGA cable to the video card of the computer and the other end to the VGA connector PC MONITOR on the back of the LCD TV.

  • Page 17: Setting The Language

    Setting the language Press ▶ or ENTER to select “Air” or “Cable”. Air - VHF/UHF channels You can choose from three different languages Cable - CABLE TV channels (English, French and Spanish) for the on-screen displays. Select the language you prefer first, then Tuning Band Picture DTV Signal...

  • Page 18: Tv Operation

    Adjust the volume level by pressing VOL + or – . Tuning Band Cable Picture The volume level will be indicated on the screen DTV Signal Auto Ch Search by white bars. As the volume level increases, so Add On Ch Search Audio do the number of bars.

  • Page 19: Labeling Channels

    CH +/– SLEEP Press and release CH+/–. The channel automatically The sleep timer allows you to set a time when the stops at the next channel set into memory. LCD TV automatically switches to standby. For proper operation, before selecting channels, they Press MENU.

  • Page 20: Setting The V-Chip

    To set the V-Chip Channel Labels Menu Ch 23-0 - - - - - - - Press MENU. Press ▲ or ▼ to select “Feature” menu, then To Move Enter To Change Menu To Exit press ▶. The characters rotation as follows: Press ▲...

  • Page 21: Closed Caption

    To change the password • The standard V-Chip rating system is available whether your TV is receiving a digital signal or not, Press MENU. The TV menu s creen will appear. and will block both analog and digital programs. To set the restriction level using the standard V-Chip Press ▲...

  • Page 22: Cc Advanced

    NOTE: Text Opacity: Transparent, Translucent, Solid, • If the program or video you selected is not closed- Flashing captioned, no captions will display on-screen. Background Red, Green, Blue, Yellow, Magenta, • If text is not available in your viewing area, a black Color: Cyan, Black, White rectangle may appear on-screen.

  • Page 23: Adjusting The Picture Preference

    Picture Mode Standard Picture Contrast Brightness Sharpness Audio Color Tint Setup Picture Size Wide A B C D E F G - - - - - - - - - - - - - - - - A B C D E F G - - - - - - - - - - - - - - - - - - - - - - - - - - Feature To Move To Select...

  • Page 24: Dnr

    Press MENU. Then press ▲ or ▼ to select “Feature” menu, then press ▶. DNR (Digital Noise Reduction) can reduce the Press ▲ or ▼ to select “Advanced Video Menu”, roughness of the picture. then press ▶ or ENTER. Press MENU. Then press ▲ or ▼ to select Press ▲...

  • Page 25: Sound Control Adjustment

    Sound control Press MENU. Then press ▲ or ▼ to select “Audio” menu, then press ▶. adjustment Press ▲ or ▼ to select “Digital Audio Output”, then press ▶ or ENTER to select “PCM” or “RAW”. Press MENU. Then press ▲ or ▼ to select “Audio” menu, then press ▶.

  • Page 26: Picture Control Adjustment In The Component And Pc Mode

    NOTE: Press ▶ or ENTER to return your settings to the • If no buttons are pressed for more than approx. 30 factory settings. seconds, the Menu-screen will return to normal Monitor-screen automatically. Press MENU to return to the normal screen. •...

  • Page 27: Reception Disturbances

    Reception disturbances Most types of television interference can be remedied by adjusting the height and position of the VHF/ UHF antenna. Outdoor antennas are recommended for best results. The most common types of television interference are shown below. If one of these symptoms appear when the TV is connected to a Cable TV system, the disturbance may be caused by the local Cable TV company broadcast.

  • Page 28: Troubleshooting

    Troubleshooting Use the following checklist for troubleshooting if you have problems with your LCD TV. Consult your local dealer or service outlet if problems persist. Be sure all connections are properly made when using with other units. SYMPTOMS POSSIBLE SOLUTIONS SYMPTOMS POSSIBLE SOLUTIONS •...

  • Page 29: Specifications

    Specifications Power supply: AC 120 V 60 Hz Power consumption: Operation: 170 W Stand by: 1 W Weight: 31.1 lbs (14.1 kg) Dimensions: Width: 32-3/8 inches (822 mm) Height: 23-3/4 inches (604 mm) Depth: 11-1/8 inches (282.5 mm) Inputs: VIDEO: 1 V (p-p)/75 ohms AUDIO: –8 dBm/50k ohms...

  • Page 30: Limited Warranty

    LIMITED WARRANTY 32” WIDE LCD TELEVISION ORION warrants this product to be free from manufacturing defects in material and workmanship under normal use and conditions for a period of 1 year from date of original purchase in the United States. Should service be necessary under this warranty for any reason due to a manufacturing defect or malfunc- tion during the first 12 months from date of original purchase, ORION will provide in-home repair service by an ORION authorized Independent Service Center at no charge.
  • Page 32 J34K0101A SH 07/10...
