P.O. BOX 212378
AUGUSTA, GA 30917
Product No.
FRS6LR5EB2 FRS6LR5EQ2 FRS6LR5ES2 FRS6LR5EW2
Series
R134a
Color
black
Volts
115
Wiring Diagram
241526901
Owner's Guide
241695300
Market
North America North America North America North America
Energy Guide
241649212
Service Data Sheet 240389616
Publication No.
5995459186
06/01/20
(EN/SERVICE/KHB)
R134a
R134a
R134a
bisque
stainless
white
115
115
115
241526901
241526901
241526901
241695300
241695300
241695300
241649212
241649212
241649212
240389616
240389616
240389616
SIDE-BY-SIDE
REFRIGERATOR
Model No.
FRS6LR5E
137
©
Copyright
All rights reserved.

Advertisement

Table of Contents
loading

Related Manuals for Frigidaire FRS6LR5E

Summary of Contents for Frigidaire FRS6LR5E

  • Page 1 Product No. FRS6LR5EB2 FRS6LR5EQ2 FRS6LR5ES2 FRS6LR5EW2 Series R134a R134a R134a R134a Color black bisque stainless white Volts Wiring Diagram 241526901 241526901 241526901 241526901 Owner's Guide 241695300 241695300 241695300 241695300 Market North America North America North America North America Energy Guide 241649212 241649212 241649212...

  • Page 2: Freezer Door

    Publication No: 5995459186 FRS6LR5E FREEZER DOOR N58FCCBBB2 01/06...
  • Page 3 FRS6LR5E Publication No: 5995459186 FREEZER DOOR Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 241674806 A - C - Gasket-frzr door, black, magnetic 241674802 - B - D Gasket-frzr door, white, magnetic 240334201 A B C D Bin-door, frzr-upper...

  • Page 4: Refrigerator Door

    Publication No: 5995459186 FRS6LR5E REFRIGERATOR DOOR N58RCCBBB5 01/06...
  • Page 5 FRS6LR5E Publication No: 5995459186 REFRIGERATOR DOOR Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 241674805 A - C - Gasket-refr door, black, magnetic 241674801 - B - D Gasket-refr door, white, magnetic 240323001 A B C D Bin-door, pseudo, bottom...
  • Page 6 Publication No: 5995459186 FRS6LR5E CABINET 01/06...
  • Page 7 FRS6LR5E Publication No: 5995459186 CABINET Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 240435906 A B C D Cover-air duct 240475907 A B C D Cover-evap coil, lower 5303208309 A B C D Plug-hole, factory test 240505801...
  • Page 8 Publication No: 5995459186 FRS6LR5E SHELVES N58SJCAAB12 01/06...
  • Page 9 FRS6LR5E Publication No: 5995459186 SHELVES Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 241657602 A B C D Shelf, flip up, wire 241657502 A B C D Shelf, fixed, freezer 241657504 A B C D Shelf, fixed, upper, freezer...
  • Page 10 Publication No: 5995459186 FRS6LR5E CONTROLS N58TAAAAA6 01/06...
  • Page 11 FRS6LR5E Publication No: 5995459186 CONTROLS Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 5308000010 A B C D Fan Blade, red, evaporator fan 215474201 A B C D Washer, "slinger", nylon, evap fan shaft 241563601 A B C D Bushing-motor mtg, (2)
  • Page 12 Publication No: 5995459186 FRS6LR5E SYSTEM N58CAAAAC1 01/06...
  • Page 13 FRS6LR5E Publication No: 5995459186 SYSTEM Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 240333603 A B C D Condenser 218679607 A B C D Block-evap coil, styrofoam, (2) 218944001 A B C D Drier-filter, R134a System 241586801...

  • Page 14: Ice And Water Dispenser

    Publication No: 5995459186 FRS6LR5E ICE & WATER DISPENSER 01/06...
  • Page 15 FRS6LR5E Publication No: 5995459186 ICE & WATER DISPENSER Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube-water-DOOR 218976901 A B C D Tube-water inlet, inlet valve, to ice maker 218976904 A B C D Tube-water inlet, valve to filter...

  • Page 16: Ice Container

    Publication No: 5995459186 FRS6LR5E ICE CONTAINER 01/06...
  • Page 17 FRS6LR5E Publication No: 5995459186 ICE CONTAINER Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 5304428402 A B C D Auger-ice 5304404343 A B C D Cam-drive 218815300 A B C D Container-ice, bucket only 5304404346 A B C D...

  • Page 18: Ice Maker

    Publication No: 5995459186 FRS6LR5E ICE MAKER 01/06...
  • Page 19 FRS6LR5E Publication No: 5995459186 ICE MAKER Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 218976409 A B C D Tube-water-DOOR 218976901 A B C D Tube-water inlet, inlet valve, to ice maker 218976904 A B C D Tube-water inlet, valve to filter...
  • Page 20 Publication No: 5995459186 FRS6LR5E ICE MAKER 01/06...
  • Page 21 FRS6LR5E Publication No: 5995459186 ICE MAKER Model Index: A FRS6LR5E (FRS6LR5EB2) B FRS6LR5E (FRS6LR5EQ2) C FRS6LR5E (FRS6LR5ES2) D FRS6LR5E (FRS6LR5EW2) POS. NO PART NO. DESCRIPTION 55 # 240531101 A B C D Valve-water, triple solenoid 218709100 A B C D Screw, hex head, 10-32 x 0.500 240363601 A B C D...

  • Page 22: Wiring Schematic

    Publication No: 5995459186 FRS6LR5E WIRING SCHEMATIC 01/06...

  • Page 23: Wiring Diagram

    FRS6LR5E Publication No: 5995459186 WIRING DIAGRAM 01/06 # Functional Parts * Non-Illustrated Parts...
