S i d e - b y - S i d e
Refrigerator
Use & Care Guide
Important Safety Instructions . . . . . . . . . . . . . . . . . . . . . . . 1-2
Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3-6
Temperature Controls . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 7-9
Fresh Food Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10-12
Freezer Features . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Ice and Water . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14-15
Water Filter . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16-17
Food Storage Tips . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
Care and Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 19-22
Operating Sounds . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24-27
Guía de uso y cuidado en español . . . . . . . . . . . . . . . . . 28-55
Guide d'utilisation et d'entretien français . . . . . . . . . . . 56-83
Benutzungs- und Pflegeanleitungen - Deutsch . . . . 84-111
Italiano - Guida all'uso e alla manutenzione . . . . . . 112-139
∂ÏÏËÓÈΤ˜ Ô‰ËÁ›Â˜ ¯Ú‹Û˘ Î·È ÊÚÔÓÙ›‰·˜ . . . . . . . . 140-167
Guia de Uso e Cuidado em Português . . . . . . . . . . . .168-195
Nederlandse gebruiks- en onderhoudshandleiding .196-223
Dansk betjeningsvejledning . . . . . . . . . . . . . . . . . . . . 224-251
Svensk manual . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .252-279
Suomenkielinen käyttö- ja huolto-ohje . . . . . . . . . . 280-307
Norsk bruks- og vedlikeholdsanvisning
. . . . . . . . . 308-335
Türkçe Kullanım ve Bakım Kılavuzu . . . . . . . . . . . . . .336-363
Part No. 12842119
Litho U.S.A.

Advertisement

Table of Contents
loading

Related Manuals for Caple CAFF22

Summary of Contents for Caple CAFF22

  • Page 1: Table Of Contents

    S i d e - b y - S i d e Refrigerator Use & Care Guide Important Safety Instructions ..... . . 1-2 Installation .

  • Page 2: Important Safety Instructions

    Important Safety Instructions Recognize Safety Symbols, Words, Installer: Please leave this guide with this appliance. Labels Consumer: Please read and keep this Use & Care Guide for future reference. This guide provides DANGER proper use and maintenance information. DANGER – Immediate hazards which WILL result Keep sales receipt and/or cancelled check as proof in severe personal injury or death.
  • Page 3 Important Safety Instructions WARNING To reduce risk of fire, electric shock, serious injury or 13. Install refrigerator according to Installation death when using your refrigerator, follow these basic Instructions. All connections for water, electrical precautions, including the following: power and earthing must comply with local codes and be made by licensed personnel when required.

  • Page 4: Installation

    Installation Transporting Your Refrigerator WARNING To be done by a qualified engineer only. • NEVER transport refrigerator on its side. If an upright position is not possible, lay refrigerator on its Location back. Allow refrigerator to sit upright for approximately 30 minutes before plugging it in to •...

  • Page 5: Handle Installation

    Installation Handle Installation 4. Rotate the handle so that the handle is flat against the door. If not installed, the handle is located in the interior of 5. Push the handle down against the the fresh food section or attached to the back of your upper door tab just enough to allow refrigerator.
  • Page 6 Installation Full-Length Aluminum Handles 6 mm Panel Dimensions: Extended Door Models Panel Height Panel Width To Install: Fresh Food Door 169.5 cm 48.1 cm 1. Release top door trim by removing Phillips Ice n’ water upper freezer door 46.0 cm 35.4 cm screws from top of fresh food door and Ice n’...
  • Page 7 Installation 4. Select models also have rear adjustment screws (B). Using Leveling the hex head driver, turn each of these adjustment screws CAUTION (B) to raise or lower the rear of the refrigerator. To protect personal property and refrigerator from 5.

  • Page 8: Temperature Controls

    Temperature Controls Touch Temperature Controls Temperature Control Guide Set the refrigerator control Refrigerator too warm (select models, style varies by model) to next higher number by The controls are located at the top front of the pressing the pad. refrigerator compartment. Refrigerator too cold Set the refrigerator control to next lower number by...
  • Page 9 Temperature Controls adjust the control as indicated in the Temperature rated has passed through the filter OR 11 months have Control Guide below. elapsed since the filter has been installed. • The first touch of the pads The red Replace light will illuminate when the rated shows the current temperature setting.
  • Page 10 Temperature Controls appear in the Freezer temperature display and the Door Alarm feature status will appear in the Fresh Food display. The Door Alarm will alert you when one of the doors has been left open for five continuous minutes. 1.

  • Page 11: Fresh Food Features

    Fresh Food Features Shelves To Slide Out Elevator™ Shelf: • Grasp the front of the shelf and pull forward. CAUTION • Push the shelf in to return to original position. To avoid personal injury or property damage, To Adjust the Elevator™ Shelf: observe the following: •...

  • Page 12: Door Storage

    Fresh Food Features Door Storage To Remove: • Slide dairy center up and pull out. Beverage Chiller™/MiniChiller™ To Install: (select models) • Slide assembly in and down so that the hooks are The Beverage Chiller™ and firmly seated on the door liner. MiniChiller™...

  • Page 13: Storage Drawers

    Fresh Food Features Storage Drawers Accessories Humidity-Controlled Crisper Drawers Grip Pads (select models) The Crisper Drawers provide a higher humidity The Grip Pads prevent objects from environment for fresh fruit and vegetable storage. sliding in the door buckets. Grip Pads are removable and are top-rack Controls dishwasher safe for easy cleaning.

  • Page 14: Freezer Features

    Freezer Features Shelves and Baskets Door Storage Fixed Freezer Shelf Adjustable Door Buckets To Remove Clip-mounted Shelves: Door Buckets can be moved to meet individual storage needs. • Lift shelf from wall mounting clips and pull left side of shelf out of wall mounting holes. To Remove: To Install Clip-mounted Shelves: •...

  • Page 15: Ice And Water

    Ice and Water Dispenser Features Water Dispenser Operation (select models) CAUTION To avoid personal injury or property damage, observe the following: • Do not put fingers, hands or any foreign object into dispenser opening. • Do not use sharp objects to break ice. •...
  • Page 16 Ice and Water Dispenser Control Auto Light (select models) (select models) (control features vary by model) The Auto Light function activates the dispenser light at half-power when the Light Ice Dispenser Operation Sensor detects that the light levels in room are low. To Dispense Ice: To Activate Auto Light: •...

  • Page 17: Water Filter

    Water Filter Water Filter Removal and Replacing Water Filter Installation (select models) IMPORTANT: Air trapped in system may cause water and cartridge to eject. Use caution when removing. WARNING 1. Turn filter counterclockwise until it releases from To avoid serious illness or death, do not use filter head.

  • Page 18: Specifications

    Water Filter System Specification and Performance Data Sheet Refrigerator Water Filter Cartridge Specifications Service Flow Rate (Maximum)..........0.78 GPM (2.9 L/min) Rated Service Life 750 (Maximum) ........750 gallons/2838 liters Maximum Operating Temperature ........100° F / 38° C Minimum Pressure Requirement........35 psi / 241 kPA Minimum Operating Temperature ........33°...

  • Page 19: Food Storage Tips

    Food Storage Tips Fresh Food Storage Frozen Food Storage • The fresh food compartment of a refrigerator should • The freezer compartment of a refrigerator should be be kept between 1°-4° C with an optimum kept at approximately -18° C. To check the temperature of 3°...

  • Page 20: Care And Cleaning

    Care and Cleaning WARNING CAUTION To avoid electrical shock which can cause severe To avoid personal injury or property damage, personal injury or death, disconnect power to observe the following: refrigerator before cleaning. After cleaning, connect • Read and follow manufacturer’s directions for all power.

  • Page 21: Removing Odors From Refrigerator

    Care and Cleaning Removing Odors From Energy Saving Tips Refrigerator • Avoid overcrowding refrigerator shelves. This reduces air circulation around food and causes refrigerator to WARNING run longer. To avoid electrical shock which can cause severe • Avoid adding too much warm food to refrigerator at personal injury or death, disconnect power to one time.

  • Page 22: Replacing Light Bulbs

    Care and Cleaning Replacing Light Bulbs Upper Freezer Section 1. Remove ice bin by WARNING lifting front of bin and To avoid electrical shock which can cause severe pulling out. personal injury or death, disconnect power to 2. Remove light shield by refrigerator before replacing light bulb.

  • Page 23: Preparing For Vacation

    Care and Cleaning Preparing for Vacation Upon Your Return: After a Short Vacation or Absence: CAUTION For models with automatic ice makers or dispensers: If your refrigerator has a dispenser and there is any • Reconnect the water supply and turn on supply valve possibility that the temperature can drop below (see page 3).

  • Page 24: Operating Sounds

    Operating Sounds Improvements in refrigeration design may produce sounds in your new refrigerator that are different or were not present in an older model. These improvements were made to create a refrigerator that is better at preserving food, is more energy efficient, and is quieter overall. Because new units run quieter, sounds may be detected that were present in older units, but were masked by higher sound levels.

  • Page 25: Troubleshooting

    Troubleshooting PROBLEM POSSIBLE CAUSES WHAT TO DO Freezer control and Refrigerator is in defrost mode. Normal operation. lights are on, but Wait 40 minutes to see if refrigerator restarts. compressor is not operating Temperature- Control settings are too low. See page to adjust controls.
  • Page 26 Troubleshooting PROBLEM POSSIBLE CAUSES WHAT TO DO Door is not closing properly. Check for internal obstructions that are keeping door Water droplets from closing properly (i.e. improperly closed drawers, form on outside ice buckets, oversized or improperly stored containers, of refrigerator etc.) See page 6 Leveling.
  • Page 27 Troubleshooting Ice and Water PROBLEM POSSIBLE CAUSES WHAT TO DO Freezer door is not closed. Verify that freezer door is closed. Power is removed No indicator lights are lit on dispenser from the control when freezer door is opened. control Refrigerator is not plugged in.
  • Page 28 Troubleshooting PROBLEM POSSIBLE CAUSES WHAT TO DO Water pressure is low. Water pressure must be between 241 to 689 kpa to Ice forms in inlet function properly. tube to ice maker A minimum pressure of 241 kpa is recommended for refrigerators with water filters.
