Related Manuals for Caple CAFF20
Summary of Contents for Caple CAFF20
- Page 1 Instruction manual for side by side fridge freezer Model code: CAFF20 Contact Caple on 0844 800 3830 or for spare parts www.4caple.co.uk...
-
Page 2: Table Of Contents
Refrigerator - Freezer Thank you for your trust and for buying this appliance. We hope it will successfully serve the purpose for many years. Refrigerator with freezer is for domestic use The left part is freezer and is used for freezing only. -
Page 3: We Care For The Environment
• When your appliance finally wears out, • Use higher temperature settings only when please try not to burden the environment with required or recommended. it; call your nearest authorised service agent. • Before loading the appliance with packages (See Disposing of the Worn Out Appliance). of fresh foods, make sure they are cooled to ambient temperature. -
Page 4: Storing Time During Power Supply
Storing Time During Power Supply break it, in order to prevent eventual accidents (danger of children becoming Interruption locked inside the appliance). • The refrigerating system of the appliance is Do not open the freezer in case of failure or filled with refrigerant and insulating power supply interruption! In case the substances which should be separately... -
Page 5: Decorative Plinth Installation
Decorative socle installation decorative plinth screw... -
Page 6: Description Of The Appliance
Description of the Appliance 1 Freezer door rack 2 Freezer compartment glass shelf 3 ice-maker box 4 Ice box 5 Freezer compartment drawer 6 Refrigerator compartment glass shelf 7 Refrigerator compartment small drawer 8 Vegetable crisper 9 Refrigerator door rack 10 Substance box 11 Lower plastic cover 12 air channel cover... - Page 7 1. Button operation 1. Freezer compartment adjustment button 2. Mode Settings 3. Refrigerator compartment temperature adjustment button. 4. Confirmation and lock/unlock button 2. Indicator lamp A. Frozen tchermostat Indicator lamp B. Mode selection Indicator lamp C.Refrigerator thermostat Indicator lamp D. Confirmation and lock/unlock button lamp 3.
- Page 8 The following functions must be in operation under the unlocked state 5. Intelligent mode Press 2 button to select Intelligent mode, the 11 icon shows,then press 4 button to confirm, the refrigerator will be running according to Intelligent mode. When Intelligent mode is on the temperature of the refrigerator compartment is set on 5 degree and freezer compartment is set on -18 degree.
- Page 9 12. Power failure memory function When the electricity is off, the instantaneous work state is locked, After the electricity is on, the Refrigerator recovers work state before power failure automatically . 13. Latency protection function With 5 minutes time-delay Circuit and procedures, The compressor’s running time intervals are not less than five minutes at any time.
- Page 10 the best areas different...
- Page 11 Store pasta, canned ,milk, etc. Store fast food, dairy products, etc. Store cooked meat and sausage, etc. Store fruits and vegetables, etc Wave Fresh Light function The light has a similar spectrum to that of sunlight. It will help fruit and vegetables to photosynthesis, helping food to keep the vitamin C and lengthen the storage time.
- Page 12 Freezer compartment 1. The storage grilles on the door of the freezer room are used for the storage of frozen food. 2. The storage grilles in the freezer room are used for the storage of frozen food . 3. The glass shelves are used for the storage of frozen foods, such as fish, meat and ice cream.
-
Page 13: Use
Storing Fresh Foods • Some organic solutions like volatile oils in lemon or orange peel, acid in butter etc. can Proper use of the appliance, adequately packed cause damages and when in contact with food, correct temperature and taking into plastic surfaces or gaskets for longer period account hygienic precautions will substantially of time. -
Page 14: Freezing Fresh Foods
Freezing Fresh Foods the quality of freezing is reduced which affects the quality of frozen foods. • Carefully select food you intend to freeze; it should be of adequate quality and suitable Storing Frozen Foods for freezing. • Use correct packaging and wrap it right. Packages of frozen foods are stored in the −... - Page 15 Defrosting of frozen foods Partially thawed or defrosted foods should be used as soon as possible. Cold air preserves the food but it does not destroy microorganisms which rapidly activate after defrosting and make foods perishable. Partial defrosting reduces the nutritional value of foods, especially of fruits, vegetables and ready-made meals.
-
Page 16: Maintenance And Cleaning
Maintenance and Cleaning Defrosting the NO FROST refrigerator cloth and an alcohol based cleaning agent (for example glass cleaners). You may also There is no need to defrost the refrigerator, use alcohol (ethanol or isoprophylic alcohol). because ice depositing on the inner back wall The application of abrasive and specially aggressive cleaners, such as the stainless is defrosted automatically. - Page 17 compressor is not operating, the refrigerant Sometimes unusual and stronger noise is flow is heard. This is a normal condition and heard, which is rather unusual for the it has no influence whatsoever on the lifetime appliance. This noise is often a consequence of the appliance.
- Page 18 Remove the plug and cut off power supply . Dismantle the lampshade downwards, following the direction of the arrow. Remove the lampshade. Unload the screw at the bottom of the lamp holder, and then replace the same specifications of the light bulbs. Follow these instructions in reverse to reassemble.
