- Page 1 Gas oven with electric grill C 270G/SS Model: Instruction Manual...
- Page 2 Thank you for buying your new CAPLE Built-in Oven. To ensure that you get the best results from your new CAPLE oven, we strongly suggest that you read this instruc- tion manual thoroughly before use. This manual contains installation advice, cleaning tips and a cooking guide, as well as other important facts about your CAPLE oven.
-
Page 3: Safety Reminders
It is therefore advisable to keep small children away from the appliance. CAPLE Service To ensure the continued safe and effi- cient operation of this appliance, we rec- ommend that any servicing or repairs are carried out only by an authorised CAPLE SERVICE ENGINEER. -
Page 4: Electrical Requirements
Electrical Requirements WARNING! ELECTRICITY CAN BE EXTREMELY DANGEROUS. THIS APPLIANCE MUST BE EARTHED. For your safety please read the following information: • This appliance must be installed by a qualified technician according with the current local regulations and in compliance with the manufacturer instructions. •... - Page 5 1 - Electrical Installation - Wall box connection This appliance must be connected to a DOUBLE POLE SWITCHED double pole isolating switch (fig. 1.1) and FUSED SPUR OUTLET to the terminal block in the cooker (figs. 1.2 & 1.3) using the following guide: 1) The wire which is coloured brown must be connected to the terminal marked L (Live), or coloured Red.
-
Page 6: For The Installer
FOR THE INSTALLER 2 - How To Install Your Oven Fig. 2.1- Built under You need the following housing area to fit your oven correctly. Dimensions Fig. 2.2- Built in Oven Housing (mm) Height Built in Built Under Width Depth min. - Page 7 Also ensure that the front rail at the top of the unit is not installed as it could restrict ventilation. If the oven is being built in to a kitchen unit (fig. 2.2) ensure that the oven is ventilated with a 50 mm space at the top of the kitchen unit. Failure to allow adequate ventilation to the appliance may result in over heating or dam- age to adjacent units.
-
Page 8: Gas Connection
3 - Gas connection GAS INSTALLATION GAS CONNECTION IMPORTANT NOTE The installation of the oven to Natural Gas or LP Gas must be carried out by This appliance is supplied for use on a qualified gas engineer. Installers shall NATURAL GAS only and cannot be used take due account of the provisions of the on any other gas without modification. - Page 9 This appliance is regulated to work with natural gas. If it has to work with another type of gas (L.P.G.), before the appliance is connected you must substitute the oven burner injector as follows: - Open the oven door completely. - Remove the burner cover (Fig.
- Page 10 TABLE FOR THE CHOICE OF THE INJECTORS Cat: 2H3+ G 30 - 28-30 mbar G 20 Nominal Reduced G 31 - 37 mbar 20 mbar BURNERS Power Power Ø injector By-pass Ø injector By-pass Ring opening Ring opening [kW] [kW] [mm] [1/100 mm] [1/100 mm]...
- Page 11 FLAMES REGULATION OF THE OVEN BURNER Because of different gas mixtures in the distribution system, you may have flames with too much or too little air. In such cases, loosen the screw and move the air ring to close or open the air flow, until the regular flame is obtained (fig. 3.5). Standard position of the air ring.
- Page 12 How To Use Your Gas Oven The rating plate can be found on the bottom right hand side of the inner door. Locate the wire side frames as indicated in Fig. 3.6. Slide in, on the guides, the shelf and the tray etc. (Fig. 3.7). Before using the oven for the first time, we recommend that you clean it with soapy water, rinse carefully and heat for 30 minutes at maximum temperature.
-
Page 13: How To Use Your Oven - Control Panel
4 - How To Use Your Oven - Control panel Fig. 4.1 Control panel Temperature Selector/lgnition Grill and Light Selector Timer LIGHTING OF OVEN BURNER The thermostatic tap controlling the gas supply to the burner is equipped with a safety device which automatically stops the gas flow in case of flame extinction. - Page 14 B. Grill and Light Selector LIGHT The light will switch on automatically while grilling and can be selected when using the oven. 1 - MAX Grill with the door closed. Set the temperature to the desired setting which can be varied between 1 and max. Before using the grill, pre-heat for about 5 minutes.
-
Page 15: Cooking Guide
Cooking guide Your gas oven is a newly designed oven which incorporates an indirect burner located under the oven base plate. If you have previously been used to cooking with gas you may need to slightly alter your cooking methods. The bottom of the oven is hot and is ideal for browning the underside of shallow pastry dishes and pizzas. - Page 16 Recommended cooking temperature APPROX. HEAT OF TYPE OF DISH TO COOK MARK TEMP. OVEN 125°C Very cool Meringue cakes, 257°F oven slow cooking items 140°C Cool Milk puddings, very rich fruit 275°F oven cakes, i.e., Christmas 150°C Cool or Stews, casseroles, braising, 300°F slow oven rich fruit cakes, i.e., Dundee...
-
Page 17: Cleaning And Maintenance
5 - Cleaning and Maintenance Before cleaning the oven switch it off and wait for it to cool down. Important: Before any operation of cleaning and maintenance disconnect the appliance from the electrical network. General Installation, and any demonstration, information or adjustments are not included in the warranty. - Page 18 Removal of the inner glass door panel The inner glass door panel can easily be removed for cleaning by unscrewing the two screws (figure 5.1). During re-assembly, ensure that the inner glass is correctly aligned and do not over tighten the screws. ATTENTION The appliance gets very hot, mainly around the cooking areas.
-
Page 19: Helpful Advice
Food cooked but not brown enough. all times. Remedy Increase temperature. If you are in any doubt call the CAPLE Helpline on 0870 241 1142. Problem Food baking unevenly. A charge will be made if the appliance is... -
Page 20: Your Guarantee
YOUR GUARANTEE CAPLE guarantees all parts of this product for one year from the date of pur- chase. During that time, should it become necessary CAPLE engineers will replace or repair all defective parts free of charge, except for parts subject to fair wear and tear, such as lightbulbs.
