  • Page 1 INFORMAZIONI COMMERCIALI PER I CONSUMATORI COMMERCIAL INFORMATION FOR THE CONSUMER INFORMATIONS COMMERCIALES POUR LE CLIENT INFORMACIONES COMERCIALES PARA EL CLIENTE HANDELSINFORMATIONEN FÜR DEN KUNDEN COMMERCIËLE INFORMATIES VOOR DE KLANT ISTRUZIONI PER L’USO S-DD2 INSTRUCTIONS FOR USE S-DD2 INSTRUCTIONS POUR L’EMPLOI S-DD2 ISTRUCCIÓNES DE USO S-DD2 BEDIENUNGSANLEITUNG S-DD2 GEBRUIKSAANWIJZIGING S-DD2...

  • Page 2: Table Of Contents

    CONTENTS 1/ TO THE ATTENTION OF THE USER - Safety instructions - Description of the applianc 2 / INSTALLING THE HOOD - Mounting the hood - Removal of the filter cartridge - Mounting the filter cartridge - Electrical hook-up of the hood 3 / HOW THE HOOD WORKS 4 / CLEANING THE HOOD 5 / OPERATIONAL ANOMALIES...

  • Page 3: 1/ To The Attention Of The User

    1/ TO THE ATTENTION OF THE USER Important: keep these instructions for use with the appliance. If the appliance should be sold or passed on to others, make sure that the instructions are passed on with it. We thank you for taking note of these suggestions before installing and using the appliance. They have been written for your personal safety and the safety of others.

  • Page 4: Description Of The Applianc

    1/ TO THE ATTENTION OF THE USER DESCRIPTION OF THE APPLIANCE...

  • Page 5: Installing The Hood

    2/ INSTALLING THE HOOD 1) Before installing the appliance, make sure that none of the parts is damaged in any way. In case of damaged parts, contact your retailer and do not proceed with installation. Read all of the following instructions with care before installing the appliance. - Use an air outlet pipe of the shortest possible length.

  • Page 6: Removal Of The Filter Cartridge

    either in the suction or filter versions. VERSION EVACUATION exterieure The hood is equipped with an air outlet (Fig. A FIGURE 1) to convey smoke outwards (the flue pipe and fixing flange are not supplied). Check valve blockage Warning: Before connecting the air exhaust hose, make sure that the check valves are free to turn over freely.

  • Page 7: Electrical Hook-Up Of The Hood 0

    - ELECTRIAL HOOK UP OF THE HOOD WARNING: The electronic board for the controls needs to be installed beneath the work top, close to the body of the hood and at a minimum distance of 65 cm from all substances or ducting for flammable substances (gas pipes or ducting for specific liquids) USEFUL ADVICE: We recommend fitting the electronic board at a height of at least 10 cm from the ground and at a suitable distance from all heat sources (e.g., the side of an oven...

  • Page 8: How The Hood Works

    3/ HOW THE HOOD WORKS Model S.DD2 STANDARD VERSION A: Extraction panel down/OFF switch This serves to close the extraction panel either completely or in intermediate positions above 180 mm from the cook top. When the extraction panel is being closed, it will remain in opera- tion until it reaches 180 mm above the cook top.
  • Page 9 Other functions: - After 0 hours of appliance operation, the pushbutton panel indicates saturation of the grease filters by the buttons flashing. To reset, press the timer button. - After  hours of continuous operation from the last setting, the appliance turns off and closes automatically.

  • Page 10: Cleaning The Hood

    4/ CLEANING THE HOOD Careful maintenance helps guarantee proper operation and good results from an appliance over time. The hood must be unplugged from the electrical power source, both by unplugging the appliance from the socket as well as de-activating the breaker, before removing the metal filters.

  • Page 11: Operational Anomalies

    5/ OPERATIONAL ANOMALIES SYMPTOM SOLUTION Check that: The hood does not • there is not a power outage. work... • a specific speed has actually been selected. Check that: • the motor speed selected is sufficient for the quantity of fumes The hood has low steam present.
