Upright Vacuum Cleaner

Owner's Guide
Household Type
Z5500 Series
IMPORTANT
For any advice
on your cleaner and
to order filters and
accessories,
please telephone the
Electrolux Helpline on
08706 055055
IMPORTANT INFORMATION
2 - 4
4
GUARANTEE
HOW TO ASSEMBLE
5 - 6
HOW TO USE
7 - 8
8
Thermal Cut Off
9
Accessories
10
ROUTINE MAINTENANCE
10
Hose Blockage
11 - 12
Brush Roll Brush Roll Belt
12 - 13
Dust Cup
14
PERIODIC MAINTENANCE
14
Filters
15
Problem Solving
Dust Cup Filter
www.electrolux.co.uk

Advertisement

Table of Contents
loading

Related Manuals for Electrolux Z5500 Series

Summary of Contents for Electrolux Z5500 Series

  • Page 1: Upright Vacuum Cleaner

    Upright Vacuum Cleaner Owner’s Guide Household Type Z5500 Series IMPORTANT For any advice on your cleaner and to order filters and accessories, please telephone the Electrolux Helpline on 08706 055055 IMPORTANT INFORMATION 2 - 4 GUARANTEE HOW TO ASSEMBLE 5 - 6...

  • Page 2: Important Safeguards

    2. Examine the mains supply cable for damage (only after removing the plug from the socket outlet). 3. If there is any sign of damage to the supply cable it MUST be renewed. The repair MUST be carried out by an Electrolux Service Agent or a similar qualified person.

  • Page 3: Before You Start

    It is in your interest to ensure that the plug is correctly attached to the mains cable. In case of doubt, consult a qualified electrician, as Electrolux cannot regard the repair of faults on the plug connection as a service that can be given free of charge under the terms of the guarantee.
  • Page 4 The guarantee may be invalidated by unauthorised repair or modification of the appliance. d. You may be charged by Electrolux if you call for an engineer to resolve a problem that we believe is covered in the instruction booklet.

  • Page 5: How To Assemble

    How To Assemble Assemble the cleaner completely before plugging into an electrical outlet. CAUTION: Moving parts, stay clear of brush roll when plugging in. CAUTION: Features may vary by model yet all parts assemble the same. NOTE: Step A Remove Dust Cup Dust Latch Dust Cup...
  • Page 6 Step C Replace Dust Cup Dust Cup Latch 4. Replace dust cup by aligning front of the bottom of dust cup into groove on cleaner. Pivot dust cup up against cleaner and rotate the dust cup latch to the right to secure. Step E Store Electrical Cord Cord Retainer...

  • Page 7: How To Use

    How To Use Do not plug in cleaner until you CAUTION: understand all controls and features. 1. Cord Retainer. To use, push electrical cord down into cord retainer. 2. ON/OFF Switch. International symbol I means On, International symbol O means Off. 3.

  • Page 8: Thermal Cut Off

    How To Use (continued) 12. Hose Retainers. Place hose on retainers to store hose on unit. 13. Carrying Handle. Use this handle to carry unit from one place to another. 14. Dusting/Upholstery Brush. Store dusting brush here. 15. Electrical Cord Hooks. Wrap electrical cord around them to store electrical cord on unit.

  • Page 9: How To Use Accessories

    How To Use Accessories Do not place cleaner on furniture or stairs as the brush roll may cause damage. Place cleaner CAUTION: on floor with the handle in storage position while using accessories. NOTE: Do not place cleaner on furniture or steps as the brush roll may cause damage.
  • Page 10 How to Check and Clear Hose Blockages Low suction or poor pickup may be due to a blockage in the vacuum cleaner. 1. Remove hose from hose retainer and check suction at end of hose - if little or no suction, check dust cup. Empty if needed.

  • Page 11: How To Maintain

    How To Maintain The instructions in this booklet serve as a guide to routine maintenance.To avoid unnecessary service calls, check the dust cup, belt, and brush roll often. Brush Roll The brush roll turns as it sweeps and combs the carpet nap. Remove hair and threads from the brush roll so it continues brushing the carpet.
  • Page 12 To Change Dust Cup Pleated Filter: CAUTION: Turn off the switch and unplug the electrical cord before changing the Pleated Filter. Never operate the vacuum cleaner without the dust cup or the pleated filter assembly. Dust Cup Latch Dust Cup Release dust cup by rotating dust cup latch to the left pointing to the unlock symbol ( ).
  • Page 13 To clean the Pleated Filter: 1. Remove the filter assembly by grasping handle and lifting upward and out of the dust cup. 2. Grasp the pleated filter and turn counter clockwise to remove. 3. Lift pleated filter from cone and wash. Shake excess water from filter. Do not submerge filter assembly –...
  • Page 14 4. To close, place micron filter door on top of bottom tab, pivot door up and press door against cleaner until it latches. Use ELECTROLUX replacement filters ONLY. HEPA Filter (on certain models only) Inspect the HEPA filter periodically and change as needed. For maximum efficiency, replace the HEPA filter periodically.
  • Page 15 floor. Then turn the knob. Call Electrolux Customer Services on 08706 055055. Call Electrolux on 08706 055055. Have the model and serial numbers ready when you call. See rating plate beneath the cleaner.
  • Page 16 08706 055055 1 dusting/ upholstery brush 1 hardware package (2 screws) Don’t Forget to Use Genuine Electrolux Belts Caution: Damages caused by the use of non-genuine parts are not covered by the Electrolux Guarantee. 1 vacuum cleaner handle Printed in U.S.A.
