Troubleshooting; Thermal Cut Off - Electrolux Z2250 Series Owner's Manual

CAUTION: Turn off the switch and unplug the electrical cord before servicing.
PROBLEM
Motor will not start.
Motor suddenly stops.
Does not clean the carpet
or floor.
No suction at the end of hose.
Noise from the brush roll
area.
Cleaner is hard to push.
Cleaner height knob
hard to turn.
Missing parts
Questions?

Thermal Cut Off

This vacuum cleaner has a special thermostat that protects the cleaner in case of motor overheating. If the cleaner suddenly
shuts off, push the on/off switch off (0) and unplug the cleaner. Check the cleaner for a possible source of overheating such as
a full dustbag, a blocked hose or clogged filter. If these conditions are found, fix them and wait at least 30 minutes before at-
tempting to use the cleaner. After the 30 minute period, plug the cleaner back in and push the on/off switch on (l). If the cleaner
still does not run, please call Electrolux Customer Care on 08706 055055.
CAUSE
✓
Electric Plug
✓
Thermal Cut Off
✓
Filters
✓
Dustbag
✓
Hose
✓
Belt
✓
Brush Roll
✓
Hose Adapter
✓ Filters
✓
Hose
✓
Dustbag
✓
Brush Roll
✓
Belt
✓
Floor Type Selector
✓
Belt
✓
Floor Type Selector
SOLUTION
Push plug securely into outlet.
Try another outlet.
Check circuit breaker.
See below.
Clean or replace the filters. Hint: If picking up fine
dust, the filters may not look dirty but a fine substance
tends to reduce suction when it blocks the airflow
through the filter(s). Page 6.
Replace the dustbag with a new dustbag. Page 6.
Be sure the dustbag is properly seated into the cleaner
body. Page 6.
Be sure hose adapter is secure on back of cleaner.
Page 8.
Remove any blockages from the hose that restrict the
airflow. Page 8.
Check to see that the end of the hose is firmly pressed
into the hose retainer in the back of the vacuum.
Check base hose and long hose. Page 8.
Replace a broken, cut, loose or out of shape belt.
Clean hair and thread from bristles and end cap area.
Replace brush roll if bristles are worn.
Be sure hose adapter is secure. Page 8.
Clean or replace the filters. Hint: If picking up fine
dust, the filters may not look dirty, but a fine substance
tends to reduce suction when it blocks the airflow
through the filters.
Remove any clogs from the hose that restrict the
airflow. Check base hose and long hose. Page 8.
Change dustbag.
Remove hood and clean debris or items from the brush
roll area.
Replace a broken, cut, loose or out of shape belt.
Page 7.
Put handle in operating position. Tilt the cleaner
back to raise the front wheels off floor. Then turn the
knob to a higher setting.
Replace a broken, cut, loose or out of shape belt.
Page 7.
Hint: Put handle in operating position. Tilt the
cleaner back to raise the front wheels off floor.
Then turn the knob.
Call 08706 055055. Know the model and serial
numbers when you call.
Call 08706 055055. Know the model and serial
numbers when you call.
9
