310AAV/310JAV
4- -Way Multipoise Induced Combustion Gas Furnace
Sizes 045 thru 155
Series E
The 310AAV/310JAV 4- -Way Multipoise Gas Furnace was
designed by Bryant dealers for Bryant dealers. Applications are
easy with 4- -way Multipoise design, through- -the- -furnace
downflow venting, 13 different venting options, and a design for
easy service access. An inner blower door is provided for tighter
sealing in sensitive applications. The 310AAV/310JAV furnace is
approved for use with natural or propane gas, and the 310JAV is
approved for use in Low NOx Air Quality Management Districts.
Product Data
STANDARD FEATURES
S Noise elimination combustion system
S Four- -position furnace: Upflow, Horizontal Right,
Horizontal Left, Downflow
Thirteen different vent options
S Compact design only 33- -1/3 in. (846 mm) tall
S Microprocessor based "smart" control center
Adjustable heating air temperature rise
Enhanced diagnostics with LED and reflective sight glass,
non- -volatile fault code memory, and self- -test feature
On- -board fuse for transformer protection
S Patented blocked- -vent safeguard to ensure proper furnace
venting
S Certified to leak 2 percent or less of its nominal air
conditioning CFM delivered when pressurized to 1- -In. W.C.
with all present air inlets, air outlets, and condensate drain
port(s) sealed.
S HYBRID HEATr Dual Fuel System compatible
A10252
S All models are chimney friendly when used with accessory
vent kit
S Twinning in Upflow, Downflow, and Horizontal
S Perfect Lightt Igniter
S Residential installations eligible for consumer financing
through the Comfort Credit Program
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Bryant 310AAV
Summary of Contents for Bryant 310AAV
- Page 1 S All models are chimney friendly when used with accessory vent kit The 310AAV/310JAV 4- -Way Multipoise Gas Furnace was designed by Bryant dealers for Bryant dealers. Applications are S Twinning in Upflow, Downflow, and Horizontal easy with 4- -way Multipoise design, through- -the- -furnace...
- Page 2 DIMENSIONS [130.5] [130.5] 2 1/16 2 1/16 [51.6] [51.6] [43.5] [43.5] Ø7/8 Ø7/8 [22.2] [22.2] ACCESSORY (2) ACCESSORY (2) 8 5/8 8 5/8 [219] [219] 6 13/16 6 13/16 [172.3] [172.3] 5 7/8 5 7/8 1 15/16 1 15/16 [148.5] [148.5] 5 5/8 5 5/8...
-
Page 3: Clearance To Combustibles
CLEARANCE TO COMBUSTIBLES A10269 Always Ask For Use of the AHRI Certified TM Mark indicates a manufacturer’s participation in the program. For verification of certification for individual products, go to www.ahridirectory.org. -
Page 4: Specifications
SPECIFICATIONS UNIT SIZE 024045 036045 024070 036070 048070 042090 048090 RATINGS AND PERFORMANCE Input Btuh* 310JAV Upflow; all 44,000 44,000 66,000 66,000 66,000 88,000 88,000 310AAV Nonweatherized ICS 310JAV Downflow/ 42,000 42,000 63,000 63,000 63,000 84,000 84,000 Horizontal Output Capacity 310JAV Upflow;... - Page 5 SPECIFICATIONS (continued) UNIT SIZE 060090 036110 048110 066110 048135 066135 060155 RATINGS AND PERFORMANCE Input Btuh* 310JAV Upflow; all 88,000 110,000 110,000 110,000 132,000 132,000 154,000 310AAV Nonweatherized ICS 310JAV Downflow/ 84,000 105,000 105,000 105,000 126,000 126,000 147,000 Horizontal Output Capacity 310JAV Upflow;...
- Page 6 SEE NOTES: 1,2,4,7,8,9 SEE NOTES: 1,2,3,4,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 UPFLOW UPFLOW DOWNFLOW A02058 A02059 A02061 SEE NOTES:1,2,3,4,5,7,8,9 SEE NOTES: 1,2,3,4,5,7,8,9 SEE NOTES: 1,2,4,5,6,7,8,9 DOWNFLOW DOWNFLOW DOWNFLOW A02060 A02063 A02062 Venting Notes 1. For common vent, vent connector sizing and vent material: United States, latest edition of the National Fuel Gas Code (NFGC), ANSI Z223.1/NFPA 54.
- Page 7 SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 HORIZONTAL RIGHT HORIZONTAL RIGHT A02068 A02070 SEE NOTES: 1,2,4,7,8,9 HORIZONTAL RIGHT A02069 SEE NOTES: 1,2,4,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 HORIZONTAL LEFT HORIZONTAL LEFT A02064 A02065 SEE NOTES: 1,2,4,5,7,8,9 SEE NOTES: 1,2,4,5,7,8,9 HORIZONTAL LEFT HORIZONTAL LEFT A02066 A02067...
- Page 8 ACCESSORIES DESCRIPTION PART NO. 024045 036045 024070 036070 048070 042090 048090 060090 036110 048110 066110 048135 066135 060155 FILCABBB0016 FILCABBB0020 Media Filter Cabinet FILCABBB0024 FILBBCAR0016 Cartridge Media Filter FILBBCAR0020 FILBBCAR0024 EXPXXUNV0016 EZ Flex Media Filter with End EXPXXUNV0020 Caps EXPXXUNV0024 EXPXXFIL0016 Replacement EZ Flex Filter EXPXXFIL0020...
-
Page 9: Model Number Nomenclature
Thermidistat Control can be configured for multiple use and staging. It must be configured for each specific application. ‡ Dual Fuel thermostat is used with furnace and heat pump application. MODEL NUMBER NOMENCLATURE Bryant Type Code Gas Furnace, 4--- Way Multipoise, 80% Fixed--- Capacity... - Page 10 AIR DELIVERY—CFM (With Filter)* EXTERNAL STATIC PRESSURE (In. W.C.) 310AAV/JAV RETURN-AIR UNIT SIZE SUPPLY SPEED Bottom High 1085 1035 024045 Med-High — Side(s) Med-Low — Bottom High 1440 1375 1305 1240 1160 1070 036045 Med-High 1360 1300 1240 1175 1115 1040 Side(s) Med-Low...
- Page 12 Casing shall be of .030 in. (.76 mm) thickness minimum, pre- - painted galvanized steel. Catalog No. PDS310A.45.6 E2010 Bryant Heating & Cooling Systems D 7310 W. Morris St. D Indianapolis, IN 46231 Printed in U.S.A. Edition Date: 09/10 Manufacturer reserves the right to discontinue, or change at any time, specifications or designs without notice and without incurring obligations.
Need help?
Do you have a question about the 310AAV and is the answer not in the manual?
Questions and answers
The blower motor is making a load noise when it in gages.model310AAV042090
A loud noise from the blower motor in the Bryant 310AAV furnace could be due to several reasons:
1. Dirty Blower Wheel or Housing – Accumulated dust and debris can cause imbalance and noise. Cleaning the blower wheel and housing may resolve this.
2. Loose Blower Wheel – If the blower wheel is not securely attached to the motor shaft, it can wobble and create noise. Ensure the set screw is properly tightened.
3. Worn or Failing Motor Bearings – Over time, motor bearings can wear out, causing grinding or squealing noises. If the bearings are failing, the motor may need replacement.
4. Obstructed Blower Wheel – Foreign objects inside the blower housing can cause rattling or scraping sounds. Inspect and remove any debris.
5. Improper Motor Mounting – If the motor is not properly secured to the blower housing, it can vibrate and generate noise. Check and tighten the mounting bolts.
If the issue persists, a qualified technician should inspect the furnace for further diagnosis.
This answer is automatically generated
What are the input and output capacities, in BTUs or Tons, for each Bryant 310 AAV0363 Furnaces ? We have two, that are twinned together. They were installed in FALL 2016.
