Fostex DV40 Supplement Owner's Manual

Version v1.3 supplement
Hide thumbs Also See for DV40:
Table of Contents

Advertisement

Quick Links

Download this manual See also: Owner's Manual, Supplement Owner's Manual
DV40 Owner's Manual
< Version V1.3 Supplement >
This owner's manual supplement describes
new functionality added by updating the
DV40 with software version 1.3.
Please refer to the original owner's manual
and V1.2 owner's manual supplement to-
gether along with this supplement to fully
utilize the functions of a DV40 running V1.3
software.
< Important Notice! >
When data recorded on a DV40 is exported
to a PC for editing, etc. and is then copied
back to the DVD-RAM disk again,
DO NOT COPY THE HISTORY FILE IN THE HSTF
(HISTORY FOLDER).
Suppose a DVD-RAM disk has a history file
copied back to it and is loaded into a DV40,
if MULTIPLE UNDO, OPTIMIZE or DELETE
functions are executed there is a high dan-
ger that the disk may be destroyed.
8288 694 000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DV40 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Fostex DV40

Summary of Contents for Fostex DV40

  • Page 1 8288 694 000 DV40 Owner's Manual < Version V1.3 Supplement > This owner's manual supplement describes new functionality added by updating the DV40 with software version 1.3. Please refer to the original owner's manual and V1.2 owner's manual supplement to- gether along with this supplement to fully utilize the functions of a DV40 running V1.3...

  • Page 2: Table Of Contents

    Model DV40 Owner’s Manual <Version V1.3 Supplement> Contents <1> Multiple Punch In/Out function in LIST PLAY mode ..............Using the Multiple Punch In/Out function in LIST PLAY mode ........3 <2> Single File Maximum Recording Capacity Select Function ............Selecting the Single Maximum Recording Capacity ............5 <3>...

  • Page 3: 1> Multiple Punch In/Out Function In List Play Mode

    Model DV40 Owner’s Manual <Version V1.3 Supplement> <1> Multiple Punch In/Out function in LIST PLAY mode It is now possible to implement multiple punch in/out function for ADR (Automatic Dialog Replacement) purpose. This is the mode to create a new BWF file every time punch in/out function is executed in the LIST PLAY mode.
  • Page 4 Model DV40 Owner’s Manual <Version V1.3 Supplement> While in the file creation process, the message "Pls Wait!" flashes. As shown in the diagram below, the progress of the file creation process is shown by the “level” indication on the FL display which reduces from right to left.

  • Page 5: 2> Single File Maximum Recording Capacity Select Function

    Model DV40 Owner’s Manual <Version V1.3 Supplement> <2> Single File Maximum Recording Capacity Select Function The maximum recording capacity of a single audio file (either BWF or SDII) was limited to 2GB on DV40 until now. Updating the software to V1.3 allows selecting either a 2GB or 4GB maxi- mum file recording capacity.

  • Page 6: 3> File Divide Function

    Model DV40 Owner’s Manual <Version V1.3 Supplement> <3> File Divide Function There is a case that an audio file larger than 2GB cannot be correctly recognized by a PC. In such a case, creating a smaller file by the “Divide File” menu which is newly added to the AUDIO EDIT mode allows as PC to recognize the file.

  • Page 7: Deleting A Divided File

    Model DV40 Owner’s Manual <Version V1.3 Supplement> 3. While "Sure?" flashes, press the [ENTER/YES] key. If the file is successfully divided, "Completed!" will be displayed. 4. Register the next SOURCE IN and OUT points and repeat the procedures 1. ~ 3. The divided files will be named in numerical serial sequence.

  • Page 8: 4> Updating Software Via A Dvd-Ram's Info Folder

    Model DV40 Owner’s Manual <Version V1.3 Supplement> <4> Updating Software via DVD-RAM INFO Folder "Version up?" SETUP menu which enables updates to the MAIN and ETHERNET CARD software by copying update files with a ".mot" extension to the BWF file INFO folder has now been added in V1.3.
  • Page 9 Model DV40 Owner’s Manual <Version V1.3 Supplement> 6. After updating the software for both the MAIN and ETHERNET CARD, press the [EXIT/NO] key (or [STOP] key) and then power cycle the DV40. 7. Press the [SETUP] key while pressing down the [STOP] key to enter the additional menu SETUP mode.

  • Page 10: 5> File Renumbering Function

    Model DV40 Owner’s Manual <Version V1.3 Supplement> <5> File Renumbering Function A "Renumber File?" UTILITY menu which allows reorganization of the file numbers has been added. If there are deleted files and the disk was optimized in previous software versions, the file numbers of the missing files still exist.

  • Page 11: 7> Permission To Use "/" As A File Name Character

    Model DV40 Owner’s Manual <Version V1.3 Supplement> <7> Permission to use “/” as a file name character A character “/” which is prohibited to use as a file name in Windows OS can be used on DV40 with software update to V1.3. <NOTE>...
  • Page 12 FOSTEX CORPORATION 3-2-35 Musashino, Akishima-shi, Tokyo, Japan 196-0021 FOSTEX AMERICA 15431, Blackburn Ave., Norwalk, CA 90650, U. S. A. © PRINTED IN JAPAN JULY 2002 8288 694 000 FX...
