This instruction book contains safety precautions, information on use and helpful hints and tips. To ensure you use this appliance effectively and safely, please read this instruction book carefully before installing or using this appliance and retain for future reference. The symbols below help you to find things more easily: Safety precautions Warnings and Safety information...
IMPOR ANT S IMPOR ANT S These warnings are provided in the interests of your safety. Ensure that you understand them all before installing or using this appliance. Your safety is of paramount importance. If you are unsure about any of the meanings or these warnings contact the Customer Care Department. Prior to installation Check the appliance for transport damage.
Instructions for the User Guide to use the instruction book Important Safety Instructions Instructions for the User General Information Description of the Appliance Using the Appliance Before Use To Start the Appliance Thermostat Control Hints for storage Storage time and temperature of foods How to use the four-star frozen food compartment 7 How to make ice cubes Storage Shelves...
UCTIONS F General information This appliance is designed for the refrigeration of food in a domestic home. It has a four-star frozen food compartment for ice making and frozen food storage. Description of the appliance 1. Frozen food compartment 2. Glass shelf 3.
Thermostat Control The thermostat control situated inside the refrigerator regulates the temperature of the larder compartment. Thermostat control is marked from 1-5 the higher the number, the colder the setting.
Do not use sharp or pointed items to remove a frozen ice cube tray from the freezer compartment. Storage Shelves The shelves in the refrigerator compartment are adjustable to allow storage of large items. The shelves can be re-arranged by opening the door to 90°.
Normal Operating Sounds You may hear faint gurgling or bubbling sounds when the refrigerant is pumped through the coils or tubing. When the compressor is on, the refrigerant is being pumped round and you will hear a whirring sound or pulsating noise from the compressor.
Defrosting The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located below the appliance, where it evaporates.
After letting the appliance run for at least half an hour replace the previously removed food into the **** -star compartment. When defrosting it is not necessary to remove the foods from the inner door and the refrigerator compartment. Important A temperature rise of the frozen food packs during defrosting may shorten their storage life.
Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, you are invited to contact our Coustomer Care Department by letter or telephone as follows:...
Guar Guar We Electrolux undertake that if within 12 months of the date of the purchase this ELECTROLUX appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, the company will, at our option repair or replace the same FREE OF...
Do not use detergents, abrasive powders, highly perfumed cleaning products, wax polishes or cleaning products containing bleach or alcohol. or the Ins or the Ins ERT 1546 Frozen food comp.: 18 Fresh food com.: 128 Frozen food comp.: 18 Fresh food com.: 122...
Ventilation Requirements The appliance must have adequate ventilation to ensure correct operation. Diagram shows the ventilation requirements when installed: A:* Under a worktop, or cupboard. * The clearance space of 10 cm above the appliance may be reduced to 5 cm providing a clearance space 2,5 cm is left on either side of the appliance.
Page 15
To reverse the top hinge assembly proceed as follows: Remove the 2 worktop retaining screws from the back of the appliance. Slide the worktop towards the rear and lift clear of the appliance. Remove the 2 upper hinge plate retaining screws. Remove the hinge plate from the top of the door.
Door Reversal of Freezer Compartment After reversing the refrigerator door, it is necessary to reverse the door of the frozen food compartment as well. Proceed as follows. Press the retaining lever inside the lower doorhinge Tilt the lower doorhinge out together with the freezer compartment door then remove it from the pin of the freezer compartment door.
Electrical Connection Electrical Connection Any electrical work required to install this appliance should be carried out by a qualified electrician or competent person. This appliance must be earthed. The manufacturer declines any liability should these safety measures not be observed. Electrical Requirements Before switching on, make sure the electricity supply voltage is the same as that indicated on the appliance...
Page 18
Time and method of storage of fresh foods in the refrigerator Foods Raw meat Cooked meat Roasted meat Raw minced meat Cooked minced meat Cold cuts Fresh fish Cooked fish Tinned fish, open Fresh chicken Fried chicken Fresh duck, goose...
Page 19
Storage time of deep-frozen and frozen products Foods Vegetables: green beans, green peas, mixed vegetables, marrow, corn, etc. Ready-cooked foods: vegetable dish, trimmings, with meat, etc. Ready-cooked foods: sirloin steaks, stews Soups: Fruits: cherry, gooseberry, fruit cream, Meat: chicken, duck, goose , tuna fish Ice-cream, Ice-lollies age time char age time char...
Page 20
From the Electrolux Group. The world’s No.1 choice. The Electrolux Group is the world's largest producer of powered appliances for kitchen, cleaning and outdoor use. More than 55 million Electrolux Group products (such as refrigerators, cookers, washing machines, vacuum cleaners, chain saws and lawn mowers) are sold each year to a value of...
