REMOTE AUTO START
STANDARD FEATURES
Some of the system's standard features include:
• 4-button remote transmitter
• Extended range receiver w/built-in LED status
indicator & valet switch
• Flashing parking lights
• Auto cold Start feature
• Stop & go feature
• Programmable engine run-time
• Hood & brake pedal safety inputs
OPTIONAL FEATURES
This system has optional features that may
require additional parts and/or labor. Please
contact your dealer for more details.
• Remote keyless entry (door lock/unlock)
• Trunk/hatch release
Note: Some features may not be appropriate
for certain vehicles.
REMOTE TRANSMITTER BUTTONS
Button 1
Button 3
Transmitter Icons
NOTE: Transmitter cosmetics may differ, but
button functions remain the same as described:
Button 1 locks the doors* and also activates
the Panic Mode* when held for 4 seconds.
Button 2 unlocks the doors*.
Button 3 controls the Remote Start feature.
Button 4 activates the Car Finder feature.
Optional Keyless Entry Instructions Included
SYSTEM MANUAL
Button 2
Button 4
SYSTEM OPERATION
DOOR LOCKING
To lock the system press transmitter button 1:
• The parking lights will flash once.
• The horn will honk once.*
• The doors will lock.*
• The LED will begin flashing after 3
seconds.
• The Starter Defeat feature will activate.*
*
Optional Feature
COMFORT CLOSURE
The optional Comfort Closure feature activates
the lock output as long as button 1 is held. Using
this feature will roll-up the windows and close
the sunroof on some late model vehicles.
To activate the Comfort Closure feature:
1. Press and release transmitter button 1 to
lock the doors.
2. Immediately press and hold button 1 again
until the windows and sunroof are closed.
• The LED will flash once.
• The parking lights will flash once.
• The doors will lock.*
*
Optional Feature
DOOR UNLOCKING
To unlock the system press transmitter button 2.
• The parking lights will flash twice.
• The horn will honk twice.*
• The doors will unlock.*
• The LED will stop flashing.
• The Starter Defeat will deactivate.*
*
Optional Feature.
1
