Electrolux 2223 208-81 User Manual

Electrolux fridge-freezer user manual
Hide thumbs


Quick Links

f r i d g e - f r e e z e r


ENN 28600
2223 208-81



  Related Manuals for Electrolux 2223 208-81

  Summary of Contents for Electrolux 2223 208-81

  • Page 1: User Manual

    - f r e e z e r USER MANUAL ENN 28600 2223 208-81...
  • Page 2: Important Safety Information

    IMPORTANT SAFETY INFORMATION It is most important that this instruction book should be retained with the appliance for future reference. Should the appliance be sold or transferred to another owner, or should you move house and leave the appliance, always ensure that the book is left with the appliance in order that the new owner can get to know the functioning of the appliance and the relevant safety information.
  • Page 3: Table Of Contents

    Start your appliance Temperature control Quick-freezing Freezing fresh food Frozen food storage Thawing Making ice cubes Use of the refrigerator-Setting the temperature Fresh food refrigeration Normal operating sounds Movable shelves Positioning the door shelves Hints and Tips Maintenance and Cleaning...
  • Page 4: Operation

    OPERATION Before using Remove all securing tapes. Wash inside the appliance with lukewarm water and bicarbonate of soda (5 ml to 0.5 litre of water). Do not use soap or detergent as the smell may linger. Dry thoroughly. Control panel Pilot light - Green Thermostat control knob Fast freeze light - Amber...
  • Page 5: Quick-Freezing

    Meat, fish and fruit should be thawed in the refrigerator compartment and small pieces of meat can even be cooked while still frozen, but you must ensure that it is thoroughly cooked through.
  • Page 6: Use Of The Refrigerator-Setting The Temperature

    Do not cover the shelves with any protective material, such as paper, cardboard or plastic, which may obstruct the air circulation through them. To help you use your refrigerator correctly, here are some more useful hints: Raw meat (beef, pork, lamb & wild fowl): wrap in polythene bags and place on top of the salad crispers.
  • Page 7: Movable Shelves

    Movable shelves The walls of the refrigerator have runners so that the shelves can be positioned as desired . For better use of space, the front half-shelves can lie over the rear ones. Positioning the door shelves To permit storage of food packages of various sizes, the door shelves can be adjusted in height.To make...
  • Page 8: Hints And Tips

    • Do not store uncovered food. • Remove suspect food from your refrigerator and clean, refer to ‘Maintenance and Cleaning’. • Ensure that food placed in the freezer is dated and labelled and used in date order to ensure that food is consumed at its best.
  • Page 9: Maintenance And Cleaning

    Replace the light cover by sliding it into its original position. Defrosting Refrigerator The refrigerator automatically defrosts every time the compressor stops. The water is discharged, via the pipe, into a tray located at the back of the appliance above the compressor, where it evaporates.
  • Page 10: Something Not Working

    SOMETHING NOT WORKING Important: If you call out an engineer to a fault listed below, or to repair a fault caused by incorrect use or installation a charge will be made, even if the appliance is under guarantee. Before contacting your local Service Force Centre, check the following points: Symptom No power to the appliance The light does not come on...
  • Page 11: Service And Spare Parts

    Please note that a valid purchase receipt or guarantee documentation is required for in-guarantee service calls. CUSTOMER CARE DEPARTMENT For general enquiries concerning your Electrolux appliance or for further information on Electrolux products, please contact our Customer Care Department by letter or telephone at the address below or visit our website at
  • Page 12: Guarantee Conditions

    Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour, materials or carriage on condition that: The appliance has been correctly installed and used only on the electricity supply stated on the rating plate.
  • Page 13: Technical Specification

    TECHNICAL SPECIFICATIONS POWER SUPPLY VOLTAGE AND FREQUENCY TOTAL POWER ABSORBED AVERAGE DAILY UNITS ELECTRICITY * GROSS CAPACITY NET CAPACITY STAR RATING This figure is based on standard test results in accordance with European Standard EN 153. Actual consumption will depend on how the appliance is used and where it is located. 220-240 V / 50 Hz 160 W 0.860 kWh...
  • Page 14: Installation

    INSTALLATION Warning IF YOU ARE DISCARDING AN OLD APPLIANCE THAT HAS A LOCK OR CATCH ON THE DOOR, YOU MUST ENSURE THAT IT IS MADE UNUSABLE TO PREVENT YOUNG CHILDREN BEING TRAPPED INSIDE. Depending upon the position which you choose for your appliance, you may wish to reverse the way in which the door opens.
  • Page 15: Electrical Connection

    The cover/carrier is indicated by the coloured insert at the base of the plug. A replacement cover/carrier must be obtained from your local Electrolux Service Force Centre. This appliance complies with the E.E.C. Directive No. 87/308 of 2.6.87 relative to radio interference suppression.
  • Page 16: Door Reversal

    Instructions for totally built-in appliances Door reversal The appliance is supplied with the right or left door opening. To change the opening direction of the door proceed as in the following instructions before installing it. 1. Unscrew the upper pin and remove the spacer 2.
  • Page 17 (I = short) (P = long) Apply the sealing strip pushing it between the refrigerator and the adjacent cabinet. Apply covers (C-D) on joint cover lugs and into hinge holes. Snap vent grille (B) and hinge cover (E) into position.
  • Page 18 Place guide (Ha) on the inside part of the furniture door, up and down as shown in the figure and mark the position of external holes. After having drilled holes, fix the guide with the screws supplied. Fix cover (Hc) on guide (Ha) until it clips into place Open the appliance door and the furniture door at 90°.
  • Page 19 Fix cover (Hd) on guide (Hb) until it clips into place. If the appliance is fixed to the side of the kitchen unit, simply slacken the screws in fixing brackets (E), move the brackets as shown in the figure and re- tighten the screws.
  • Page 20 . . e e l l e e c c t t r r o o l l u u x x . . c c o o m m © Electrolux plc 2007...

This manual is also suitable for:

Enn 28600
