  • Page 2: For Your Safety

    t i o Introduction This gas appliance has been designed and manufactured to all the necessary British Standards. It also carries the C.E. mark. The appliance complies with European Council Directive 90/396/EEC. It is important that you understand how to use and care for the appliance properly before you use it for the first time.

  • Page 3: Table Of Contents

    E O G 9 3 3 0 Contents Installing the appliance General information The cooling fan for the controls Ignition Lighting the oven and grill Oven light The grill The grill pan and handle The oven Baking trays and dishes Oven cooking charts Slow cooking The electronic timer...

  • Page 4: Installing The Oven

    E O G 9 3 3 0 Installing the oven For your safety This appliance must be installed and serviced by a competent person as stated in the Gas Safety (Installation & Use) regulations current edition and IEE Wiring Regulations. It is important that the appliance is suitable for your gas supply.

  • Page 5: General Information

    E O G 9 3 3 0 General information To get the best results from your new appliance please read these instructions carefully. You should pay particular attention to cooking times and gas mark settings as these may differ from your previous appliance. You may find it necessary to adjust these until you are more familiar with the appliance.

  • Page 6: Ignition

    E O G 9 3 3 0 Ignition The grill and oven burners light automatically when you turn on the control. If, for any reason either of the burners go out, the spark ignition will automatically relight it. Please note: You can only use the grill with the door fully or partially open.

  • Page 7: Lighting The Oven And Grill

    E O G 9 3 3 0 Lighting the oven and grill Grill To light: 1 Open the grill door. 2 Push in the control knob and turn it to the highest setting. This is shown by a large flame symbol. 3 Leave the grill door open when you you are using the grill.

  • Page 8: To Turn Off Any Burner

    E O G 9 3 3 0 To turn off any burner 1 Push in the control knob and turn it to the off position. This is shown by a large dot. For your safety When you are lighting any burner check that it has lit before you leave the appliance.

  • Page 9: The Grill

    E O G 9 3 3 0 The grill We suggest that you run the grill without food for approximately 5 - 10 minutes to burn off any residue from the surface. During this period an odour may be emitted, it is therefore advisable to open a window for ventilation.

  • Page 10: Cooking Positions

    E O G 9 3 3 0 Cooking positions There is only one position for the grill shelf (Position 2). Positions are counted from the top downwards. Most food should be cooked on the grid in the grill pan. You can turn the grid over to suit different thicknesses of food.

  • Page 11: The Grill Pan And Handle

    E O G 9 3 3 0 The grill pan and handle The grill pan is supplied with a removable handle. To attach the handle, place the wirework under the cut out in the pan so that the metal plate hooks over the top of the grill pan. Slide the handle to the left and over the central bump on the grill pan.

  • Page 12: Plate Warming

    E O G 9 3 3 0 To check the progress of the food when using the grill you should withdraw the grill pan on the shelf to attend to food. After removing the grill pan you can rest it on a heat resistant work surface if you need to. Plate warming You can use the grill compartment to warm plates while the oven is on.

  • Page 13: The Oven

    E O G 9 3 3 0 The oven For your safety Never leave the appliance unattended when the oven door is open. Before you use the oven you should wipe it out with a damp cloth. This will remove any dust. We suggest that you run the oven without food for 10 - 15 minutes at Gas mark 7 to burn off any residue from the surface.

  • Page 14: Oven Shelves

    E O G 9 3 3 0 Oven shelves The two oven shelves can be slotted into place in any of five positions. For safety the shelves will only pull out so far. If you want to remove a shelf completely, pull it forward as far as it will go, raise the front edge and lift it out.

  • Page 15: Baking Trays And Dishes

    E O G 9 3 3 0 Baking trays and dishes For your safety Never place cooking dishes, trays and so on over the oven burner. This will damage the oven as well as the ovenware and possibly the cabinet underneath the oven. Leave a gap of 13mm (½") between all dishes and the sides of Leave a gap of 13mm (½") between all...

  • Page 16: Oven Cooking Charts

    E O G 9 3 3 0...
  • Page 17 E O G 9 3 3 0...
  • Page 18 E O G 9 3 3 0...

  • Page 19: Food Preparation-Slow Cooking

    E O G 9 3 3 0 Slow cooking The slow cook setting gives a very low heat in the oven. It is particularly useful when you are cooking soups, stews and casseroles because the long slow cooking will make cheaper, tougher cuts of meat more tender. You need to cook food at gas mark 6 for 30 minutes before you turn the oven down to the slow cook setting.
  • Page 20 E O G 9 3 3 0 Soups, casseroles and stews Do not cook casseroles over 2.7kg (6lb). Cook in the middle of the oven or above. Cover food with a tight fitting lid or tin foil. Vegetables Cut into small pieces. Dried beans must be pre-soaked then boiled in an open pan for 15 minutes before adding to any dish.

  • Page 21: The Electronic Timer

    E O G 9 3 3 0 THE ELECTRONIC MINUTE MINDER Button 1 = ( ) Decrease control and minute minder setting button Button 2 = (+) Increase control ) Bell Symbol The electronic minute minder can also be used to show the time of day. Please note that this is a 24 hour clock, for example 2pm is shown as 1400.

  • Page 22: To Cancel The Minute Minder

    E O G 9 3 3 0 2. TO USE THE MINUTE MINDER The minute minder gives an audible reminder at the end of any period of cooking up to 23 hours and 59 minutes. To set press button (1) and the display will read 0.00, See Fig 5.

  • Page 23: Care And Cleaning

    E O G 9 3 3 0 Care and cleaning For your safety For hygiene and safety reasons you must keep this gas appliance clean. A build up of fat or other foodstuff could cause a fire. Try to mop up spills and splashes as soon as they happen. Do not use any polishes, caustic cleaners, abrasives, washing soda or soap powder except those recommended in this booklet.
  • Page 24 E O G 9 3 3 0 The oven The inside of the oven is finished in vitreous enamel. You should clean the oven regularly using hot soapy water and mild abrasives or a soap filled pad such as 'Brillo'. If you use any oven cleaners they must have the Vitreous Enamel Development Council (VEDC) seal of approval.

  • Page 25: Cleaning Between The Outer And Inner Door Glass

    E O G 9 3 3 0 Cleaning between the outer and inner door glass You can remove the glass from the oven and grill doors if you need to. The grill door is fitted with a trim. You must note the correct position of the trim when you remove the grill door glass.

  • Page 26: Cleaning The Door Glass

    E O G 9 3 3 0 Cleaning The Door Glass To prevent damaging or weakening the door glass panels avoid the use of the following: Household detergents and bleaches Impregnated pads unsuitable for non-stick saucepans Brillo/Ajax pads or steel wool pads Chemical oven pads or aerosols Rust removers Bath/Sink stain removers...

  • Page 27: What Is Wrong And Why

    E O G 9 3 3 0 What is wrong and why? We strongly recommend that you carry out the following checks on your appliance before calling a Service Engineer. Problem The oven or grill will not light. Check Check that the appliance is switched on at the wall. Check that the timer is set to 'manual' (See page 21).
  • Page 28 E O G 9 3 3 0 Problem Having difficulty cleaning any part of the appliance. Check Check that you are following the instructions for care and cleaning (See page 23). Problem The oven lights do not work. Check If you have had your appliance for some time you may need to replace an oven light bulb.

  • Page 29: Replacing An Oven Light Bulb

    E O G 9 3 3 0 Replacing an oven light bulb You need a 25 Watt small Edison screw with a temperature rating of T300. Make sure the oven is cool before you replace a bulb. Unplug the appliance. Open the oven door and remove the oven shelves.

  • Page 30: Service And Spare Parts

    E O G 9 3 3 0 Service and spare parts In the event of your appliance requiring service, or if you wish to purchase spare parts please contact your local Service Force Centre by telephoning:- 0 8 7 0 5 9 2 9 9 2 9 Your telephone call will be automatically routed to the Service Force Centre covering your post code area.
  • Page 31 Customer Care Department For general enquiries concerning your Electrolux appliance or further information on products, you are invited to contact our Customer Care Department by letter or telephone as follows or visit our website at www.electrolux.co.uk...

  • Page 32: Installation Instructions

    INSTALLATION INSTRUCTIONS Please note that the handle may differ in type and shape from that shown in the diagram. For your safety Where applicable Natural Gas and L.P. Gas versions of this appliance are available. Check that this model is suitable for the type of supply available. In the interest of safety this appliance must be installed and/or serviced by a competent person, as stated in the Gas Safety (Installation and Use) Regulations Current Editions.

  • Page 33: Technical Data

    TECHNICAL DATA DIMENSIONS Overall Flexible Gas Pipe Minimum Cabinet Solid Gas Pipe Minimum Cabinet Maximum Cabinet Weight of Appliance Minimum Clearance top of Appliance to Roof of Cabinet CONNECTIONS Flexible Hose Solid Pipe Electrical GRILL Burner Steel tubular burner with expanded metal frets. Heat Input Injector Marking OVEN...

  • Page 34: Safety Requirements/Ventilation

    IMPORTANT - SAFETY REQUIREMENTS This appliance must be installed in accordance with the Gas Safety (Installation and Use) Regulations Current Editions and the I.E.E Wiring Regulations. Detailed recommendations are contained in the following British Standard Codes of Practice - BS.6172, BS.5440: Part 2 and BS.6891. All British Standards must be 'Current Editions'.

  • Page 35: Location Of Appliance

    LOCATION OF APPLIANCE This appliance must not be installed in a bed-sitting room of volume less than 20m³ or in a bathroom, shower room or garage. It is essential that there is a minimum clearance of 3mm between the top surface of the appliance and the inside top of the cabinet.

  • Page 36: Installation

    INSTALLATION FITTING THE APPLIANCE AND CABINET It is recommended that a /8" 1100mm long angle bayonet flexible hose (B.F.S.) and a ½" straight socket (B.F.S.) be used for the installation. However any approved hose of the correct length can be used. IMPORTANT: Flexible tubing used must comply with BS 669 current editions.
  • Page 37 INSTALLATION FITTING THE APPLIANCE AND CABINET. Make suitable arrangements for gas and electrical supplies into the installation site. Preferably a junction box or a 3 pin earthed socket should be situated at the back of the cabinet below the oven. Fit cabinet as Fig.

  • Page 38: Connection To Electricity Supply

    2. CONNECTION TO ELECTRICITY SUPPLY WARNING: THIS APPLIANCE MUST BE EARTHED, DO NOT EARTH THIS APPLIANCE TO THE GAS SUPPLY PIPING. This appliance must be connected to a 230V-240V a.c. 50Hz supply which incorporates a 3 ampere fuse. If any other type of plug is used it should incorporate a 5 ampere fuse in either the plug or adapter or at the distribution board.
  • Page 39 Turn off the electricity supply and the thermostat; disconnect the pressure gauge and replace the test point plug . Turn on gas supply and check for gas soundness. NOTE: The electrical supply must be connected in order to test the pressure. Fig.7 4.

  • Page 40: Checking The Grill

    CHECKING THE GRILL Place the grill pan containing the grid under the grill burner. With the grill door open, turn on the grill tap, check that there is a spark from it's ignition system. This should continue until the burner is alight. There is a safety switch which shuts off the gas supply to the grill burner when the door is closed.

  • Page 41: Minute Minder Operation

    MINUTE MINDER OPERATION The minute minder gives an audible reminder at the end of any period of cooking up to 23 hours and 59 minutes. To set press button (1) and the display will read 0.00. Release button (1) and press and hold button (2). The display will count up in one minute intervals until the interval to be timed is reached, eg 30 minutes.

  • Page 42: Guarantee Conditions

    Guarantee Conditions Standard guarantee conditions We, Electrolux, undertake that if within 12 months of the date of the purchase this Electrolux appliance or any part thereof is proved to be defective by reason only of faulty workmanship or materials, we will, at our option repair or replace the same FREE OF CHARGE for labour,...

  • Page 43: Contents Check List

    Contents Check List Note: If you require relacements of the item listed below please contact your local Service Force Centre quoting the relevant part number. The loose contents of this pack include:- No. OFF DESCRIPTION Grill Pan Handle (311468100) Fixing Kit Grill Grid (311419801) Grill Pan (311409401) Oven Shelf...

  • Page 44: Important Notice

    This instruction booklet is accurate at the date of printing, but will be superseded if specification or appearance are changed. ELECTROLUX 55 - 77 HIGH STREET, SLOUGH, BERKSHIRE, SL1 1DZ TELEPHONE 0870 5 950950 Part Number:311654702 www.electrolux.co.uk © Electrolux plc 2003...
