  • Page 1 EN User Manual | Oven EOG1102COX...
  • Page 2: Table Of Contents

    WE’RE THINKING OF YOU Thank you for purchasing an Electrolux appliance. You’ve chosen a product that brings with it decades of professional experience and innovation. Ingenious and stylish, it has been designed with you in mind. So whenever you use it, you can be safe in the knowledge that you’ll get great results every time.
  • Page 3: Safety Information

    SAFETY INFORMATION Before the installation and use of the appliance, carefully read the supplied instructions. The manufacturer is not responsible for any injuries or damage that are the result of incorrect installation or usage. Always keep the instructions in a safe and accessible location for future reference.
  • Page 4: Safety Instructions

    similar accommodation where such use does not exceed (average) domestic usage levels. • Only a qualified person must install this appliance and replace the cable. • Do not use the appliance before installing it in the built-in structure. • Disconnect the appliance from the power supply before carrying out any maintenance.
  • Page 5: Electrical Connection

    • Before mounting the appliance, check if electrical ratings of the mains power the appliance door opens without restraint. supply. • Do not operate the appliance without the • Always use a correctly installed cavity bottom cover. It is a functional shockproof socket.
  • Page 6: Gas Connection

    • Do not change the specification of this appliance. Total power (W) Section of the cable • Make sure that the ventilation openings (mm²) are not blocked. maximum 3680 3x1.5 • Do not let the appliance stay unattended during operation. The earth cord (green / yellow cable) must be •...
  • Page 7: Internal Lighting

    door is never closed when the appliance • Concerning the lamp(s) inside this product operates. Heat and moisture can build up and spare part lamps sold separately: behind a closed furniture panel and cause These lamps are intended to withstand subsequent damage to the appliance, the extreme physical conditions in household housing unit or the floor.
  • Page 8: Adjustment To Different Types Of Gas

    A. Gas supply ramp, end of shaft with ramp B. Washer C. Elbow 5. Put the supplied gasket between the pipe and the gas supply ramp. Turn the pipe to the 1/2" gas supply ramp. 6. Use a 22 mm spanner to tighten the nuts. Keep the gas supply ramp in the correct position.
  • Page 9: Minimum Level Adjustment Of The Oven Burner

    Make sure that the gas supply pressure of the appliance is in line with the recommended values. If the supply gas pressure is changeable or different than the necessary pressure, you must fit an applicable pressure adjuster on the gas supply pipe. 3.5 Minimum level adjustment of the oven burner 1.
  • Page 10 3.6 Building In 7. Set the knob for the gas control to the maximum position and let the oven heat Only set up the appliance in a kitchen or in a for at least 10 minutes. kitchen-dining room. Do not set up the 8.
  • Page 11: Securing The Oven To The Cabinet

    min. 550 min. 560 ±1 65cm² 130cm² There must be a clearance of minimum 4 mm Only make connections with correct cables between the top surface of the appliance and for the power supplied. the inner top of the cabinet. When you install the appliance "built-under"...
  • Page 12: Product Description

    4. PRODUCT DESCRIPTION 4.1 General overview Control panel Knob for the heating functions Knob for the Minute Minder Knob for the gas control Power indicator Air vents for the cooling fan Heating element Lamp Turnspit hole Oven cavity bottom plate Shelf support, removable Shelf positions 4.2 Accessories...
  • Page 13: Daily Use

    5.2 Oven cavity bottom plate first time, put the bottom plate with the hole on its front part in the burner area, as shown When you buy the oven, at first the oven in "Product description" chapter. cavity bottom plate is together with the accessories.
  • Page 14: Clock Functions

    Oven function Application To turn on the lamp. Light To roast large pieces of meat on the turnspit. Turnspit 6.5 Using the grill 2. Release the knob for the gas control. Do not keep the knob for the gas control pushed for more than 15 seconds.
  • Page 15: Inserting Accessories

    7. Lay the back side of the spit on the turnspit frame. Refer to "Product description" chapter. 8. Remove the turnspit handle. 9. Select a function with the turnspit position. The turnspit rotates. 10. Ignite the grill burner. Refer to the cooking tables.
  • Page 16: Additional Functions

    9. ADDITIONAL FUNCTIONS 9.1 Cooling fan the oven cool. If you turn off the oven, the cooling fan can continue to operate until the When the oven operates, the cooling fan oven cools down. turns on automatically to keep the surfaces of 10.
  • Page 17: Gas Oven Cooking

    Prepare 1.4 - 1.5 kg of food. Food Tempera‐ Time Use the third or fourth shelf position. ture (°C) (min) Food Temperature Time (min) Bone-in beef, 1.0 kg min. 50 - 65 (°C) Boneless beef, 1.0 kg 55 - 65 Pizza, thin 200 - 210 20 - 30...
  • Page 18: Information For Test Institutes

    Use the third shelf position. Use the fourth shelf position. Maximum temperature is the default value for Food Tempera‐ Time all types of food. ture (°C) (min) Food Pieces Time (min) Egg custard in a bain- min. 70 - 85 marie 1st side 2nd side...
  • Page 19: Care And Cleaning

    (°C) (min) Small Conventional Baking 150 - 35 - 55 Preheat the oven for 10 cakes, 20 Cooking tray minutes. per tray Apple pie, 2 Conventional Wire shelf 4 80 - 90 Preheat the oven for 10 tins Ø20 cm Cooking minutes.
  • Page 20 Clean all accessories after each use and let them dry. Use a soft cloth with warm water and a mild detergent. Do not clean the accessories in a dishwasher. Do not clean the non-stick accessories using abrasive cleaner or sharp-edged objects. Accessories 11.2 How to remove: Shelf supports Remove the shelf supports to clean the oven.
  • Page 21 Step 2 Lift and pull the latches until they click. Step 3 Close the oven door halfway to the first opening position. Then lift and pull to remove the door from its seat. Step 4 Put the door on a soft cloth on a stable sur‐ face.
  • Page 22: Troubleshooting

    11.4 How to replace: Lamp Always hold the halogen lamp with a cloth to prevent grease residue from burning on the lamp. WARNING! Risk of electric shock. The lamp can be hot. Before you replace the lamp: Step 1 Step 2 Step 3 Turn off the oven.
  • Page 23: Service Data

    Problem Possible cause Remedy Steam and condensation settle on A dish was left in the oven for too Food should not be left in the oven the food and in the oven cavity. long. for longer than 15-20 minutes after cooking.
  • Page 24: Energy Efficiency

    13.2 Gas oven burner Gas type NOMINAL NOMINAL Reduced BY-PASS INJECTOR GAS POW‐ GAS FLOW gas power NEEDLE MARK ER (kW) (g/h) (kW) (1/100 mm) (1/100 mm) G20 (2H) 20 mbar Regulated G30/G31 30/30 mbar 13.3 Gas grill burner Gas type NOMINAL NOMINAL Reduced...
  • Page 28 867348110-H-112023...
