50" Grass Mulcher Kit - 1692885
REF NO.
PART NO.
1
1715811
2
1716151
3
1716150
4
1917372
5
1917356
6
1931332
7
1716697
Footnotes:
The above parts group applies to the following Mfg. Nos.:
1692885, 50" Grass Mulcher Kit
TP 400-2209-00-AT-SMA
QTY.
1
PLATE, Discharge Closure
1
BAFFLE Assembly, RH 50"
1
BAFFLE Assembly, LH 50"
10
NUT, Hex 5/16-18
10
LOCK WASHER, 5/16
10
BOLT, Carriage 5/16-18 x 0.625
3
BLADE, Mulch for 50"
DESCRIPTION
9
